Summary of Contents for Freutek SHS0001
- Page 1 MACHINE: SHS0001 MULTIFUNCTIONAL ELECTRIC SWEEPER SHS0001 MULTIFUNCTIONAL ELECTRIC SWEEPER MANUAL...
-
Page 2: Table Of Contents
Introduction ........................3 Security ..........................4 Explanation of Symbols…………………………………………………………………………………………………. 4 General description…………………………………………………………………………………………………………4 General safety rules .....................6 Safety Requirements for Batteries ................6 Description of the machines ....................7 Operational Performance ................... 7 Control Panel & Operating Components ..............7 Water Addition Method....................8 Technical Specifications ...................... -
Page 3: Introduction
Introduction Content and purpose The user manual provides the necessary information for customers to operate the machine safely, conveniently, and correctly, including technical characteristics, methods of operation, machine storage, maintenance, spare parts, and safety conditions. Before using the machine, users and professional maintenance technicians should read this manual carefully. -
Page 4: Security
Safety The following symbols indicate potentially hazardous situations. It is very important to take the protective measures indicated in these instructions. The manual is intended to prevent injuries. For effective accident prevention, please refer to the relevant regulations. Most accidents happen in the company, while working or traveling, if you don't pay attention to basic safety rules. - Page 5 When the machine is running, the working speed should be kept within 5km/h, and the dust should be moved every 30-45 minutes to achieve the best cleaning effect. In case of high voltage alarm when the machine is running and after operation, the battery should be charged in time to prolong its service life.
-
Page 6: General Safety Rules
26. To ensure the correct operation and safety of the machine, professionals or service centers must follow the maintenance section of this manual. 27. If the machine is to be dismantled and scrapped, supervise operations. Some harmful substances (such as used batteries, waste oil, plastic, etc.) must be sent to appropriate collection points to ensure compliance of disposal. -
Page 7: Description Of The Machines
Description of the machines Operational Performance The sweeper should be operated by a professional operator on relatively flat concrete, asphalt, ceramic or other ground (sweep and vacuum) to clean dust or light waste. Control Panel & Operating Parts 1. Key switch: This is used to power the vehicle, which is switched on after the key switch is operated. 2.Forward/Reverse Switch: By pressing the forward switch to position D and the throttle, the sweeper starts. -
Page 8: Water Addition Method
Water Addition Method Open inlet 1 of the water tank and add water to the tank. Technical Specifications Model SHS0001 Sweeping width 1260mm Side brush diameter 450mm (x2) Work Efficiency 6500m2/h Driving speed 0-9 km/h Hours of continuous work 3-4h... -
Page 9: Usage
Usage Before starting the machine Warning! 1. Check if the machine has been damaged by moving parts during transport. 2. Close the fixing plates on both sides and the front cover box, tighten the hook of the garbage can (see figure), and make sure the machine runs normally. Discharge Method 1. -
Page 10: Machine Operation
Machine Operation Note: When working, decide whether to temporarily start the vibration device based on the amount of waste on the clean ground. If the filter is clogged or full, the machine cannot collect the waste. The waste container should be emptied every time it is filled. Attention! Every 30-45 minutes of operation, the vibrating function must be stopped (depending on the ambient temperature and the volume of waste) and the waste must be poured out at the same time. -
Page 11: First Use
First use After the first use (8 hours), check If the connections and fasteners have been properly tightened; Check if the visible parts are intact. The durability and operational safety of the machine must be guaranteed by proper routine maintenance. The following are the general maintenance requirements. -
Page 12: Maintenance
Maintenance Maintenance Schedule Every Every Every 100 Every 200 Every 400 Maintenance Delivery of the machine hours hours hours(1) 0 hours（1 0 hours（1 Evaluaciones Evaluaciones ） ） Controlling the height adjustment of the side brush and the main brush If the main brush is the side brush are entangled or twisted Complete inspection and... -
Page 13: Check The Pressure Of The Main Brush On The Ground
Check the pressure of the main brush on the ground (8 hours after first use) Check that the main brush is in the correct position and away from the ground. The procedure is as follows: use the machine on level ground. Keep the machine's main brush stationary and rotated for a few seconds;... -
Page 14: Main Brush Replacement Method
Main Brush Replacement Method Attention! When replacing the main brush, it is preferable to wear gloves, because the brush may be sharp. Loosen nut 1 and open the left baffle (as shown below). As in the figure below, tilt the sweeper backwards and raise it. Remove screws 1 and 2. Remove the main brush. -
Page 15: Brush Replacement Method
Brush Replacement Method When changing the edge brush, it is best to wear gloves to avoid injuring yourself with the sharp bristles. The main function of the side brush is to collect the waste from both sides towards the center thanks to its own rotation and then pour it into the waste container. -
Page 16: Filter Maintenance And Replacement
Filter Maintenance and Replacement Unscrew the 8 nuts (as shown below) Pull out the filter (as shown below Unscrew the 6 nuts and remove the dust on them Note: Do not use water or detergents for cleaning, as this may damage the filter. If possible, clean the rubber gasket of the frame filter. -
Page 17: Charger Usage
Charger use Before using the charger, please read this manual carefully to get the most out of the product. When using this product, in order to ensure the personal safety of operators and the safe and stable operation of the equipment, the following contents should be carefully observed! Attention! Make sure the DC plug is firmly connected to the outlet. -
Page 18: Model Rules
Model Rules The voltage and rated capacity of the battery paired with the charger must be within the rated range. This charger is only suitable for the specified battery type, referring to the nameplate. Connect the battery and charger securely. Charging Process Fully automatic charging The charging process of the lead-acid battery is as follows: (the battery charging curve is attached... -
Page 19: Maintenance In The Event Of A Breakdown
Maintenance in the event of a breakdown Problem Fault analysis Resolution Steps Turn on the power Blown fuse Replace the fuse Different switch If the Battery loses Load; Replace the battery switch voltage (If it is not used for a long time, please charge it once every two months) Brush handle... - Page 20 Problem Fault analysis Resolution Steps Abrasion of the skin Replacing the cap The handle is not lowered and the Check the cause of Cleaning is wire rope is locked. jam and remove the fault incomplete Filter failure Blocked filter Vibrating powder for 2-10 minutes Blower motor Loose connection Check the wiring...
- Page 21 Problem Fault analysis Resolution Steps Transfer of Damaged front dust plate Replace the front dust plate Waste Forward Rolling main brush Damaged front deflector Replace the front dust cover with respect to the Front dust cover Sanding brush too fast The brush is attached too Reduce brush pressure Other tightly to the wire rope...
-
Page 22: Circuit Diagram
Circuit Diagram Electrical Mounting Drawing Name function Large DC Contactor Overall Main Power Supply Main line fuse Positive Overall Main Power fuse DC fuse drive axle Positive Pole Assurance Built-in power supply Fuse 10A DC Power Conversion Fuse Fuse 20A DC Secondary Circuit Positive Fuse Fuse 15A DC Key Master Fuse... -
Page 23: Disposal
DISMANTLING OR DEMOLITION MUST BE CARRIED OUT BY THE CUSTOMER, IN FULL COMPLIANCE WITH THE REGULATIONS IN FORCE ON THE SUBJECT, HANDING OVER THE ENTIRE MACHINE OR THE PARTS THAT COMPOSE IT TO COMPANIES APPOINTED FOR THESE SERVICES. As the owner of an electrical or electronic appliance, the law (in accordance with EU Directive 2012/19/EU on waste electrical and electronic equipment and the national laws of the EU Member States that have implemented this directive) prohibits you from disposing of this product or its electrical/electronic accessories as municipal solid household waste and...
