Assembly Instructions
BKT-CCPL
Codec Plus mount
Thank you for purchasing AVFI's BKT-CCPL Bracket.
This product is designed to have many mounting options.
Confirm all hardware is included before you begin assembly.
Read these instructions start to finish before beginning installation.
Note: If you cannot understand these instructions or are concerned about safety
of the installation contact a qualified contractor or contact AVFI at 1-866-405-0655.
Supplied Parts
Slide Codec onto bracket to check fit and
1
orientation (mounting direction)
Key on back of codec should be point
upwards or sideways in mounted position.
www.video-furn.com
BKT-CCPL
Supplied Hardware (Installed on bracket)
M8 Nut
M8-20mm Bolt
(4)
(4)
190 Don Hillock Drive |Aurora |Ontario|L4G 0G9 | 1.866.405.0655
V
F
I
1
Advertisement
Summary of Contents for AVFI BKT-CCPL
- Page 1 Read these instructions start to finish before beginning installation. Note: If you cannot understand these instructions or are concerned about safety of the installation contact a qualified contractor or contact AVFI at 1-866-405-0655. Supplied Hardware (Installed on bracket) Supplied Parts...
- Page 2 Assembly Instructions BKT-CCPL Codec Plus bracket Choose from many mounting methods. ( Some hardware not included) Furniture Wall mount. Attach to wall using 4 wood screws. (screws not included) Cart/Stand mount. 8mm Machine screws w nuts x4. Attach to front or rear of Rolling stand.
