- Page 1 User Manual 125kHz RFID Access Control Reader SecureEntry-AC600...
-
Page 2: Table Of Contents
Table of contents Specifications: ................................3 Set contents: ................................... 4 Features: .................................... 4 Introduction ..................................5 Installation ..................................5 Wiring Diagram ................................6 Drawing Connection Diagram ........................... 7 Sound and light signalling ........................... 10 Admin Menu - Standalone Mode Settings ....................11 Device Management ......................... -
Page 3: Specifications
Specifications: • Warranty: 1 year • Product type: RFID card, password and fingerprint access control reader • Material: metal • Processor: 32-bit microprocessor with ARM core • Operating frequency: 125 kHz • Max number of employees in the database: 10,000 •... -
Page 4: Set Contents
Set contents: • RFID Access Control System • Screws and mounting pins • Allen key • Manual Features: • The access control reader offers user verification through an RFID card, individual password and fingerprint • Ability to set a single verification method or a combination of several methods •... -
Page 5: Introduction
Introduction The product in this series is a new generation of multifunctional autonomous access control. It uses a 32-bit microprocessor with an ARM core, which is efficient, stable and reliable. It includes reader mode and stand-alone access control mode, etc. Widely used in various situations, such as offices, residential communities, villas, banks, etc. -
Page 6: Wiring Diagram
Wiring Diagram... -
Page 7: Drawing Connection Diagram
Drawing Connection Diagram 1. Shared power supply Remark. Door contact and alarm function are optional. - Page 8 2. Special power supply Remark. Door contact and alarm function are optional.
- Page 9 3. Reader Mode...
-
Page 10: Sound And Light Signalling
Sound and light signalling Operation status Light signal Beep Ready for action Operation successful One longer beep Green Operation failed Three short signals Starting the programming mode Two short signals via the administrator Disabling Programming Mode One longer beep via Admin Tab Pressing the number One short beep button... -
Page 11: Admin Menu - Standalone Mode Settings
Admin Menu - Standalone Mode Settings Device Management Entering Stages of action Programming Menu Description Default Mode New admin code 999999 Change the # new admin admin code code # Card Add an reading/fingerprint admin card input or fingerprint twice* Card Remove an reading/fingerprint... -
Page 12: Add And Remove Users
Add and remove users Entering Programming Menu Stages of action Description Default Mode Card reading / Continuous double fingerprint addition of entry...* card users fingerprints Entering the 8 or 10 Add card digit card number users by # ...* card number Entering the ID Add card or... -
Page 13: Ways To Access
Delete users Card Remove reading/fingerprint card users input ...* by read card / Delete „...” Means fingerprints repetition by entering Previous a fingerprint Operation Please enter your 8 Delete card Press* or 10 digit card users by to exit. number...* card number Enter ID number #... -
Page 14: Advanced Settings
Door opening setting via 1 user card/ fingerprint Door opening setting by 2-10 2-10 # user cards/fingerprints Fingerprints Advanced settings Entering Stages of Programming Menu Description Default action Mode Door open time range: (0-300) # 0-300s, 0 equals 50ms Alarm time setting, 0s means no alarm... - Page 15 The device will be locked for 10 minutes if incorrect operations performed 5 times LED Off Switching On Turning off keyboard backlighting Turning on the keyboard backlight Keyboard backlight (2-99) # time: 2-99 sec. Sound off Sound on...
-
Page 16: Reader Mode Settings
Reader mode settings Entering Menu Stages of Description Default Programming action Mode New Admin Change the 999999 Code # admin code Card reading Add an / double administrator input card or Fingerprint* fingerprint Card reading Remove an / double administrator input card or Fingerprint*... - Page 17 Alarm time setting, 0s means no alarm Alarm Time (1-99) # Range: 1- 99min Set the (0-255) # device number Wiegand (26-58) # Output:26-58 bits Keyboard transmission format 4 bits 8-bit keyboard transmission format Virtual card output number...
-
Page 18: Admin Card Support
Admin card support Read added admin card -> Read first user card -> Read second user card -> ... -> Read admin card again Note: The add tab is used to add tab users continuously and quickly. When reading the card for the first time, you will hear a short beep twice and the LED will illuminate orange. -
Page 19: User Support
User support 1. Change your user code with a card Press * -> read card -> enter old code # -> enter new code # -> re-enter new code # Remark. The default code "1234" of the matching card cannot open the door unless you change the other codes. - Page 20 Remark. When the alarm is activated, the user can turn off the alarm by reading the registered card or entering the registered fingerprint or administrator code. 2. Factory reset Users can restore the factory default settings if they forget the admin code or modify the default settings.
