- Page 1 DARTH VADER ™ LIMITED COLLECTOR'S EDITION THRÓNOS200S GAMING PRO CHAIR QUICK ASSEMBLY GUIDE...
- Page 2 PCH-S203DV English Thank you for purchasing this high-quality gaming chair from Primus. To ensure proper assembly and safe use of this product, please follow the instructions contained in this guide. Gas lift cylinder Base with cover 1. Box content Back rest...
-
Page 3: Assembly Steps
Step Description Image Mount the gas lift and its cover into the top of the chair base by placing the larger end into the hole in the center. M8x20mm allen head screw (16) M5x10mm screw (2) with caps Proceed to attach the mechanical base to the seat assembly using four of the supplied M8x20mm screws. - Page 4 Step Description Image Use the supplied M5x10mm and M5x8mm screws to attach the plastic covers over the attachment points on both sides, between the seat cushion and the back rest. Attach the seat assembly to the base by sliding the center hole of the mechanical base over the gas lift cylinder.
