- Page 1 Fixing Instructions Modus Electric Horizontal Radiator Please unpack your delivery carefully and inspect the radiator and contents – any damages or shortages must be notified to your supplier within 3 days of delivery of your goods.
-
Page 2: Specifications
Specifications Technical Information WIDTH = radiator + element Standard connections: ½” Technical Specifications Materials: Steel Connections: ½” Flow and Return Test pressure: 13 Bar Testing authority: EN442 Max operation pressure: 10 Bar Max working temperature: 110c These can be cleaned using a soft damp cloth with a non-abrasive 46mm cleaning product. - Page 3 Content list Review instructions carefully before installation. Installation should be completed by a suitably qualified person. Please dispose of packaging in a responsible manner. Inside your accessories box you will have: 4-20 Sections 2 x Wall Brackets 21-40 Sections 3 x Wall Brackets...
-
Page 4: Installation Instructions
Installation Instructions . . : � -: . . : � -: . . : � -: . . : � -: . . : � -: . . : � -: � - : �. :�-- - � - : �. . - Page 5 Installation Instructions 4 x BH 4x CVD 6 x BH 6 x CVD 8x BH 8 x CVD...
- Page 6 Manual & Installation Instructions Heater Controller H+h & Temperature Sensor...
- Page 7 Content list Heater Controller – Horizontal Temperature Sensor / Remote Controller Kit Content Side Connection ATTENTION: Ensure the WiFi signal is present where the heater will be located...
- Page 8 Safety 1. The heater should be installed by a qualified person. 2. Bathroom radiators fitted with electric heaters should be fixed not less than 60 cm from a bath, shower or wash basin, and never above abath. 3. For the heater permanently connected (hard wire) there must be applied a cut-off device from the mains. Such a device must disconnect the heater from the supply mains in 2 poles, with contact separation of at least 3 mm.
- Page 9 Installation Instructions CAUTION! Do not disconnect The locking screw must be protected against heater controller when the accidental unscrewing eg. by applying a system is powered. drop of lacquer or acrylic adhesive. Mounting in radiators Central heating system Electric radiators The order of assembly of elements...
- Page 10 Installation Instructions Electric radiators Central heating system...
- Page 11 User Instructions How to use heater controller (optional remote controller) Heater controller Remote controller...
- Page 12 User Instructions Heater controller and remote controller pairing If you bought a remote controller together with H +heater you do not need to pair it! For H+h WiFi controller please download smartphone application from www.supla.org and follow the instruction.
- Page 13 User Instructions TURBO mode acivation Settings water or ambient temperature USER MANUAL: ERRORS Errors ATTENTION: Signalling improper installation or improper use: Lack of water (or wrong choice of heat- Lack of water (or wrong choice of heating element to the heater) ing element to the heater) Damaged heating element Damaged heating element (or no power circuit)
-
Page 14: Wifi Configuration
WiFi Configuration USER MANUAL: WiFi configuration Heater controller Heater controller When the heater is connected to Heater controller display Heater controller display the mains properly, the red light will flash on the controller display When the heater is connected to the mains properly, the red light will flash on the controller display. -
Page 15: Terms And Conditions
Terms and Conditions You must immediately remove all packaging, inspect the goods and notify us of any damage to the goods within 3 days of delivery. We shall have no obligation to replace or repair damaged goods in the event of failure by the Buyer to comply with this provision.
