GeoSmartPro AFY01GB User Manual

Smart air fryer
Hide thumbs

Advertisement

Quick Links

Download this manual
Smart Air Fryer
User Manual
Carefully read this instruction manual before
switching on your Smart Air Fryer for your
utmost safety.
Smart & healthy companion for your cooking.
Fry | Grill | Roast | Bake

Advertisement

loading
Need help?

Need help?

Do you have a question about the AFY01GB and is the answer not in the manual?

Questions and answers

Summary of Contents for GeoSmartPro AFY01GB

  • Page 1 Smart Air Fryer User Manual Carefully read this instruction manual before switching on your Smart Air Fryer for your utmost safety. Smart & healthy companion for your cooking. Fry | Grill | Roast | Bake...
  • Page 2 CONTENTS …Page 4-6 Warnings and Cautions Air Fryer Assembly ...Page 7-9 Operating Instructions ...Page 10-20 Specifications ...Page 21 …Page 22 Warranty App setup ...Page 23-25 Troubleshoot ...Page 26...
  • Page 3 CONTENTS What’s in the box Basket & Handle x 1 Tray x 1 Manual Air Fryer Images are for illustration purposes.
  • Page 4 OPERATING INSTRUCTIONS DANGER -Do not immerse the housing in water or rinse under the tap due to the multi-electrical and heating components -Do not let the liquid enter the appliance to prevent electric shock or short-circuit. -Keep all ingredients in the basket to prevent any contact from heating elements. -Do not cover the air inlet and the air outlet when the appliance is working.
  • Page 5 OPERATING INSTRUCTIONS -Keep the appliance out of the reach of children when it is switched on or cooling down. -Keep the appliance and its power supply cord away from heat or sharp edges that could cause damage. -Keep the power supply cord away from any parts of the appliance that may become hot during use.
  • Page 6 OPERATING INSTRUCTIONS -Always use the appliance on a stable, heat-resistant surface, at a height that is comfortable for the user. -Use of an extension cord with the appliance is not recommended. -This appliance should not be operated by means of an external timer or separate remote control system, other than that supplied with this appliance.
  • Page 7 OPERATING INSTRUCTIONS General description（Fig.1） 1 Basket 2 Basket handle 3 Transparent window 4 Digital touch control panel 5 Air inlet 6 Air outlet openings 7 Mains cord 8 Frying tray...
  • Page 8 OPERATING INSTRUCTIONS Attaching the fry basket handle: The fry basket handle might come disassembled in your appliance’s packaging. To attach the fry basket handle: -Remove the paper label. Pull the fry basket out of the appliance. -Slide the attachment point on the handle downward until it clicks into place. -The air fryer basket handle should lock into place and should not detach once it is locked into place.
  • Page 9 OPERATING INSTRUCTIONS Inserting 1. Place the air fryer Tray in the Basket. The air fryer Tray is adjustable, once the tray is adjusted to the height, food is placed closer to the heating element for broiling. You can also use it to make the total size of the basket smaller when cooking smaller quantities of food.
  • Page 10 OPERATING INSTRUCTIONS Tray position 2: Automatic switch-off The appliance has a built in timer, it will automatically shut down the appliance when count down reaches zero. You can manually switch off the appliance by pressing off button, it will automatically shut down the appliance in 20 seconds. Electromagnetic fields (EMF）...
  • Page 11 OPERATING INSTRUCTIONS Using the appliance 1. Connect the mains plug into an earthed wall socket. 2. Carefully pull the basket out of the air fryer 3. Place the ingredients in the basket. 4. Slide the basket into the Air Fryer Note: Do not exceed the MAX indication (see section “settings”...
  • Page 12 OPERATING INSTRUCTIONS Control panel presentation Notes: 8 functions are provided: Chicken drumsticks, Steak, Fish, Cake, Pizza, Sausage, Chips, and Bacon. You can use the Menu button to choose the different cooking food you like.
  • Page 13 OPERATING INSTRUCTIONS Menu pre-setting:...
  • Page 14 OPERATING INSTRUCTIONS After touching menu button , you can choose menu you like. After choosing the function, Please Start/Pause button to start cooking during the cooking process, if you want to adjust time or temperature, kindly press the Time/temperature button first.
  • Page 15 OPERATING INSTRUCTIONS Shake indicator : The shake indicator will illuminate when the cooking cycle has reached its halfway point. This halfway time gives you the opportunity to shake or flip your food in appliance, which helps ensure even cooking. Note: If you do not remove the basket and shake the food, the shake light on the control panel will remain illuminated.
  • Page 16 OPERATING INSTRUCTIONS Tip: To remove large or fragile ingredients, lift the ingredients out of the pan by a pair of tongs. 13. When a batch of ingredients is ready, the fryer is instantly ready for preparing another batch. Settings This table below will help you to select the basic settings for the ingredients. Note : Keep in mind that these settings are indications.
  • Page 17 OPERATING INSTRUCTIONS Temp ℃ Min-Max（g） Time（Min） Shake Remark Thin frozen fries 300-700 9-16 Thick frozen fries 300-700 11-20 Home-made fries（ 300-800 10-16 Add 1/2 tbsp of oil 8X8mm) Homemade potato 300-800 18-22 Add 1/2 tbsp of oil wedges 300-750 12-18 Add 1/2 tbsp of oil Home-made potato cubes...
  • Page 18 OPERATING INSTRUCTIONS Tips -Small ingredients usually require a slightly shorter preparation time than larger Ingredients. -A larger amount of ingredients only requires a slightly longer preparation time, a smaller amount of ingredients only requires a slightly shorter preparation time. -Shaking smaller ingredients halfway during the preparation time optimizes the end Result and can help prevent unevenly fried ingredients.
  • Page 19 OPERATING INSTRUCTIONS Making home-made fries: To make home-made fries, follow the steps below: 1. Make the potatoes peel and slice. 2. Wash the potato sticks thoroughly and dry them with kitchen paper. 3. Pour 1/2 tablespoon of olive oil into a bowl, put the sticks on top and mix until the sticks are coated with oil.
  • Page 20 OPERATING INSTRUCTIONS You can remove any remaining dirt by degreasing liquid. Note : The basket and frying tray are dishwasher-proof. Tip : If dirt is stuck to the basket or the bottom of the pan, fill the pan with hot water with some washing-up liquid.

  • Page 21: Specifications

    SPECIFICATIONS Technical Specification Product name: GeoSmartPro Air Fryer Product model: AFY01GB (Black) Power: 1800W Capacity: 8 Litre Control: Digital Panel Pre-set program: 8 (Drumsticks, steak, fish, cake, pizza, sausages, chips, bacon) Temp (Min-Max): 80 - 200 °C High-speed air circulation: Yes...

  • Page 22: Warranty

    GeoSmartPro, repair or alteration by a person other than a person authorised by GeoSmartPro or failure to follow instructions for use are not covered by this warranty. Additionally, normal wear and tear, including, but not limited to, minor discoloration and scratches are not covered by this warranty.
  • Page 23 2.4Ghz and the 5Ghz is temporarily turned off to pair your Smart Air Fryer. Registration: Download the GeoSmartPro Enter your email address on the app from the App Store or registration interface to receive a Google Play.
  • Page 24 Air Fryer during the pairing process. The option to add Air Fryer will automatically appear on your GeoSmartPro App. If not, click on the “add button” and select the Smart Air Fryer icon to connect. When prompted, enter your Wi-Fi details and click next...
  • Page 25 CONNECT TO THE GEOSMARTPRO Once you’ve entered all the details, the app will now scan to add your Smart Air Fryer and connect it through your Wi-Fi network for remote access. Wait until your configuration is successful, then tap ”Complete” & Enjoy your Smart Air Fryer Note: •...

  • Page 26: Troubleshoot

    TROUBLESHOOT Problem Possible cause Solution The Smart Air Fryer does not The appliance is not plugged Put the mains plug in an earth work wall socket. Reduce the amount the The amount of ingredients in ingredients in the basket so it The ingredients fried with the the basket are overfill or the results in even and tasty...
  • Page 27 TROUBLESHOOT More FAQ available on GeoSmartPro app and at www.geosmartpro.com Information on the disposal for Waste Electrical & Electronic Equipment (WEEE) This symbol on the products and accompanying documents means that used electrical and electronic products should not be mixed with general household waste.
  • Page 28 CONNECT TO THE GEOSMARTPRO ADDRESS GeoSmartPro Ltd, Watford Croxley, 1 Floor, Building 2, Croxley Business Park, Watford, Hertfordshire, WD18 8YA. ONLINE www.geosmartpro.com support@geosmartpro.com 040523AFY01GB...
