MAS DIY PEDAL TOWER Assembly & Usage Manual

Hide thumbs

Advertisement

Table of Contents

DIY
PEDAL
Assembly & Usage
masfx.info/tower

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DIY PEDAL TOWER and is the answer not in the manual?

Questions and answers

Summary of Contents for MAS DIY PEDAL TOWER

  • Page 1 PEDAL Assembly & Usage masfx.info/tower...
  • Page 2 ASSEMBLY: Face Plate M3x6mm screw Quick Overview Solder the necessary components to 12mm female-female spacer each circuit board. Controls PCB Short Header Assemble from the bottom-up. You could also do it top-down. Refer to the next page to determine which spacers and hardware to use 12mm male-female spacer for connecting each layer.

  • Page 3: Parts Identification

    PARTS IDENTIFICATION POLY FUSE Begins with “F”, e.g. “F401” To keep this kit reasonably priced, we’re not individually wrapping DIP-8 PACKAGE and labeling each and every part. Instead we’ve grouped them into bundles where they’ll be easily Begin with “U”, e.g. “U301.” Either a dot or a half-circle shape will be distinguished from one another as long as you recognize each general present to indicate orientation type of part.

  • Page 4: Back Plate

    Don’t hesitate to reach out, directly or on the forum, with any questions, problems, or feedback. Thanks! 5mm female-female spacer Back Plate Mark A. Stratman M3x10mm screw mark@mas-effects.com...

  • Page 5: Power Switch

    JACK PCB POWER SWITCH ASSEMBLY Push the plastic cap onto the power switch Install and solder the switch onto the SW201 footprint. The switch’s cap will overhang the edge of the board slightly. Use the blue putty if necessary to hold it in place while you solder.

  • Page 6: Battery (Not Included)

    JACK PCB the top of the battery to reduce the chance of shorting CONTINUED solder points on the board above it. This risk can also be mitigated by closely trimming any leads on the board above it. BATTERY SNAP CONNECTOR TIP: Even if you don’t plan to use the battery, it’s useful for adding weight Trim the battery snap connector’s wires to to the bottom of your stack, and stabilizing the platform.
  • Page 7 CONNECTORS ASSEMBLY (optional add-on) BLANK CUSTOM LAYERS FOR MIDDLE LAYERS Follow these guidelines for all middle layers, such as the blank custom layer, amplifier/speaker, and tone and sample player: 12mm male-female spacer Middle PCBs Tall Header Install the tall header into the “BOARD CONNECTORS” spot on the bottom of the board, indicated with a rectangle.
  • Page 8 JFET Q301 ASSEMBLY (optional add-on) AMPLIFIER This is likely a surface mount device (SMD) and pre- & SPEAKER soldered, but if not, line up your transistor’s curved and straight sides with the printing on the PCB and solder See “CONNECTORS FOR MIDDLE LAYERS” on page 13 for how to into place.
  • Page 9 BUTTONS & POWER SWITCH ASSEMBLY (optional add-on) SAMPLE As usual, use putty if necessary to hold the buttons, & TONE PLAYER SW402 and SW403, and the power switch, SW404, in place while soldering. See “CONNECTORS FOR MIDDLE LAYERS” on page 13 for how to connect and stack this layer.

  • Page 10: Volume Knob

    ASSEMBLY on the bottom of the control board and solder the pins on top. CONTROLS & FACE PLATE 12mm female-female spacer Controls PCB Short Header Align the corner mounting holes with the standoffs on the lower layer. Gently and carefully seat and press the header over the pins on the lower layer.
  • Page 11 WALKTHROUGH PORTS Plug male breadboard pin connectors into these to interface the tower with your projects. The other end of the wire can be another male pin, a female socket, an alligator clip, or more. DC POWER JACK INPUT and OUTPUT JACKS (in back) (in back) POWER...
  • Page 12 USAGE: INPUT / OUTPUT CONDITIONAL INPUT / OUTPUT Dry input and wet output signals will go to jack if a cable is plugged in. INPUT OUTPUT When unplugged, the signal will be routed to the ALT OUT JACK JACK e.g. amp/speaker “ALT IN”...

  • Page 13: External Power

    POWERING AUDIO PROBE USING THE YOUR CIRCUIT EXTERNAL POWER If you hook your breadboard or pedal guts or other circuit up to the FX IN and FX OUT ports but can’t hear Sometimes you may want to use power from an any sound coming through, never fear, the audio probe is alternate source outside of the tower, e.g.
  • Page 14 For example, the ability to record your own sample is something that You can use the blank layer PCBs MAS Effects sells, or design your was left out of the main feature set in order to keep costs down, but own PCB.
