MGP146 Gate Positioner
Installation and Configuration Manual
This manual applies to:
MGP146, MGP146-CA, MGP146-US
Read this manual before using product. Failure to
follow instructions and safety precautions can
result in serious injury, death, or property
damage. Keep manual for future reference.
Part Number: 11679 C
Revised: July 2024
Original Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CMC MGP146 and is the answer not in the manual?

Questions and answers

Summary of Contents for AGI CMC MGP146

  • Page 1 MGP146 Gate Positioner Installation and Configuration Manual This manual applies to: MGP146, MGP146-CA, MGP146-US Read this manual before using product. Failure to Part Number: 11679 C follow instructions and safety precautions can Revised: July 2024 result in serious injury, death, or property Original Instructions damage.
  • Page 2 July 15, 2021 Positioner December 3, 2021 • Added blanking plug requirements and system sketches • Changed company logo • Updated text and drawings fixing references Manual converted to AGI (Arbortext) format. February 1, 2024 Various content updates. July 25, 2024...

  • Page 3: Table Of Contents

    MGP146 GATE POSITIONER – CONTENTS 1. Introduction ............................5 2. Approvals ..............................6 3. Safety............................... 7 3.1 Safety Alert Symbol and Signal Words..................7 3.2 General Safety Information....................... 7 3.3 HAZLOC Controls Safety ......................7 3.4 Electrical Equipment Safety ...................... 8 3.5 Drives and Lockout/Tagout Safety ....................
  • Page 4 MGP146 GATE POSITIONER – 9. Calibration............................. 36 9.1 Initiating an Automatic Calibration..................36 10. Controller Commands......................... 37 10.1 Motion Commands........................ 37 10.2 Calibration Commands ......................37 11. Reading Values from the Controller ....................38 12. Communication System........................39 13. Troubleshooting..........................42 13.1 Run / Error Indicator ......................

  • Page 5: Introduction

    Keep this manual handy for frequent reference and to review with new personnel. If any information in this manual is not understood or if assistance is needed, please contact an AGI representative for assistance. This manual should be regarded as part of the equipment.

  • Page 6: Approvals

    2. APPROVALS MGP146 GATE POSITIONER – 2. Approvals The MGP146 is US/CAN certified to be safely placed in hazardous areas classified in United States NEC (National Electrical Code) / Canada CEC (Canadian Electrical Code) as Class NEC/CEC Class II Division 1 Groups E, F and G Zone 20 under the following standards: United States Canada...

  • Page 7: Safety

    MGP146 GATE POSITIONER – 3. SAFETY 3. Safety 3.1. Safety Alert Symbol and Signal Words This safety alert symbol indicates important safety messages in this manual. When you see this symbol, be alert to the possibility of injury or death, carefully read the message that follows, and inform others.

  • Page 8: Electrical Equipment Safety

    3. SAFETY MGP146 GATE POSITIONER – • Follow safety protocols to verify there are no actual hazards including heat sources, blockages, and lack of guarding. Always operate the system without bypassing controls. • Validate system operation: • before first operating •...

  • Page 9: Safety Equipment And Procedures

    MGP146 GATE POSITIONER – 3. SAFETY • De-energize, block, and dissipate all sources of hazardous energy. • Lock out and tag out all forms of hazardous energy. • Ensure that only 1 key exists for each assigned lock, and that you are the only one that holds that key. •...

  • Page 10: Personal Protective Equipment

    3. SAFETY MGP146 GATE POSITIONER – 3.7. Personal Protective Equipment The following Personal Protective Equipment (PPE) should be worn when installing or maintaining the equipment. • Safety Glasses • Steel-Toe Boots Wear safety glasses at all times to Wear steel-toe boots to protect feet from protect eyes from debris.

  • Page 11: Overview

    MGP146 GATE POSITIONER – 4. OVERVIEW 4. Overview The MGP146 Gate Positioner is designed for use with a broad range of actuators. The Controller can position any device with either a rotary or linear movement that can be monitored using a rotating shaft, and is controlled with a simple open and close mechanism.

  • Page 12: Controller Operation

    5. CONTROLLER OPERATION MGP146 GATE POSITIONER – 5. Controller Operation 5.1. Connectors and Indicators Figure 1. MGP146 Top View Table 1. Indicators and Descriptions Label Description RUN/ERROR 1/sec - Controller operating normally 3/sec - Calibration in progress 10/ sec - Controller in fault Received data lamp, lights for 0.1 seconds with each valid packet INPUT 1 ON General purpose input (lamp on = contact closed)
  • Page 13 MGP146 GATE POSITIONER – 5. CONTROLLER OPERATION Table 1 Indicators and Descriptions (continued) Label Description RS-485 Termination Jumper J8 to terminate the RS-485 network 24 VDC Outputs 24 VDC isolated, protected relay, solenoid coil or motor starter outputs General Purpose 24 VDC isolated, general purpose assignable inputs Inputs Figure 2.

  • Page 14: Modbus Rtu Address Selection

    5. CONTROLLER OPERATION MGP146 GATE POSITIONER – 5.2. Modbus RTU Address Selection The Modbus RTU Slave address is selected using switch S1. The address switches are additive. Address selections are read during power-up. Note Address changes made when power is applied are not reflected until the next power-up cycle. 1.

  • Page 15: Installation Requirements

    MGP146 GATE POSITIONER – 6. INSTALLATION REQUIREMENTS 6. Installation Requirements 6.1. General Precautions To reduce the risk of ignition of hazardous atmospheres, disconnect the equipment from the supply circuit before opening. Keep assembly tightly closed when in operation. Installation in the United States must be according to National Electrical Code (NEC) Article 500 Hazardous Locations rules, and in Canada according to Canadian Electrical Code (CEC) CSA C22.1 Part I Section 18 Hazardous Locations.

  • Page 16: Conditions Of Use

    6. INSTALLATION REQUIREMENTS MGP146 GATE POSITIONER – Figure 4. MPG146 Markings Figure 5. MGP146-CA Marking Figure 6. MPG146-US Markings 6.3. Conditions of Use The MGP146 is designed for Indoor/Outdoor use. Models MGP146-CA and MGP146-US are indoor only requiring certified blanking plug for unused conduit entries, see Section 7.5 –...
  • Page 17 MGP146 GATE POSITIONER – 6. INSTALLATION REQUIREMENTS • The field wiring instructions provided in this manual and regional regulations are followed. • Low voltage wiring must be fully segregated from all other wiring systems. Do not intermix wires inside conduit or junction boxes of any kind including other Class II wiring. Placing separate Class II systems cabling in the same raceway is permitted provided they are not strapped together.

  • Page 18: Installation

    7. INSTALLATION MGP146 GATE POSITIONER – 7. Installation 7.1. Mounting Do not use a rigid connection between the Controller’s operator shaft and the position translator. Doing so risks damaging the DIP seal which can lead to fire or explosion. Use U-bolts to mount the Controller with the operator shaft connected, and a flexible linkage to the slide gate. Use a helical coupling for direct drive from a gates rack position translator, or chain drive hooked to the sprocket gear to translate linear displacement.
  • Page 19 MGP146 GATE POSITIONER – 7. INSTALLATION To mount the enclosure: Note Dimensions shown are inches. Millimeters in brackets. 1. Cut the hole pattern shown below in a free standing bracket or water-tight enclosure. 2. Clamp the conduit entries on two opposite sides using U-bolts. 3.

  • Page 20: Power And Communications

    7. INSTALLATION MGP146 GATE POSITIONER – 7.2. Power and Communications The Controller comes with three 6 ft (1.8 m) pre-made pigtail cables for connection. There are three cables that connect to the Controller using unique connectors: Table 2. Controller Connectors Supervisory power and •...
  • Page 21 MGP146 GATE POSITIONER – 7. INSTALLATION Figure 9. MGP146 Wire Harnesses Pinout 11679 C...

  • Page 22: Actuator Control Inputs And Outputs

    7. INSTALLATION MGP146 GATE POSITIONER – 7.3. Actuator Control Inputs and Outputs The Controller directly drives any actuator with 24 VDC relays, motor starters, or solenoids with up to four amps current requirement. The duty cycle of the Controller is 25% with a maximum on time of 300 seconds at full load.

  • Page 23: Position Translator

    MGP146 GATE POSITIONER – 7. INSTALLATION 7.4. Position Translator The MGP146 has an internal magnetic encoder for position sensing. The encoder has a 0.25 in (6.35 mm) shaft for connection to the Actuator. The position shaft should be isolated from the actuator to prevent damage to the encoder shaft assembly with the coupling supplied.
  • Page 24 7. INSTALLATION MGP146 GATE POSITIONER – Figure 12. Position Translator Rack and Gear 11679 C...

  • Page 25: Conduit Entries

    MGP146 GATE POSITIONER – 7. INSTALLATION 7.5. Conduit Entries In United States and Canada typical installations use a direct conduit connection: • The 3/4 NPT (National Pipe Taper) threaded conduit entries shall be connected to Rigid Metal Conduit (RMC) or other wiring methods according to NFPA NEC Article 501 / CSA CEC C22.1 Section 18. Use certified fittings rated for use in Hazardous Locations or comply with modified ANSI/ASME B1.20.1 standard for RMC thread forming.
  • Page 26 7. INSTALLATION MGP146 GATE POSITIONER – Figure 13. Solenoid Gate Application 11679 C...
  • Page 27 MGP146 GATE POSITIONER – 7. INSTALLATION Figure 14. Electric Gate Application The 24 VDC power supplies may be combined into one however this defeats the isolation feature of having supervisory control separated from potential inductive spikes from magnetic coils (contactor or solenoids). 11679 C...

  • Page 28: Controller Parameters

    8. CONTROLLER PARAMETERS MGP146 GATE POSITIONER – 8. Controller Parameters The operation and accuracy of the Controller is determined by user configurable parameters. This section describes each of these parameters and the effect they have on the operation of the Controller.

  • Page 29: Communication Port

    MGP146 GATE POSITIONER – 8. CONTROLLER PARAMETERS 8.3. Communication Port 8.3.1 Serial Port Speed [Register 48] The communication port can operate at five standard baud rates. The Controller only determines its baud rate during a power-up sequence and must be reset for a new baud rate to take effect. Cycling power or issuing a Soft Reset over the communication system will reset the Controller.

  • Page 30: Encoder Direction [Register 44, Options 1, 2, 3, And 4]

    8. CONTROLLER PARAMETERS MGP146 GATE POSITIONER – 8.4.3 Encoder Direction [Register 44, Options 1, 2, 3, and 4] Selecting the CCW option can change direction of rotation interpreted by the magnetic encoder. Note the open and close outputs and limit switches must be wired to reflect the direction of rotation. The default is CW (clockwise) as opposed to CCW (counter-Clockwise).

  • Page 31: Pseudo Limit Switch System

    MGP146 GATE POSITIONER – 8. CONTROLLER PARAMETERS 8.5.2 Pseudo Limit Switch System The Pseudo Limit Switch system allows for the creation of open and closed limit switches using the transducer position value. This system cannot be used to substitute for a closed limit switch for multi-turn applications. In all other cases the Pseudo Limit Switch will emulate the limit switch functions available to an input limit switch.

  • Page 32: Positioning Accuracy

    8. CONTROLLER PARAMETERS MGP146 GATE POSITIONER – 8.7. Positioning Accuracy The following parameters determine the accuracy of the final position achieved by the Controller. These parameters should be configured before an automatic calibration sequence is initiated. The Controller uses a two-step process to position the actuator: 1.
  • Page 33 MGP146 GATE POSITIONER – 8. CONTROLLER PARAMETERS Table 8 Position Accuracy Parameters (continued) Parameter Description must be longer than or equal to the Turn Around Time parameter. The default value is 20 for 2000 milliseconds. After each jog the Controller adjusts the jog on time. This value is the Minimum Jog on Time (Lit) [Register 40034] shortest jog on time the Controller will allow.

  • Page 34: Calibration Parameters

    8. CONTROLLER PARAMETERS MGP146 GATE POSITIONER – 8.7.1 Calibration Parameters The Controller can perform an automatic calibration sequence. This sequence automatically sets the Controller’s calibration parameters. See Section 9. – Calibration on page 36 for details on initiating a calibration sequence.

  • Page 35: Timing

    MGP146 GATE POSITIONER – 8. CONTROLLER PARAMETERS 8.8. Timing The controller uses a series of timers during a positioning operation: Parameter Description Output Turn Around Time Most Actuators require a delay between open and close operations. The [Register 40027] turnaround timer forces a delay between all operations. Anytime an output is turned off, both outputs will remain off until this timer has expired.

  • Page 36: Calibration

    9. CALIBRATION MGP146 GATE POSITIONER – 9. Calibration 9.1. Initiating an Automatic Calibration The MGP146 Gate Positioner has an automatic calibration system. There are two ways to initiate the calibration sequence: To calibrate the Controller from the communication system: 1. Issue the Start Calibrate Command (Register 40001, Bit 5). Note The high byte of the command register must be set to 0xAA to initiate the calibrate command.

  • Page 37: Controller Commands

    MGP146 GATE POSITIONER – 10. CONTROLLER COMMANDS 10. Controller Commands Commands are executed by setting bits in the Command Register [Register 40001]. The bits are automatically cleared by the Controller. 10.1. Motion Commands Details of the seek operation are in Section 15.1 –...

  • Page 38: Reading Values From The Controller

    11. READING VALUES FROM THE CONTROLLER MGP146 GATE POSITIONER – 11. Reading Values from the Controller The Controller has a series of internal values that provide details of the current operation. These values can be read using the communication system. Table 13.

  • Page 39: Communication System

    MGP146 GATE POSITIONER – 12. COMMUNICATION SYSTEM 12. Communication System The Controller utilizes the Modbus485 communications protocol. It is a slave device. The Controller will only respond to the following Modbus commands: Command Value Command 3 [3hex] Read holding registers 6 [6hex] Write one holding register 16 [10hex]...
  • Page 40 12. COMMUNICATION SYSTEM MGP146 GATE POSITIONER – Table 14 Complete Register Layout (continued) Register Range Identifier Function Units Default 40027 Turn around time 100 msec 1–255 40028 1 sec 1–255 Command fault time* 40029 Jog idle time 100 msec 1–255 40030 10 msec 1–255...
  • Page 41 MGP146 GATE POSITIONER – 12. COMMUNICATION SYSTEM Table 15 Registers with Bit Values (continued) Parameter Register Adder Function 1 = Motor direction to close 1 = Calibration fault 1 = Actuator did not attain position 1 = No movement detected while output on 1 = Encoder fault 1 = Parameter memory corrupted 1 = Controller firmware is corrupted...

  • Page 42: Troubleshooting

    13. TROUBLESHOOTING MGP146 GATE POSITIONER – 13. Troubleshooting 13.1. Run / Error Indicator 11679 C...
  • Page 43 MGP146 GATE POSITIONER – 13. TROUBLESHOOTING 11679 C...

  • Page 44: Communicating With The Mgp146

    13. TROUBLESHOOTING MGP146 GATE POSITIONER – 13.2. Communicating with the MGP146 Before using this guide for troubleshooting communication problems, make sure of the following: 1. Use a proven Modbus 485 Master RTU communications program. 2. Use a breakout box to verify packets are being sent to the RS232 to RS485 converter. The TX, RTS, and CTS lamps of the breakout box should be flashing.
  • Page 45 MGP146 GATE POSITIONER – 13. TROUBLESHOOTING 11679 C...

  • Page 46: Positioning Errors

    13. TROUBLESHOOTING MGP146 GATE POSITIONER – 13.3. Positioning Errors 13.3.1 Actuator will not Open Make sure the Force Open or Close option is not active before using this section. 11679 C...

  • Page 47: Actuator Will Not Close

    MGP146 GATE POSITIONER – 13. TROUBLESHOOTING 13.3.2 Actuator will not Close Make sure the Force Open or Close options are not active before using this section. 11679 C...

  • Page 48: Actuator Position Read Back Is Incorrect

    13. TROUBLESHOOTING MGP146 GATE POSITIONER – 13.3.3 Actuator Position Read Back is Incorrect 11679 C...

  • Page 49: Specifications

    MGP146 GATE POSITIONER – 14. SPECIFICATIONS 14. Specifications 14.1. MGP146 Common Specifications Detailed product specifications can be obtained from the individual product data sheets. Table 16. MGP146 Common Specifications Supervisory Input 10 to 28 VDC Voltage Current 50mA @ 24 VDC Control Outputs and Inputs Voltage 10 to 28 VDC (separate isolated...
  • Page 50 14. SPECIFICATIONS MGP146 GATE POSITIONER – Figure 16. MGP146 Housing Dimensions Figure 17. MGP146-CA/US Housing Dimensions 11679 C...

  • Page 51: Appendix

    MGP146 GATE POSITIONER – 15. APPENDIX 15. Appendix 15.1. Seek Operation Sequence When a seek to position, full open, or full close command is issued the Controller executes a seek operation. The seek operation uses the following logic: Table 17. Seek Operation Logic Step 1 Determine direction.
  • Page 52 15. APPENDIX MGP146 GATE POSITIONER – Figure 18. Drawing 10258: Typical Mounting 11679 C...
  • Page 53 MGP146 GATE POSITIONER – 15. APPENDIX Figure 19. Drawing 10259: Housing Details 11679 C...
  • Page 54 15. APPENDIX MGP146 GATE POSITIONER – Figure 20. Drawing 11635: Solenoid Wiring Diagram 11679 C...
  • Page 55 MGP146 GATE POSITIONER – 15. APPENDIX Figure 21. Drawing 11635–1: Contactor Wiring Diagram 11679 C...

  • Page 56: Warranty

    Goods shall be limited to 90 days. Subject to AGI’s sole discretion, if the Goods, or a component thereof, are found to have a default in materials and/or workmanship within the Warranty Term, AGI will, at its own option and expense, repair or replace the subject Goods.
  • Page 57 CONTRACT, INFRINGEMENT, NEGLIGENCE, STRICT LIABILITY, OTHER TORT OR OTHERWISE), SHALL AGI’S LIABILITY TO BUYER AND/OR ITS CUSTOMERS EXCEED THE PURCHASE PRICE OF THE GOODS. BUYER AGREED THAT IN NO EVENT SHALL AGI’S LIABILITY TO BUYER AND/OR ITS CUSTOMERS EXTEND TO INCLUDE INCIDENTAL, CONSEQUENTIAL, OR PUNITIVE DAMAGES. THE TERM “CONSEQUENTIAL DAMAGES”...
  • Page 58 CMC is an AGI Brand. AGI is a leading provider of equipment solutions for agriculture bulk commodities including seed, fertilizer, grain, and feed systems with a growing platform in providing equipment and solutions for food processing facilities. AGI has manufacturing facilities in Canada, the United States, the United Kingdom, Brazil, South Africa, India and Italy and distributes its products globally.
