Diving Phone Case
Instruction Manual
Before installing the phone and using the waterproof
case for diving, please conduct a waterproof test.
Please read this manual carefully before use.
Please keep this manual properly for future reference.
Youcan Robotics(Shanghai) Co.,Ltd.
（ YC-WP-01 ）
（ YC-WP-02 ）
Advertisement
Summary of Contents for Youcan Robot YC-WP-01
- Page 1 Diving Phone Case Instruction Manual Before installing the phone and using the waterproof case for diving, please conduct a waterproof test. （ YC-WP-01 ） （ YC-WP-02 ） Please read this manual carefully before use. Please keep this manual properly for future reference.
- Page 2 Attention 1. Please use the product correctly on the basis of fully understanding the instructions. Our company is not responsible for any property losses caused by incorrect operation. 2. Before using the waterproof case to submerge your phone in water, please conduct a waterproof test first ( method: put a piece of dry tissue paper inside the waterproof case and then immerse it in 0.66ft water for 10- 20 minutes, take it out,wipe off the water and check the tissue paper ).
-
Page 3: Product Specifications
Product Specifications Product model: YC-WP-01 Waterproof depth: 40m (130 ft) Waterproof structure: press-mounted O-ring seal Battery: 3V AAA(No.7) Battery *2 (purchase separately) Main material: PC/optical glass/stainless steel/silicone rubber Applicable temperature: 0°C ~ 40°C Product size: 8.35*2.36*4.4inch Product weight: about 1.28lb Support system: iOS13.0.0 and above... - Page 4 Product Instruction (YC-WP-01) Maximum ( internal available) size of waterproof case inside: 6.89*3.35*0.31inch Left Right Lens window Down Protection pad Cold shoe connector Confirm button Power switch Power indicator light Bluetooth indicator light Battery door Safety lock Waterproof ring Window...
- Page 5 Product Instruction (YC-WP-02) M67 red filter (Need to purchase separately) Cold shoe connector Left Right M67 connector Down Adapter framework Confirm button M67 Wide-angle lens Safety lock (Purchase separately) Interface for vacuuming 1/4 interface Bluetooth indicator light Waterproof ring Lens window Power indicator light Magnet Bluetooth switch...
- Page 6 Mobile Phone Mouse Mode Settings 【 Apple system 】 A. Turn on the "Assistive Touch" feature of the phone. Method: Open "Settings" → "Accessibility" → "Touch" → "Assistive Touch" and turn it on. B. Set the "Hover Control" mode for the mouse. Off state: Confirmation requires a press of the shutter button.
- Page 7 Bluetooth switch on the phone, and then pair again. 3. Mobile Installation 【 YC-WP-01 】 a. Adjust the mobile phone lens to align with the waterproof case lens window, and it is recommended to place the phone tightly on the left side of the waterproof case;...
- Page 8 【 YC-WP-02 】 a. Stick the magnetic sheet to the appropriate position of the phone; b. Install the adapter frame according to the phone model; c. Carefully place the phone into the waterproof case and close and lock it. Adapter frame Magnet 4.
-
Page 9: Operating Method
Operating Method 1. Turn on the default camera app on your mobile phone. 2. Use the waterproof case (up, down, left, right, confirm) buttons to control the mouse direction, and use the confirm button to control the mobile phone to take photos, shoot videos, and other functions. Use button to control mouse direction Confirm 3. - Page 10 Maintenance and Care 1. Before using the waterproof case, check the waterproof ring and surrounding grooves, and remove any debris (such as salt, sand, or hair). 2. After each use of the waterproof case, soak the case in fresh water for 15-30 minutes.
- Page 11 Contact Us Youcan Robotics(Shanghai) Co.,Ltd. Customer Service: service@youcanrobot.com Telephone: +86 21-20936568...
- Page 12 Diving Phone Case Instruction Manual...
