Summary of Contents for BANLAW ResTrack Lite BRTLC01A-1
- Page 1 Banlaw ResTrack Lite Quick Start Guide Banlaw ResTrack Lite Controller BRTLC01A-1, BRTLC01A-2, BRTLC01A-3 & BRTLC01A-4...
- Page 2 Banlaw ResTrack Lite Quick Start Guide Introduction Thank you for purchasing Banlaw ResTrack Lite Controller. This Quick Start Guide is designed to guide you through installation and commissioning of your ResTrack Lite Controller. Before proceeding with the physical installation of your ResTrack Lite hardware, from a computer create or login to an account at https://restracklite.banlaw.com...
-
Page 3: Quick Start Tips
Flow meter K-Factor into the ResTrack Lite web application. The K-Factor value is typically provided within the flow meter packaging. Quick Link to Product Data Sheets https://www.banlaw.com/fuel-management-systems/lite-controller/downloads/ Banlaw Supplied Flow Meter K-Factor Values Banlaw Hall Effect Hall Effect Part Number... - Page 4 Banlaw ResTrack Lite Quick Start Guide ResTrack Lite System Overview The ResTrack Lite system comprises three key elements: the ResTrack Lite Web App, Mobile App and the Controller. These elements are closely integrated, with data transferring between them to ensure seamless management and tracking of fuel dispensing transactions.
- Page 5 • The user is prompted to identify the vehicle. Methods of identification can be configured in the web application per vehicle, which can include: o Banlaw SecureFill™ Auto-ID system. o Scanning a Vehicle QR code. o Manual selection. o Or any combination of the above.
-
Page 6: Package Contents
Banlaw ResTrack Lite Quick Start Guide Package Contents BRTLC01A BRTLPS**A Banlaw ResTrack Lite Controller Controller Power Supply (Qty. 1) (Qty. 1) (Only available in BRTLC01A-2, -3 & -4) Banlaw PN: 001993 BRTLC016 Field Wirable L Coded Connector Sticker, Vehicle QR (Qty. -
Page 7: Controller Overview
Banlaw ResTrack Lite Quick Start Guide Controller Overview Indicators Controller Identification Connection Ports Controller Identification The ResTrack Lite Controller can be identified and traced using its unique serial number and QR code located on the left-hand side of the controller as indicated in the figure below:... - Page 8 SecureFill Auto-ID Banlaw SecureFill Auto-ID Gateway can be added in to enable a higher level of security that is compatible with Banlaw Auto-ID products. Power Input The Power Input accepts an M12 L-coded connector and receives 12–24 VDC at up to 4 A.
- Page 9 Banlaw ResTrack Lite Quick Start Guide Controller Indicator Function & Status Indicator Description Types of indication CONSTANT- Power is present and stable. Power Indicates the presence of power to FLICKERING – Unstable power. (GREEN LED) the controller. OFF- Power is not present.
-
Page 10: Controller Specifications
Banlaw ResTrack Lite Quick Start Guide Controller Specifications BRTLC01A – ResTrack Lite Controller Communication Interface Bluetooth 5.2 Input Power 12 - 24 VDC Idle Power Consumption 40mA at 12VDC / 20mA at 24VDC Internal Fuse Enclosure Material ABS Thermoplastic Enclosure... -
Page 11: Hardware Installation
Hardware Installation Pre-Installation Checklist Check Check List ☐ Ensure the controller has been registered in the webapp. • Ensure Banlaw ResTrack Lite mobile app has been downloaded and • ☐ logged in. ☐ Turn off all power to pump and tank. -
Page 12: Controller Mounting Dimensions
Banlaw ResTrack Lite Quick Start Guide Controller Mounting Dimensions (All dimensions in mm unless noted otherwise) Recommended Fasteners M6 or 3/16” Countersunk Screw + M6 or 3/16” Nyloc Nuts (Qty. 4) The figure above illustrates the overall dimensions of the controller, including the •... -
Page 13: System Example
“Type I” power supply shown above. • System Example The figure below provides an illustration of a dual-nozzle system integrated with the ResTrack Lite controller, utilizing Banlaw's Splash Fill and Dry-Break technologies. BRTSFL101 SecureFill Auto-ID Gateway BRTLC01A ResTrack Lite Controller... - Page 14 To disconnected, ROTATE the connector’s rotating collar “Anti- • clockwise”. It is recommended to use Banlaw products to ensure compatibility. • • If using an existing component, ensure it is compatible with ResTrack Lite and the connectors have been terminated as indicated in the Product Data Sheet.
-
Page 15: System Commissioning Guide
(NOTE: It will be non-audible in a noisy environment.) • Flow valve/s in the CLOSED position. 10. Using the Banlaw ResTrack Lite mobile application, start a dispensing event to a ResTrack Lite registered vehicle and observe the following: The intended nozzle is enabled (1 or 2) and its respective LED turns Yellow. -
Page 16: Commissioning Checklist
Banlaw ResTrack Lite Quick Start Guide Commissioning Checklist Check Check List Confirm all electrical connections are connected to their appropriate • ☐ locations and terminated correctly. ☐ Confirm that the Controller turns on and cycles through all 5 LEDs. •... - Page 17 Banlaw ResTrack Lite Quick Start Guide How many controllers do I need? • A. ResTrack Lite supports one tank or fluid type per controller. How many level sensors do I need? • A. Only one level sensor per controller, per tank.
