YO Relay Switch

User guide v1.1

Table of Contents

Need help?

Do you have a question about the YO Relay Switch and is the answer not in the manual?

Questions and answers

Summary of Contents for YOSensi YO Relay Switch

Page 1 YO Relay Switch User guide v1.1...
Page 2: Release Notes
YO Relay Switch User guide v1.1 page 2/26 Release notes Released Version Key changes 10.06.2024 Initial release. 08.07.2024 Changes in location of LEDs. Reset button relocation www.yosensi.io...
Page 3: Table Of Contents
Conﬁgurable parameters Parameters description Downlink message Update Channel state Update Channel output mode Conﬁguration node via Yosensi Management Platform Conﬁguration node with Yosensi mobile app Connecting node with network Yosensi Management Platform conﬁguration Adding node manually Adding node via Bluetooth...
Page 4: Product Description
Product description Overview The YO Relay Switch is a remotely controlled LoRaWAN switch equipped with two control channels. This actuator can transmit the state of its input and control its output. The device operates in LoRa Class C, which means it has the ability to listen continuously beyond short periods of data transmission.
Page 5: Physical Interfaces
5/26 Figure 2 Device sticker. Physical interfaces LEDs YO Relay Switch communicates its current behavior to the user by RGBW LED placed on the top of the device shown on ﬁgure 1. DIODE STATUES INTERPRETATION BEHAVIOUR COLOUR DEVICE STATUS Single ﬂash...
Page 6: Specifications
YO Relay Switch User guide v1.1 page 6/26 Speciﬁcations Physical Figure 3 Dimensions of the device. PHYSICAL SPECIFICATION Dimensions Height: 90 mm Width: 36 mm (2 pole) Depth: 58 mm Colour Light grey (RAL 7035) Mounting method 35 mm DIN rail standard...
Page 7: Operating Conditions
YO Relay Switch User guide v1.1 page 7/26 Operating conditions OPERATING CONDITIONS Temperature 0° to 70°C Humidity 0 to 90% Placement Indoor use Power supply 6 - 30 V DC 5 - 21 V AC Power consumption Typical: 18 mA DC (12 V DC)
Page 8 YO Relay Switch User guide v1.1 page 8/26 Figure 6 Relay State Channel 2 chart. www.yosensi.io...
Page 9: Installation
YO Relay Switch User guide v1.1 page 9/26 Installation Package contents Device. Warranty card. Antenna. Safety precautions SAFETY PRECAUTIONS SYMBOL DESCRIPTION Device is marked with a symbol saying that electrical and electronic products may not be mixed with unsorted household waste. Remember that batteries used to power the device must be treated at a specialized treatment facility.
Page 10: Installation Guide
YO Relay Switch User guide v1.1 page 10/26 Installation guide 1. Mount the device on a 35 mm DIN rail. Figure 7 Device mounted on 35 mm DIN rail. 2. Connect the antenna to the device. Figure 8 Device with antenna.
Page 11 YO Relay Switch User guide v1.1 page 11/26 3. Screw the load wires to the device at the designated locations for the ﬁrst channel (CH1) and the second channel (CH2). Figure 9 Connecting communication wires to device terminal blocks .
Page 12: Operation
3. Server – in most cases, a cloud-based service where data is processed, stored, analysed, and presented in user-friendly ways (via a user interface); Yosensi default and recommended tools are Yosensi Management Platform (for IoT structure management) and Grafana (for data presentation).
Page 13: Device Configuration
(generic): conﬁguration data for LoRaWAN connection, ble (generic): bluetooth settings, device (dynamic): individual conﬁguration for a speciﬁc device (this section’s structure differs for each device), Sample conﬁguration ﬁle for the YO Relay Switch device. "info": { "devmodel": "LNRS", "fwver": "1.0.0", "loraradio": "SX1261",...
Page 14 YO Relay Switch User guide v1.1 page 14/26 GENERICS PARAMETERS SECTION NAME DESCRIPTION POSSIBLE DEFAULT READ/ VALUES VALUE WRITE devmodel Device name LNRS fwver Firmware version 1.0.0 loraradio Radio chipset model SX1261 info lorawanver LoRaWAN stack version 1.0.2 loraregion LoRaWAN region...
Page 15: Device Parameters
YO Relay Switch User guide v1.1 page 15/26 DEVICE PARAMETERS NAME DESCRIPTION POSSIBLE DEFAULT READ/ VALUES VALUE WRITE measinterval Measuring and sending 60*–999999 1800 interval LoRa [s] channel Relay channel number 1 - 14 outputmode Output type normally no, nc...
Page 16: Downlink Message
YO Relay Switch User guide v1.1 page 16/26 Downlink message It is possible to change the measurement interval (measinterval) by using downlink. Information about changing parameter will be sent from server via gateway when Example of downlink message must include: ●...
Page 17 YO Relay Switch User guide v1.1 page 17/26 UPLINK SUBBAND REGION DESCRIPTION POSSIBLE DEFAULT READ/ VALUES VALUE WRITE EU868 Sub-band 1; 867.1 - 868.5 MHz; channels 0-7 Sub-band 1; 902.3 - 903.7 MHz; channels 0-7 Sub-band 2; 903.9 - 905.3 MHz; channels 8-15 Sub-band 3;...
Page 18: Configuration Node Via Yosensi Management Platform
6. There are two options to conﬁgure the device. First recommended is “form based editor”, second is “text editor”. Below is a guide to conﬁguration of the YO Relay Switch device. Figure 13 Conﬁguration with setting Channel 1 as NC and Channel 2 as NO using form based editor.
Page 19: Configuration Node With Yosensi Mobile App
19/26 Conﬁguration node with Yosensi mobile app Connect to the device using Yosensi app as follows: 1. Login to Yosensi App using your credentials. 2. Go to the Devices section and choose the device you want to conﬁgure. If you can not see the device ensure that you are in the correct organization.
Page 20: Connecting Node With Network
IoT systems management (like the root directory in operating systems). It can be created only by Yosensi staff, and all clients using Yosensi Management Platform have one created for them by default. In case of any questions, you can ﬁnd us at support@yosensi.io.
Page 21 4. Proceed to the application by clicking its name on the list, then press the ‘≡’ button to add a node. Click ‘Add manually’ . Set the node’s ‘Name’ and ‘Description’ ﬁelds, and ﬁll in ‘DEV EUI’ and ‘OTAA Key’ (otaa section – appkey). All device identiﬁers are provided by Yosensi Support when you order the nodes.
Page 22 5. New nodes must be added in OTAA mode. Nodes can be switched to ABP mode after activation in the Yosensi Management Platform by changing the Node conﬁguration. Click on the link in the ‘Node Name’ column. Go to the ‘KEYS’ tab and switch ‘LoRa Type’ from OTAA to ABP and ﬁll in the blank spaces, then press update.
Page 23: Adding Node Via Bluetooth
Extended documentation of the protocol can be found in the Payload description on our website. An example payload produced by YO Relay Switch is presented below with divisions for each measurement and marked with decoded values, whose interpretation is described in the Payload description.
Page 24 [s] = 0 addr = 255 prec = 0 meas_len = 2 CH1: NC, CH2: NO Example of YO Relay Switch ACK uplink after receiving downlink command: 02:0a:00:00:04:00:10:00:01:04:00:11:ff:00:03 Payload header First measurement (Channel “addr” Relay actual state ) 0x02...
Page 25: Compliance Statements
YO Relay Switch User guide v1.1 page 25/26 Compliance statements www.yosensi.io...
Page 26 YO Relay Switch User guide v1.1 page 26/26 www.yosensi.io...

This manual is also suitable for:

Lnrs
