TG-201 LINKX user
manual.
Device diagram and instructions
1. Antenna
2. LCD display
3. Down button for changing channel and adjusting volume
4. On / Off / Mute / Set – Transmitter buttons; Additional function for TG-201T: to mute
the audio signal
On / Off (Off) / Set – Receiver buttons
5. Up button for changing channel and adjusting volume
6. Headset input / microphone input (transmitter)
Headphone output (receiver)
7. Two-way communication switch (transmitter)
8. Talk button (receiver)
9. Lanyard connection point
10. Label area
11. Battery compartment and a built-in lithium
polymer battery
12. Battery compartment cover and screws
13. Micro-USB charging port
14. Force quit button
Advertisement
Summary of Contents for MEXPO TG-201 LINKX
- Page 1 TG-201 LINKX user manual. Device diagram and instructions 1. Antenna 2. LCD display 3. Down button for changing channel and adjusting volume 4. On / Off / Mute / Set – Transmitter buttons; Additional function for TG-201T: to mute the audio signal On / Off (Off) / Set –...
- Page 2 Explanation of the illustration on the LCD display Connecting the headset to the transmitter and the headphones to the receiver Insert the plug (3.5 mm) of the headset into the transmitter input (6) and the headphone plug (3.5 mm) into the receiver (6). Make sure that the plug is fully inserted into the device.
- Page 3 Transmitter Using buttons and (5) allows to set the volume level from 4 to 8. Quickly pressing the power switch (4) activates the mute function (MUTE) - the volume indicator disappears and the crossed sound symbol icon flashes. Quickly pressing the power switch again cancels the mute function.
