Thermal camera JCU Installation
instructions
Warning: Product installation and
operation
This product must be installed and operated in
accordance with the instructions provided. Failure to
do so could result in personal injury, damage to your
boat and/or poor product performance.
Caution: Service and maintenance
This product contains no user serviceable
components. Please refer all maintenance and repair
to authorized Raymarine dealers. Unauthorized repair
may affect your warranty.
Tools required
JCU installation requires the following tools:
• Jigsaw power drill.
• Power drill.
• 6.4 mm (0.25 in) drill bit.
• Screwdriver.
Document number: 87126-1
Parts supplied
1. Joystick Control Unit (JCU).
2. Bezel.
1
3
2
4
5
D11967-1
Date: 12 2010
Advertisement
Summary of Contents for Raymarine JCU
- Page 1 Please refer all maintenance and repair to authorized Raymarine dealers. Unauthorized repair may affect your warranty. Tools required JCU installation requires the following tools: • Jigsaw power drill. • Power drill. • 6.4 mm (0.25 in) drill bit. D11967-1 •...
-
Page 2: Location Requirements
JCU, as shown in the "Thick panel mounting" diagram in this document. ii. To mount the JCU to a panel thickness of 0.79 cm (0.31 in) or The standard method for mounting the JCU is a flush or panel mounting arrangement. - Page 3 Thin panel mounting Thick panel mounting Thermal camera JCU Installation instructions...
- Page 4 123.2 mm (4.9 in) optional drill guide This document may not print true to scale. Before modifying mounting surface, ensure printed template matches the measurements provided. 129.54 ±1.25 mm (5.1 ±0.049 in) cutout 141.4 mm (5.6 in) outside of JCU D11991-1 Thermal camera JCU Installation instructions...
-
Page 5: Raymarine Customer Support
You can obtain this product information using the menus within your product. Raymarine provides a comprehensive customer support service. You can contact customer support through the Raymarine website, telephone and email. If you are unable to resolve a problem, please use any of these facilities to obtain additional help. - Page 6 .c o m Thermal camera JCU Installation instructions...
