Lumascape LS353LED Installation Instructions

Lumascape Lighting Industries Pty Ltd
38-44 Enterprise Street, Cleveland, QLD 4163, Australia
PO Box 1875, Cleveland D.C., QLD 4163, Australia
T 07 3286 2299
F 07 3286 6599
E sales@lumascape.com.au
W www.lumascape.com.au
LS353LED
Shallow Inground with MicroAntileach™ cable
Warranty void if not installed as per installation instructions
DANGER
ISOLATE LUMINAIRE FROM POWER
Failure to isolate power
supply before installation or
maintenance may result in
fire, serious injury, electric
shock, death and may
damage the luminaire.
Connect luminaire to suitable power
1.
supply.
Power supply must be isolated prior to
connection or disconnection of cables.
Failure to do so will result in damage to
the luminaire components.
4.
Check gasket beading
faces down into cavity
www.lumascape.com.au
Finished floor level
2.
Flushed floor/ground level
Fit stainless steel lid. Tighten screws.
5.
Copyright ©2013 Lumascape Lighting Industries Pty. Ltd. ABN 21 010 572 773
INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS
1x 1x
FOR OUTDOOR USE
10x
1x
Discard plastic lid and black O-ring.
3.
Discard aluminium lid.
RETAIN GASKET.
6.
15°
A.C.N. 0105 72 773
1x
IN0032 - 16 Oct 2013
