Summary of Contents for DMP 7830F-R
- Page 1 INSTALLATION AND PROGRAMMING GUIDE 7830F-R Graphic Remote Annunciator...
-
Page 2: Table Of Contents
CONTENTS Get Started ......... 1 Additional Programming ....7 What’s Included .............1 Access the User Menu ........7 What You’ll Need ..........1 User Menu ...............7 Procedure ..............1 Backlighting Brightness ......7 Internal Speaker Tone ........7 Install the Annunciator ....2 Internal Volume Level ........ -
Page 3: Get Started
GET STARTED The 7830F-R Graphic Remote Annunciator offers an easy to use touchscreen interface, a LED indicator, an internal speaker, a simple terminal connection to a 4-wire keypad bus, and other features. Keypads can be mounted on a backbox or a flat surface with appropriate fasteners. -
Page 4: Install The Annunciator
Do not overtighten. When all wire connections have been completed, place the annunciator cover back onto the base and snap it into place. Figure 2: Mounting Hole Locations 7830F-R Installation and Programming Guide | Digital Monitoring Products... -
Page 5: Wire The Annunciator
Send Data to Panel* Power from Panel* *Required connections Keypad Back Black - Ground Green - Receive Data To Panel Keypad Bus Yellow - Send Data Red - Power Figure 3: Keypad Wiring 7830F-R Installation and Programming Guide | Digital Monitoring Products... -
Page 6: Use The Annunciator
Figure 4: Keypad Layout Carousel Menu The carousel menu options allow the user to quickly and easily perform functions on the 7830F-R Graphic Remote Annunciator. These options are operational at all times with a user code. SILENCE - Press SILENCE to silence the main alarm bell and the Fire Bell Output. This does not stop an alarm ▶... -
Page 7: Program The Panel
DEVICE SETUP *UNUSED* Enter a name for the device. Device Type DEVICE SETUP Select FI (Fire). Stop STOP Press CMD until STOP displays. Press a top row select area to save programming. 7830F-R Installation and Programming Guide | Digital Monitoring Products... -
Page 8: Program The Keypad
ADDING INFO. ADDING INFO COMPLETED displays to confirm a successful SURE? upload. Press and release the microSD card to eject. Stop Press CMD until you reach the end of the menu, then select STOP to save the new STOP settings. 7830F-R Installation and Programming Guide | Digital Monitoring Products... -
Page 9: Additional Programming
Click Download and enter Your Name, Your Company, and Email information. After the .zip download is complete, unzip the files and save them all to the root directory of a FAT32 format microSD card. 7830F-R Installation and Programming Guide | Digital Monitoring Products... - Page 10 Press CMD until Restart Keypad displays. Press Restart. Do not remove the microSD card or disrupt power. 10. When the annunciator is finished restarting and returns to the home screen, remove the microSD card. 7830F-R Installation and Programming Guide | Digital Monitoring Products...
-
Page 11: Reference
Annunciator Bus Wiring Specifications ▶ DMP recommends using 18 or 22-gauge unshielded wire for all keypad and LX-Bus circuits. Do not use twisted pair or shielded wire for LX-Bus and Annunciator Bus data circuits. To maintain auxiliary power integrity when using 22-gauge wire, do not exceed 500 feet. When using 18-gauge wire, do not exceed 1,000 feet. -
Page 12: Certifications
I N T R U S I O N • F I R E • A C C E S S • N E T W O R K S Designed, engineered, and manufactured in Springfield, MO 2500 North Partnership Boulevard using U.S. and global components. Springfield, Missouri 65803-8877 LT-2780 1.01 24322 800.641.4282 | DMP.com © 2024...
