Hoelzle EH490L Instruction Manual

Battery powered crimping tool
Hide thumbs
1
2
3
4
5
6
7
8
9

Advertisement

Table of Contents

Instruction Manual
Battery Powered Crimping Tool EH490L
Due to continuing improvements, actual product may differ
slightly from the product described herein.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL
SAVE THIS MANUAL
Keep this manual for the safety warnings and precautions, assembly, operating, inspection,
maintenance and cleaning procedures. Write the month and year of purchase. Keep this
manual and the receipt in a safe and dry place for future reference.
IMPORTANT SAFETY INFORMATION
In this manual, on the labeling, and all other information
provided with this product:
This is the safety alert symbol. It is used to alert you to potential
personal injury hazards. Obey all safety messages that follow this
symbol to avoid possible injury or death.
DANGER indicates a hazardous situation which,
if not avoided, will result in death or serious injury.
WARNING indicates a hazardous situation which,
if not avoided, could result in death or serious injury.
CAUTION, used with the safety alert symbol,
indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EH490L and is the answer not in the manual?

Questions and answers

Summary of Contents for Hoelzle EH490L

  • Page 1 SAVE THIS MANUAL Instruction Manual Battery Powered Crimping Tool EH490L Keep this manual for the safety warnings and precautions, assembly, operating, inspection, maintenance and cleaning procedures. Write the month and year of purchase. Keep this manual and the receipt in a safe and dry place for future reference.

  • Page 2: Work Area Safety

    Please cut off the power of the charger each time to reduce the hazard from child GENERAL SAFETY RULES or the person who not expert on the tool. Do not wait until the battery runs over for recharging, the recharging will caused TO WORK IN SAFE CONDITIONS WITH THIS TOOLING, IT IS IMPERATIVE TO the battery does not working anymore.

  • Page 3: Specific Safety Rules

    4. Service UNDERSTAND YOUR TOOL Have your Battery Powered Crimping Tool serviced by a qualified service technician PEH490L is a tool for crimping Cu/Al lugs with cable from 10-240mm² . It is powered using only identical replacement parts. This will ensure that the safety of the Battery by Li-ion, actuated by motor and controlled by MCU, with OLED display and a high Powered Tool Kit is maintained.

  • Page 4: Description Of Components

    2. Description of components: 3. Function description Micro computer control system-automatically detects the pressure when in working with double safety protect. OLED display - Dot matrix OLED display, which shows working times, battery power, working pressure (if equipped with pressure sensor), maintenance reminding and fault code.
  • Page 5 Table 1 Signal Instruction and Meaning: OPERATING INSTRUCTION Series Instruction OLED screen What it means Read the entire SAFETY INFORMATION section at the beginning of this manual Self-checking to assure everything is Self-checking including all text under subheadings therein before using this product. Use this tool for the manufacture’s intended purpose only.
  • Page 6 CHARGER) 2. Usage of the tool 2.1 OLED display interface description: When use the factory original battery, must charge by the original charger.4.0Ah/5.0Ah battery charging current shouldn’t exceed 5A.2.0Ah battery charging current shouldn’t exceed 3.0Ah.The battery will be smoking, burnt, even explode if charge with a non-compliant charger.

  • Page 7: Operation

    2.2 Operation 1) Do not hammer or knock any part of the tool. Before operation, check the tool for any damage, aging, missing parts, misalignment or component jamming and any other unfavorable factors that endanger safety and normal operation. It works effectively without any jams.

  • Page 8: Maintenance And Servicing

    TROUBLESHOOTING MAINTENANCE AND SERVICING FAULT ANALYSIS SOLUTION Dirt, contaminants, etc in ram area of Clean hydraulic system A. Tool tool. Charge the battery Damaged equipment may cause serious personal injury. Do not use damaged is inoperative The battery run out Return tool to manufacture or equipment.
  • Page 9 LIMITED 2 YEARS WARRANTY We make every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of two years from the date of shipment (90 days if used by a professional contractor or if used as rental equipment).
