WaveLinx

IR Remote User Guide (#ACC-P-RT)

This document is intended for installers and set-up technicians

using the WaveLinx PRO IR Remote in the WaveLinx PRO

Wireless System

ATTENTION

DISCLAIMER OF LIABILITY: Cooper Lighting Solutions assumes no liability for damages or losses of any kind that may arise from the

improper, careless, or negligent installation, handling or use of the products.

IMPORTANT: This manual provides information on the functions supported by the WaveLinx PRO IR Remote when used with the

WaveLinx Wireless System. It is not a replacement for the WaveLinx PRO User Manual.

Table of Contents

Need help?

Do you have a question about the WaveLinx ACC-P-RT and is the answer not in the manual?

Questions and answers

Summary of Contents for Cooper WaveLinx ACC-P-RT

Page 1 Wireless System ATTENTION DISCLAIMER OF LIABILITY: Cooper Lighting Solutions assumes no liability for damages or losses of any kind that may arise from the improper, careless, or negligent installation, handling or use of the products. IMPORTANT: This manual provides information on the functions supported by the WaveLinx PRO IR Remote when used with the...
Page 2: Table Of Contents
Classified WaveLinx PRO IR Remote User Manual (SR9) WaveLinx PRO IR Remote User Manual - Table of contents WaveLinx PRO IR Remote Introduction ............................... 3 WaveLinx PRO IR Remote Overview ..............................3 Supported WaveLinx PRO Devices ..............................4 Installing the Batteries ..................................4 WaveLinx PRO IR Remote Use Best Practices ..........................
Page 3: Wavelinx Pro Ir Remote Introduction
Classified WaveLinx PRO IR Remote User Manual (SR9) WaveLinx PRO IR Remote Introduction The WaveLinx PRO IR Remote (#ACC-P-RT) is not a substitute for using the WaveLinx Mobile App to perform the initial site setup. It is a tool to be used in addition to the mobile app to assist with a useful subset of testing/programming functions.
Page 4: Supported Wavelinx Pro Devices
Classified WaveLinx PRO IR Remote User Manual (SR9) Supported WaveLinx PRO Devices The WaveLinx PRO IR Remote can be used on the WaveLinx PRO sensor devices listed below. Note that the sensor devices must have the minimum firmware version shown or a newer version to operate with the WaveLinx PRO IR Remote commands. Ambient Integrated Sensors (WAA) including: •...
Page 5: Wavelinx Pro Ir Remote Use Best Practices
Classified WaveLinx PRO IR Remote User Manual (SR9) LED Indicators during IR Remote Use There are indicators on both the IR remote and the sensor to show that the signal is being sent and received. • When any button is pressed on the IR remote, the LED at the top of the remote will flash red one time for each button press. •...
Page 6: Quick Operation Test Of A Device
Classified WaveLinx PRO IR Remote User Manual (SR9) Quick Operation Test of a Device Installers or setup technicians: Use the WaveLinx PRO IR Remote to perform a quick operation check. The selected sensor will cycle the connected lighting to verify that the sensor is properly controlling the lighting. The operation test command will work in the following situations: 1: Stand directly below the sensor and point the IR remote at the sensor lens.
Page 7: Disable Pairing In A Device
Classified WaveLinx PRO IR Remote User Manual (SR9) Disable Pairing in a Device Setup technicians: Use the WaveLinx PRO IR Remote to command the sensor to stop searching for a Wireless Area Controller. The disable pairing command will work in the following situations: 1: Stand directly below the sensor and point the IR remote at the sensor lens.
Page 8: Set The Occupancy Sensor Sensitivity
Classified WaveLinx PRO IR Remote User Manual (SR9) Set the Occupancy Sensor Sensitivity Setup technicians: Use the WaveLinx PRO IR Remote to command the occupancy sensor to HI or LO sensitivity. Set the occupancy sensor to low (LO) sensitivity if it is detecting motion outside of the desired coverage area or to slow the response time. Set the occupancy sensor to high (HI) sensitivity to regain the full motion sensing range and to ensure a faster response time.
Page 9: Place An Open Loop Daylight Set Into Test Mode
Classified WaveLinx PRO IR Remote User Manual (SR9) Place an Open Loop Daylight Set into Test Mode Setup technicians: Use the WaveLinx PRO IR Remote to command an open loop daylight set into test mode. This command is issued to any supported sensor connected to a fixture that is operated by the open loop daylight set.
Page 10: Adjust The Daylight Dimming Response
Classified WaveLinx PRO IR Remote User Manual (SR9) Adjust the Daylight Dimming Response Setup technicians: Use the WaveLinx PRO IR Remote to adjust the lighting’s dimming response based on the incoming daylight light level. This command will operate for open loop daylight sets and for closed loop daylight sets. The daylight dimming adjustment commands will work in the following situations: The area must have a configured open loop daylight set OR an enabled closed...
Page 11: Assign Point Guards (Advanced Use Only)
Classified WaveLinx PRO IR Remote User Manual (SR9) Assign Point Guards (Advanced Use Only) Setup technicians: Use the WaveLinx PRO IR Remote to assign Point Guards in a user defined area that has a large quantity of devices reporting to a single zone. This feature assumes advanced knowledge and is intended to be used by technicians familiar with large zone application or when working under guidance from technical support.
Page 12 Classified WaveLinx PRO IR Remote User Manual (SR9) The point guard assignment command will work in the following situations: The area must have a zone defined with devices in the zone. 1: Stand directly below the sensor that is to function as a Point Guard and point the IR remote at the sensor lens.
Page 13 Visite www.cooperlighting.com para conocer nuestros términos y condiciones. Cooper Lighting Solutions 1121 Highway 74 South Peachtree City, GA 30269 P: 770-486-4800 www.cooperlighting.com Cooper Lighting Solutions is a For service or technical assistance: registered trademark. 1-800-553-3879 All other trademarks are Property of Canada Sales ©...
