SEC-SH
Energy-saving Intelligent Drying Control System
Date：Dec., 2023
Version: Ver. A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SEC-SH and is the answer not in the manual?

Questions and answers

Summary of Contents for Shini SEC-SH

  • Page 1 SEC-SH Energy-saving Intelligent Drying Control System Date：Dec., 2023 Version: Ver. A...

  • Page 2: Table Of Contents

    Contents 1. General Description ..................4 1.1 Coding Principle ..................5 1.2 Feature ....................5 1.3 Safety Regulations .................. 7 1.3.1 Safety Signs and Labels ............... 7 1.4 Exemption Clause ................... 7 2. Structure Characteristics and Working Principle ......... 9 2.1 Working Principle ..................
  • Page 3 Table Index Table4-1：Control Panel ................... 12 Table4-2：User Menu Parameter Table ............16 Table4-3：User Parameter Setting Table ............17 Table4-4：Recipe List ..................20 Table 4-5：Trouble Table .................. 21 Table 5-1：Common Faults and Troubleshooting ..........23 Picture Index Picture 1-1：Energy-saving Intelligent Drying Control SystemSEC-150SH ..4 Picture 2‑1 Working principle ................

  • Page 4: General Description

    The energy-saving intelligent drying control system SEC-SH can be implemented and modified on most hopper dryers. Remove the original control system of the hopper dryer and replace it with the Shini energy-saving intelligent drying control system, which can save 30%~80% energy consumption according to different blower airflows and environments.

  • Page 5: Coding Principle

    1.1 Coding Principle 1.2 Feature 1) Features microcomputer PID controller, LCD screen. 2) 28 default preprograms material receipt, and simply select materials as required. The system can automatically set the drying and exhaust air temperatures for easy operation. 3) It has a self-adaption function and simply sets the drying temperature; the control system will match the exhaust air temperature.
  • Page 6 Chapter 5, which contains service instructions intended for service engineers. Other chapters contain instructions for the daily operator. Any modifications of the machine must be approved by SHINI in order to avoid personal injury and damage to machine. We shall not be liable for any damage caused by unauthorized change of the machine.

  • Page 7: Safety Regulations

    Shini (including employees and agents). Shini is exempted from liability for any costs, fees, claims and losses caused by reasons below: 1) Any careless or man-made installations, operation and maintenances upon machines without referring to the Manual prior to machine using.
  • Page 8 3) Any operational actions that are not authorized by Shini upon machine, including adding or replacing accessories, dismantling, delivering or repairing. 4) Employing consumables or oil media that are not appointed by Shini. 8(25)

  • Page 9: Structure Characteristics And Working Principle

    2. Structure Characteristics and Working Principle 2.1 Working Principle Note: The drying temperature will be decreased in the heat insulation mode. Picture 2‑1 Working principle 9(25)

  • Page 10: Installation And Debugging

    Picture 3-2. 3) Step 3, connect to the pipe heater, blower and thermocouple, etc. of the original dryer to the SEC-SH according to the circuit diagram of the manual. 4) Step 4, fix the exhaust air thermocouple on one of the hopper mounting holes of the dryer, as shown in Picture 3-2.

  • Page 11: Power Connection

    Exhaust air thermocouple Universal adapter board Picture 3-2：Installation Steps 3.2 Power Connection 1) Make sure the voltage and frequency of the power source comply with those indicated on the manufacturer nameplate that attached to the machine. 2) Power cable and earth connection should conform to your local regulations.

  • Page 12: Operation Guide

    4. Operation Guide 4.1 Control Panel Picture 4‑1：Control Panel Table4-1：Control Panel ICONS Name Represents the percentage of the current electric heating operating power, with a maximum value of "100" and a minimum Heating ICONS value of "0". The current value is 20%, indicating that the power of the electric heating operation is 20% of the maximum power Represents the percentage of the current fan operating power.

  • Page 13: Common Interface

    Heat Lit: The unit is in Heat preservation mode Preservation Off: The unit is not in Heat preservation mode Mode icon Lit: PID parameter self-tuning is on Self-setting icon Off: PID parameter self-tuning is off Steady yellow: Stop/In stopping Status indicator Steady green: In operation Flickering red: Fault alarm On/Off button...
  • Page 14 If the user parameter [lock temperature] is set to "no", the set temperature can be directly modified under the main interface, the operation is as follows: Note: You can also modify the set temperature in the user parameter. 4.2.1.2 Check related information on the main screen 1) The control mode is: Recipe mode: 2) The control mode is: Self-adaption mode: 4.2.1.3 The timing time is displayed on the main screen...

  • Page 15: Fault Screen

    4.2.1.4 ECO Mode After the first start-up and the drying time, when the air exhaust set temperature ＞ the actual temperature, and the anti-excessive drying time (default 30 minutes) is over, the unit will enter the ECO mode. The actual drying temperature decreases and the temperature is determined by the cooling deviation (default 20 ℃);...

  • Page 16: Delayed Shutdown And Standby Interface

    4.2.3 Delayed shutdown and standby interface 4.2.3.1 Delay stop interface Note: In the case of delayed shutdown, the main interface and the delayed shutdown interface are alternately displayed every 2 seconds until the shutdown countdown is over. 4.2.3.2 Standby interface Picture 4-4：Standby interface Note: Enter the standby interface after the delayed shutdown ends.

  • Page 17: Parameter Table

    Start time Mon.~ Sun. time setting hr./min./sec. You can query all faults that have occurred Press the <Set> key for 2s to Historical fault in the last 10 times clear the history of failures. Comm. address During external comm., it Baud rate must set the parameters Comm.
  • Page 18 on the home screen. This parameter is Self-tuning Disabled Disable/use displayed only when the machine is running Chinese Multiple languages Chinese /English Recipe Control mode Recipe Mode mode/Adaptive mode Check the version of Version current controller. On the home screen, press the "Menu" key to enter the menu. Select User Settings in the menu bar and press the "Set"...
  • Page 19 shutdown time: Thursday shutdown 00:00 00:00-23:59 time: Friday shutdown 00:00 00:00-23:59 time: Saturday shutdown 00:00 00:00-23:59 time: Sunday shutdown 00:00 00:00-23:59 time: Press the "Menu" key from the home screen to enter the menu. Select User Settings in the menu bar and press the "Set"...

  • Page 20: Recipe List

    parity Data length Stop bit 4.4.2 Recipe list Table4-4：Recipe List Drying temperature Exhaust air Groups Ingredients Drying time (min) (℃) temperature (° C) PETG PMMA PEEK 20(25)

  • Page 21: Trouble Table

    Note: Under the condition that the moisture content of materials meets the standard, decrease the exhaust air temperature appropriately can improve the energy-saving effect. 4.4.3 Trouble Table This controller has various alarm functions. When a failure occurs, the alarm interface displays the current fault. The specific fault code meaning is shown in the following Table.
  • Page 22 1. The machine continues to run when the alarm is given. After troubleshooting, the machine automatically resets. 2. Detection after power on (1) [SV] - [PV] > [low temperature alarm] and delay [low temperature reaction time] Low temperature alarm. When the temperature rises, automatic reset. If you want to prohibit, set [low temperature reaction time] = 0.

  • Page 23: Troubleshooting

    5. Troubleshooting Table 5-1：Common Faults and Troubleshooting Fault Possible Reasons Solution 1. Thermocouple poor contact. 1. Check and connect it closely. Probe failure 2. Thermocouple wire broken. 2. Check and replace. 1. Temp. control large error or fault of the 1.

  • Page 24: Maintenance And Repair

    6. Maintenance and Repair Attention! All screws of electrical components inside the control box must be fastened tightly, without regular inspections! 6.1 Maintenance Schedule 6.1.1 General Machine Information Model Manufacture date Ф Voltage V Frequency Hz Power 6.1.2 Installation & Inspection Check if the pipe joint is tightly locked by clips or not.

  • Page 25: Half-Yearly Checking

    Check exhaust fan’s working state. Check whether the exhaust fan and dust-proof screen are blocked. 6.1.6 Half-yearly Checking Check whether the heat-resistant air pipe is damaged. Check the drying heater. Check the blower. 25(25)
