- Page 1 Translation of copy in original language IMPORTANT: MUST BE READ 83103600 rev. 1.0 14/12/2022 Installation, use and maintenance manual Installation, use and maintenance manual WOOD BURNING STOVES WOOD BURNING STOVES ---- ----...
-
Page 2: Table Of Contents
Installation, use and maintenance manual ---- - WOOD BURNING STOVES 1 PRODUCT SAFETY 2 HANDLING AND UNPACKING 3 MINIMUM INSTALLATION REQUIREMENTS 4 INSTALLATION 4.1 FLUE PIPE 4.2 CHIMNEY COWL 4.3 DRAW 4.4 STOVE EFFICIENCY 4.5 AIRTIGHT STOVE ONLY 4.6 INSTALLATION PLACE 4.7 CONNECTION TO THE FLUE PIPE 5 PRODUCT DESCRIPTION 5.1 TECHNICAL DATA... -
Page 3: Product Safety
On a sample basis, some products are subjected to internal testing before shipment and, as such, these may contain residues. Eva Stampaggi aims to provide as much information as possible to ensure safer use and to avoid damage to persons, property or parts of the stove itself. -
Page 4: Safety Warnings
● Read the manual carefully: ● Eva Stampaggi S.r.l. assumes no responsibility for damage to persons and/or property or for the malfunction of the stove resulting from non-compliance with the provisions of this Instruction Manual ● The guarantee will remain valid for 1 year for professional operators and 2 years for consumers ●... - Page 5 Installation, use and maintenance manual ---- - WOOD BURNING STOVES ● The combustion chamber must be kept closed, except when loading or removing residues, in order to prevent smoke egress. ● Do not use the appliance as waste incinerator or for any other purpose other than the intended one. ●...
-
Page 6: Handling And Unpacking
INSTALLATION WITH WALL FUME OUTLET IS PROHIBITED. INSTEAD THE FUME OUTLET MUST BE ROOF- TYPE AS PROVIDED FOR BY NATIONAL REGULATIONS. Eva Stampaggi S.r.l. assumes no responsibility for damage to persons and/or property caused by non-compliance with the point highlighted above for products installed in a non-compliant manner. - Page 7 The Buyer must request and retain the certification of compliance of the installation, and the connection of the stove, with the provisions of law. In the absence of such certification Eva Stampaggi S.r.l. assumes no criminal and/or civil liability, direct and/or indirect for the malfunction of the stove and for damage caused to persons or property, resulting from the use of the product.
-
Page 8: Installation
Installation, use and maintenance manual ---- - WOOD BURNING STOVES INSTALLATION INSTALLATION FLUE PIPE FLUE PIPE THE PRODUCTION OF STOVES WITH HIGHER PERFORMANCE IS INCREASINGLY REQUIRED SO IT IS BECOMES ESSENTIAL TO ENSURE THAT INSTALLATIONS COMPLY WITH THE LAW. IF THE VENT PIPE PASSES THROUGH NON-HEATED ENVIRONMENTS, IT MUST BE INSULATED FOR CORRECT COMBUSTION. -
Page 9: Chimney Cowl
Installation, use and maintenance manual ---- - WOOD BURNING STOVES CHIMNEY COWL CHIMNEY COWL A properly installed chimney cowl ensures optimum stove functioning. The anti-downdraught chimney cowl consists of a number of components whose outlet section sum always doubles the flue pipe section. Make sure the chimney cowl is at least 150cm above the roof rise so that it is fully exposed to the wind. -
Page 10: Draw
Installation, use and maintenance manual ---- - WOOD BURNING STOVES DRAW DRAW Fumes heat up during combustion, increasing their volume. Their density is therefore lower than the one of the surrounding colder air. This difference between the inside and outside temperatures of the chimney results in a negative pressure which increases proportionally to the vent pipe length and the temperature. -
Page 11: Airtight Stove Only
Installation, use and maintenance manual ---- - WOOD BURNING STOVES ATTENTION ATTENTION Read the manual carefully: Before installing, the following indications must be met: Select the position where the stove is to be installed and: ● Arrange the connection to the vent pipe for fume extraction. ●... -
Page 12: Installation Place
Installation, use and maintenance manual ---- - WOOD BURNING STOVES INSTALLATION PLACE INSTALLATION PLACE ATTENTION ATTENTION Read the manual carefully: ● When the stove is on, it can create a depression in the room where it is installed, therefore there must not be any open flame apparatus in the same room, with the exception of type C boilers (airtight). -
Page 13: Connection To The Flue Pipe
Installation, use and maintenance manual ---- - WOOD BURNING STOVES CONNECTION TO THE FLUE PIPE CONNECTION TO THE FLUE PIPE THE LENGTH OF THE FUME DUCT PIPE MUST HAVE A DIAMETER EQUAL TO OR GREATER THAN THAT THE LENGTH OF THE FUME DUCT PIPE MUST HAVE A DIAMETER EQUAL TO OR GREATER THAN THAT SPECIFIED FOR EACH APPLIANCE. -
Page 14: Product Description
Installation, use and maintenance manual ---- - WOOD BURNING STOVES PRODUCT DESCRIPTION PRODUCT DESCRIPTION TECHNICAL DATA TECHNICAL DATA EVSL8 EVSL105S EVSL5 EVSL6 Fume discharge (mm) Heatable room size (m3) 140 - 200 180 - 270 40 - 100 70 - 160... -
Page 15: Product Use
Installation, use and maintenance manual ---- - WOOD BURNING STOVES PRODUCT USE PRODUCT USE POWER ON POWER ON The first ignition after installation must be performed with very little wood. This is used to understand if the installation has been performed correctly and there is no loss of smoke and for settling of the product structure. To light the stove, small (dry) logs and possibly ecological fire-lighters are required. -
Page 16: Combustion
If the wood is damp or the flue does not have much draft, it is advisable to leave the door ajar. The moment you close it and the fire tends to go out, reopen the door and favor the complete ignition of the initial charge. COMBUSTION COMBUSTION To obtain the best combustion, follow the parameters below: EVSL8 EVSL105S EVSL5 EVSL6 Amount of wood (kg/h) - Page 17 Don't smother the fire by closing the air vents. ● Do not leave the primary air adjustment device open (in the EVSL8 and EVSL105S stoves) during normal Do not leave the primary air adjustment device open (in the EVSL8 and EVSL105S stoves) during normal...
-
Page 18: Cleaning And Maintenance
ATTENTION ATTENTION Eva Stampaggi S.r.l. assumes no criminal and/or civil liability, direct and/or indirect for the malfunction of the stove and for damage to persons or property caused by the failure/incorrect cleaning and routine maintenance of the stove. ATTENTION ATTENTION Perform cleaning with the stove completely cold. - Page 19 ATTENTION ATTENTION Eva Stampaggi S.r.l. assumes no criminal and/or civil liability, direct and/or indirect for the malfunction and those resulting from people or things caused by the failure/incorrect extraordinary maintenance of the stove. It is not uncommon, at the first cold spell and with wind for fires to ignite in the chimney due to the residue build up; some advice in the unfortunate event of this happening is: ●...
-
Page 20: Yearly Scheduled Maintenance
Installation, use and maintenance manual ---- - WOOD BURNING STOVES YEARLY SCHEDULED MAINTENANCE YEARLY SCHEDULED MAINTENANCE Date 1st maintenance (Technical Assistance Centre stamp) Date 2nd maintenance (Technical Assistance Centre stamp) Date 3rd maintenance (Technical Assistance Centre stamp) 83103600 - 1.0 - 14/12/2022... -
Page 21: Installation And Test Certificate
Installation, use and maintenance manual ---- - WOOD BURNING STOVES INSTALLATION AND TEST CERTIFICATE INSTALLATION AND TEST CERTIFICATE CERTIFICATE OF INSTALLATION AND TESTING CUSTOMER STREET/ROAD: CITY: POSTAL CODE: PROVINCE TEL: Delivery date: Delivery document: Equipment mod.: Serial number: Year: DEALER and INSTALLER DATA First name: Last Name: Address:... -
Page 22: 10 Warranty
EN 303-5:2012 (pellet boilers) Eva Stampaggi S.r.l. guarantees that the stove is free from defects that make it unsuitable for its intended use or significantly reduce its value. The rules of the Italian Civil Code or applicable national law governing the guarantee in the sales contract, or applicable national law ex D. - Page 23 A FIRST IGNITION OF ITS PRODUCTS WITH A QUALIFIED TECHNICIAN. EVA STAMPAGGI HAS NO LIABILITY OF ONLINE SALES AND RELATED OFFERS, BECAUSE IT DOES NOT EVA STAMPAGGI HAS NO LIABILITY OF ONLINE SALES AND RELATED OFFERS, BECAUSE IT DOES NOT MAKE DIRECT SALES TO THE GENERAL PUBLIC.
- Page 24 EVA STAMPAGGI SRL reserves the right to make technical changes to this manual without notice. The data and features indicated are in no way binding to Eva Stampaggi S.r.l. The company reserves the right to make any changes necessary without prior notice or replacement.
