ASSEMBLY AND MANUAL OPERATION

FOR THE INDUSTRIAL MOTOR DRIVE

INDU DC 35

Table of Contents

Need help?

Do you have a question about the INDU DC 35 and is the answer not in the manual?

Questions and answers

Summary of Contents for GROS INDU DC 35

Page 1 ASSEMBLY AND MANUAL OPERATION FOR THE INDUSTRIAL MOTOR DRIVE INDU DC 35...
Page 2: Table Of Contents
ASSEMBLY AND MANUAL OPERATION FOR THE INDUSTRIAL MOTOR DRIVE INDU DC 35 TABLE OF CONTENTS Important safety recommendations........................................ Technical data................................................... INDU DC 35 dimensions............................................Preparation..................................................Mechanical assembly of chain hoist of motor drive................................Operating mode via emergency release......................................Operating mode via gear motor..........................................
Page 3: Technical Data
ASSEMBLY AND MANUAL OPERATION FOR THE INDUSTRIAL MOTOR DRIVE INDU DC 35 16. The protection system is designed for use with IMMOVABLE objects only. If the door comes into contact with a moving object, serious personal injury, death and/or property damage may occur.
Page 4: Indu Dc 35 Dimensions
ASSEMBLY AND MANUAL OPERATION FOR THE INDUSTRIAL MOTOR DRIVE INDU DC 35 INDU DC 35 DIMENSIONS PREPARATION DANGER! To avoid injury, observe the following points: -The motor drive must be installed without tensions, -The motor drive must not move on the shaft, -The structure and foundation of all components must be suitable for the forces involved.
Page 5 ASSEMBLY AND MANUAL OPERATION FOR THE INDUSTRIAL MOTOR DRIVE INDU DC 35 (Fig. 3) Open the motor drive cover, pull the cable from the chain hoist through the rubber stop- per which is located on the base of the motor (Fig.
Page 6: Operating Mode Via Emergency Release
ASSEMBLY AND MANUAL OPERATION FOR THE INDUSTRIAL MOTOR DRIVE INDU DC 35 ASSEMBLY WITH A BRACKET: WARNING! To avoid damage of the motor drive and door, the motor drive must be mounted on a console or bracket so its vibrations are dampened.
Page 7: Operating Mode Via Gear Motor
ASSEMBLY AND MANUAL OPERATION FOR THE INDUSTRIAL MOTOR DRIVE INDU DC 35 OPERATING MODE VIA GEAR MOTOR The emergency manual operation is designed to open or close the door during a power failure. Its activation interrupts the control voltage. Electrical operating mode is no longer possible.
Page 8: Central Box - Motor Drive Operating Mode
ASSEMBLY AND MANUAL OPERATION FOR THE INDUSTRIAL MOTOR DRIVE INDU DC 35 CENTRAL BOx - MOTOR DRIVE OPERATING MODE Digital LED display: On first start-up, the display shows followed by a countdown from Without adjusted limit positions. With adjusted limit positions.
Page 9: Description Of Central Box Functions
ASSEMBLY AND MANUAL OPERATION FOR THE INDUSTRIAL MOTOR DRIVE INDU DC 35 DESCRIPTION OF THE CENTRAL BOx FUNCTIONS AUTOMATIC DOOR CLOSING Action: SHORT PRESS IMPORTANT! CAUTION! The automatic door closing function “AUTO CLOSE” To change any setting of the conditions or time of...
Page 10: Table Of Functions
ASSEMBLY AND MANUAL OPERATION FOR THE INDUSTRIAL MOTOR DRIVE INDU DC 35 3. Briefly press to confirm the selected door guide type. The corresponding diode lits continuously for the door guide type “SL, HL, VL”. Then the display shows . You can start setting the door limit position of opening.
Page 11: Description Of Menu Functions
ASSEMBLY AND MANUAL OPERATION FOR THE INDUSTRIAL MOTOR DRIVE INDU DC 35 DESCRIPTION OF MENU FUNCTIONS MENU 0 Limit position settings Press and hold the SET button for approx. 6 seconds to access limit position settings, the display will show The display will show .
Page 12 ASSEMBLY AND MANUAL OPERATION FOR THE INDUSTRIAL MOTOR DRIVE INDU DC 35 TOTTMANN MODE IN BOTH DIRECTIONS Selecting the number means: Long press - open the door. Long press - close the door. TOTTMAN MODE IN DIRECTION OF CLOSING, AUTOMATIC MODE...
Page 13 ASSEMBLY AND MANUAL OPERATION FOR THE INDUSTRIAL MOTOR DRIVE INDU DC 35 1. 2 Press and hold the SET button for approx. 6 seconds to access basic function 1. 2 settings, the display will show Adjustment Press the UP button until the display shows...
Page 14 ASSEMBLY AND MANUAL OPERATION FOR THE INDUSTRIAL MOTOR DRIVE INDU DC 35 MENU Speed settings Press and hold the SET button for approx. 6 seconds to access speed settings, the display will show Speed of the closing Press the UP button until the display shows...
Page 15 ASSEMBLY AND MANUAL OPERATION FOR THE INDUSTRIAL MOTOR DRIVE INDU DC 35 Press and hold the SET button for approx. 6 seconds to access speed settings, the display will show Distance of slow Press the UP button until the display shows...
Page 16 ASSEMBLY AND MANUAL OPERATION FOR THE INDUSTRIAL MOTOR DRIVE INDU DC 35 MENU 4 Time and conditions for automatic closing settings Press and hold the SET button for approx. 6 seconds to access time and conditions 4. - of automatic closing settings, the display will show...
Page 17 ASSEMBLY AND MANUAL OPERATION FOR THE INDUSTRIAL MOTOR DRIVE INDU DC 35 MENU 5 Safety function settings (safety edge and/or light curtain) Press and hold the SET button for approx. 6 seconds to access safety function 5. - settings, the display will show...
Page 18 ASSEMBLY AND MANUAL OPERATION FOR THE INDUSTRIAL MOTOR DRIVE INDU DC 35 CAUTION! The safety edge/light curtain will be automatically detected when the limit positions are set. Performing a full cycle of opening and closing the door after resetting the limit positions of the door.
Page 19 ASSEMBLY AND MANUAL OPERATION FOR THE INDUSTRIAL MOTOR DRIVE INDU DC 35 Executes ONLY OPEN action of the door. Regardless of where the motor drive is located and what status is turned on, the motor drive will ONLY execute the OPEN action (including motion detector and infrared sensor).
Page 20 ASSEMBLY AND MANUAL OPERATION FOR THE INDUSTRIAL MOTOR DRIVE INDU DC 35 The lamp is switched on all the time when the door is moving. The lamp is switched on all the time when the door is stopped. The lamp flashes when the door is moving.
Page 21 ASSEMBLY AND MANUAL OPERATION FOR THE INDUSTRIAL MOTOR DRIVE INDU DC 35 Press and hold the SET button for approx. 6 seconds to access additional device function settings, the display will show Safety edge Press the UP button until the display shows...
Page 22 ASSEMBLY AND MANUAL OPERATION FOR THE INDUSTRIAL MOTOR DRIVE INDU DC 35 MENU 8 Maintenance alarm function settings Press and hold the SET button for approx. 6 seconds to access maintenance alarm function settings, the display will show Maintenance alarm...
Page 23: Common Faults And Solutions
ASSEMBLY AND MANUAL OPERATION FOR THE INDUSTRIAL MOTOR DRIVE INDU DC 35 COMMON FAULTS AND SOLUTIONS Appearance Cause of the fault Solution of the fault 1. Encoder failure. 1. Replace the encoder. 2. The encoder cannot record 2. Replace the encoder cable.
Page 24: Description Of Radio Receiver (Optional)
ASSEMBLY AND MANUAL OPERATION FOR THE INDUSTRIAL MOTOR DRIVE INDU DC 35 DESCRIPTION OF RADIO RECEIVER (OPTIONAL) The external radio uses the standard open code format HCS301, 868MHz. . Remote control with 4 buttons. 3. The radio receiver with central box use a standard USB interface as a connection.
Page 25: Schematic Connections
ASSEMBLY AND MANUAL OPERATION FOR THE INDUSTRIAL MOTOR DRIVE INDU DC 35 SCHEMATIC CONNECTIONS Main circiut board XH01 Input terminal – circuit board power supply (parts 1 and 2) - 24 V DC XH0 Output terminal – accessories and additional warning lamp power supply - 24 V DC XH03 Output terminal –...
Page 26 ASSEMBLY AND MANUAL OPERATION FOR THE INDUSTRIAL MOTOR DRIVE INDU DC 35 XH05 Electronic lock output terminal ±24V Electronic lock output ports, output current max. 2A, time 3s. Function menu switched on. XH06 Auxiliary relay output terminal Auxiliary relay ports, max. 100 W.
Page 27 ASSEMBLY AND MANUAL OPERATION FOR THE INDUSTRIAL MOTOR DRIVE INDU DC 35 E d. will show an error , which means that the DW self-test has failed. In this case, TOTTMANN mode will be activated auto- E d. matically during next closing of the door. Check the air pressure switch (see common faults and solutions page and ) to fix the fault and repeat the above self-test until it is completed successfully.
