  • Page 1 4-173-749-14 (1) Solid-State Memory Camcorder Supplement PMW-350K PMW-350L © 2009 Sony Corporation...

  • Page 2: Table Of Contents

    Table of Contents Foreword ...................... 3 Using an External Hard Disk..............3 Attaching/Removing the PHU-220R ..........3 Formatting the PHU-220R ..............4 Restoring the PHU-220R ..............5 Using a Media Adaptor ................5 XQD Memory Cards ................. 5 “Memory Stick” media/SDHC Cards ..........6 Operating via the REMOTE Connector............

  • Page 3: Foreword

    Foreword Using an External Hard Disk This document contains the following You can use an optional PHU-220R Professional supplementary information about the PMW- Hard Disk Unit with this camcorder. 350K/350L (called “the camcorder” below). Notes • Using a External Hard Disk •...

  • Page 4: Formatting The Phu-220R

    Fit the bottom plate (spring type) into The POWER indicator of the PHU-220R lights in green. the auxiliary shoe. Subsequently, the ACCESS lamp of the Slits for screw holes camcorder lights in orange then changes to green once the unit is ready for use. Bottom plate Notes •...

  • Page 5: Restoring The Phu-220R

    To restore the hard disk • Not all XQD memory cards are guaranteed to work with this camcorder. For compatible memory cards, Turn the MENU knob to select “Execute”, and contact your Sony dealer. then press the knob. The restoration begins automatically. Formatting...

  • Page 6: Memory Stick" Media/Sdhc Cards

    1) For details on the specified USB card reader, visit the card with this camcorder, formatting is required. Sony Professional Products web site. A “Memory Stick” or an SDHC card to be used with this camcorder must be formatted using the format function of this camcorder.

  • Page 7: Operating Via The Remote Connector

    Sony Unit, the RCP-1001/1501 Remote Control Panel, Corporation. or other control unit is connected, some • “XQD” is a registered trademark of Sony Corporation. camcorder functions can be controlled from these units. You can use the RM-B750’s display or a video...
  • Page 8 Relationship between the setting of the RM Rec • Buttons and switches to which the Turbo Gain Start item and the function of recording start/stop function has been assigned, including the buttons ASSIGN. 1/3 switches, the ASSIGNABLE 4 switch, the COLOR TEMP. button, and the Recording start/ Settings of RM Rec Start ASSIGNABLE 5 switch.

  • Page 9: Operating The Menu From The Rm-B150/B170

    settings of the paint data made with the remote Setup menu of control unit can be retained even if the remote the camcorder control unit is removed. However, if the switch position on the remote control unit differs from the one on the camcorder, the switch position on Main data block Remote control data block...

  • Page 10: Functions That Can Be Controlled From The Rm-B150/B170/B750

    Functions That Can Be Controlled from the RM-B150/ B170/B750 You can adjust the functions in the following table by using menu operations, adjustment knobs, switches, and the touch panel (RM-B750 only) on the RM-B150/B170/B750. For details on operations, refer to the operation manual of the RM-B150/B170/B750. How to Read the Table In the RM-B150, RM-B170, and RM-B750 columns of the table below, “Yes”...
  • Page 11 Menu Sub-item Setting Description RM-B150 RM-B170 RM-B750 items Iris Iris Mode Auto/Manual Selects the iris mode. Iris Speed –99 to ±0 to +99 Specifies the control speed (speed of reaction to changes in the video). (Larger values specify quicker reaction times.) Iris Level –99 to ±0 to +99 Adjusts the level of the auto iris target value.
  • Page 12 Menu Sub-item Setting Description RM-B150 RM-B170 RM-B750 items Media Start/Stop Starts or stops recording. Play Play/Pause Starts playback. FREV – Starts high-speed reverse playback. FFWD – Starts high-speed playback. Stop – Stops playback. Rec Review – Starts a recording review. PREV –...
  • Page 13 Menu Sub-item Setting Description RM-B150 RM-B170 RM-B750 items Black Master Black –99 to ±0 to +99 Specifies the master black level. R Black –99 to ±0 to +99 Specifies the R black level. B Black –99 to ±0 to +99 Specifies the B black level.
  • Page 14 Menu Sub-item Setting Description RM-B150 RM-B170 RM-B750 items Knee Knee On/Off Turns knee correction on or off. Knee Point 50% to 95.0% to Specifies the knee point. 109% (in steps of Knee Slope –99 to ±0 to +99 Specifies the knee slope. Knee Saturation On/Off Turns the knee saturation function on or...
  • Page 15 Menu Sub-item Setting Description RM-B150 RM-B170 RM-B750 items Detail(HD Detail On/Off Turns detail adjustment mode)/ on or off. Detail(SD Level –99 to ±0 to +99 Specifies the detail level. mode) H/V Ratio –99 to ±0 to +99 Specifies the mix ratio between the H detail level and the V detail level.
  • Page 16 Menu Sub-item Setting Description RM-B150 RM-B170 RM-B750 items Matrix Matrix On/Off Turns the matrix correction function on or off. Preset Matrix On/Off Turns the preset matrix function on or off. Preset Select 1/2/3/4/5/6 Selects a preset matrix. 1: SMPTE-240M equivalent 2: ITU-709 equivalent 3: SMPTE WIDE equivalent...
  • Page 17 Menu Sub-item Setting Description RM-B150 RM-B170 RM-B750 items V Modulation On/Off Turns V modulation Modulation shading on or off. Master –99 to ±0 to +99 Specifies the master V V Modulation modulation. R V Modulation –99 to ±0 to +99 Specifies the V modulation level of R signal.
  • Page 18 Menu Sub-item Setting Description RM-B150 RM-B170 RM-B750 items Black R/G/B Black H –99 to ±0 to +99 Specifies a SAW black Shading shading correction value for the horizontal direction. R/G/B Black H –99 to ±0 to +99 Specifies a parabola Para black shading correction value for the horizontal...
  • Page 19 Adjustments of the lens functions When the optional exclusive lens is used, the following functions can also be controlled from the RM- B150/B170/B750. Function Operation on the lens RM-B150 RM-B170 RM-B750 Iris adjustment Iris ring Iris close – Switching between auto iris and manual iris IRIS switch Zooming Zoom ring Focus adjustment...

  • Page 20: Functions That Can Be Controlled From The Rcp-1001/1501

    Functions That Can Be Controlled from the RCP-1001/ 1501 You can adjust the functions in the following table by using menu operations, adjustment knobs, switches, and the touch panel on the RCP-1001/1501. For details on operations, refer to the operation manual of the RCP-1001/1501. How to Read the Table In the RCP-1001, and RCP-1501 columns of the table below, “Yes”...
  • Page 21 Menu Sub-item Setting Description RCP-1001/1501 items Switch Gamma On/Off Turns gamma correction on or off. Status Black Gamma On/Off Turns black gamma correction on or off. Matrix On/Off Turns linear matrix correction and user matrix correction on or off. Knee On/Off Turns knee correction on or off.

  • Page 22: Using A Wi-Fi Adapter

    • Check the firmware version of your camcorder to make sure that the camcorder supports the Wi-Fi adapter. For details, contact your Sony dealer or your Sony service representative. • In order to use the Wi-Fi connection feature, you must install an optional CBK-UPG02 Installation Key.

  • Page 23: Making A Wi-Fi Connection

    a) The IP address determined by DHCP server is External device connector displayed here. When you have changed a setting Set the Set item to [Execute]. When a confirmation message appears, turn the MENU knob to select “Execute” and press the knob. To make a connection in ad hoc mode Refer to “Settings on the Computer”...

  • Page 24: Using The Web Menu

    Encryption (data encryption): Depending To make a connection in infrastructure the settings on the computer, Disable, mode WEP, TKIP or AES WEP Key Index (key index): 1 when Setting up the wireless LAN access point Encryption is set to [WEP] The following settings are required.
  • Page 25 Example (when the IP address is Example Web menu “192.168.1.10”): Type “http://192.168.1.10/ ” in the address bar. If the connection is complete, a dialog appears asking you to enter the user name and password. Enter the user name and password, and click [OK].

  • Page 26: Using Live Logging Functions

    Example: <PlanningMetadata … version="1.00"> load="true" sp sp For details on the planning metadata, refer to the Operating Instructions supplied with the camcorder. Using Live Logging Functions The Live Logging function allows you to record shot marks using a computer while you are shooting.

  • Page 27: Output Formats And Limitations

    Output Formats and Limitations Video Formats and Output Signals The format of signals output from the VIDEO OUT, HD/SD SDI OUT, and HDMI connectors varies according to the HD/SD mode, the current recording and playback video formats, and the output signal specified by OPERATION >Input/Output >Output &...
  • Page 28 Video Input/Output settings Output signal (i.LINK (HDV/DV) is I/O signal) format Output& 23.98P Source i.LINK HD/SD SDI HDMI VIDEO i.LINK i.LINK Output Select (HDV/DV) SP 1440/ HD&HDV – i.LINK Enable 1920×1080/ 1920×1080/ 1920×1080/ 59.94i 59.94i 59.94i 59.94i Y (1440×1080/ Camera Enable signal 59.94i) Camera/...
  • Page 29 Video Input/Output settings Output signal (i.LINK (HDV/DV) is I/O signal) format Output& 23.98P Source i.LINK HD/SD SDI HDMI VIDEO i.LINK i.LINK Output Select (HDV/DV) HD&HDV PsF i.LINK Enable Muting Input/output 1920/ disabled Camera Enable 1920×1080/ 1920×1080/ 1920×1080/ 23.98P& 23.98PsF 23.98PsF 23.98PsF Y Camera/ Disable...
  • Page 30 Video Input/Output settings Output signal (i.LINK (HDV/DV) is I/O signal) format Output& 23.98P Source i.LINK HD/SD SDI HDMI VIDEO i.LINK i.LINK Output Select (HDV/DV) SP 1440/ HD&HDV PsF cannot be selected 23.98P Pull i.LINK Enable 1920×1080/ 1920×1080/ 1920×1080/ Down 59.94i 59.94i 59.94i (1440×1080/...
  • Page 31 Video Input/Output settings Output signal (i.LINK (HDV/DV) is I/O signal) format Output& 23.98P Source i.LINK HD/SD SDI HDMI VIDEO i.LINK i.LINK Output Select (HDV/DV) HD&HDV – i.LINK Enable Muting Input/output 1280/ disabled Camera Enable 720×480/ 720×480/ 720×480/ 29.97P 59.94P 59.94P 59.94P Camera/ Disable...
  • Page 32 Video Input/Output settings Output signal (i.LINK (HDV/DV) is I/O signal) format Output& 23.98P Source i.LINK HD/SD SDI HDMI VIDEO i.LINK i.LINK Output Select (HDV/DV) DVCAM/ HD&HDV and SD&HDV cannot be selected 29.97P SD&DV – i.LINK Enable 720×480/ 720×480/ Composite 29.97PsF 29.97PsF 720×480/ (720×480/...
  • Page 33 Video Input/Output settings Output signal (i.LINK (HDV/DV) is I/O signal) format Output& 23.98P Source i.LINK HD/SD SDI HDMI VIDEO i.LINK i.LINK Output Select (HDV/DV) SP 1440/ HD&HDV – i.LINK Enable 1920×1080/ 1920×1080/ 1920×1080/ 50i Y signal (1440×1080/ Camera Enable 50i) Camera/ Disable Input/output...
  • Page 34 Video Input/Output settings Output signal (i.LINK (HDV/DV) is I/O signal) format Output& 23.98P Source i.LINK HD/SD SDI HDMI VIDEO i.LINK i.LINK Output Select (HDV/DV) HD&HDV – i.LINK Enable Muting Input/output 1280/ disabled Camera Enable 720×576/50P 720×576/ 720×576/ 50P Y signal Camera/ Disable i.LINK...
  • Page 35 Video Input/Output settings Output signal (i.LINK (HDV/DV) is I/O signal) format Output& 23.98P Source i.LINK HD/SD SDI HDMI VIDEO i.LINK i.LINK Output Select (HDV/DV) DVCAM/ HD&HDV and SD&HDV cannot be selected – i.LINK Enable 720×576/ 720×576/ Composite 25PsF 25PsF 720×576/ (720×576/ Camera Enable 25PsF...

  • Page 36: Output Signals And Operation Restrictions When A Camcorder System Is Configured (In Hd Mode Only)

    Output Signals and Operation Restrictions When a Camcorder System is Configured (in HD Mode Only) The table below shows output signals from the camcorder and operation restrictions to the camcorder when it is connected with a camera adaptor and camera extension unit to configure a shooting and recording system.
