User Manual The instruction manual is an integral part of this product, please keep it properly. The user must read carefully, especially the safety description in the manual, as well as the installation and maintenance information.
User Manual Important safety instructions ! This flake ice machine is a commercial device and is only suitable for the purpose specifically designed for the device. Any other use is considered improper use and may cause danger. For any losses caused by improper, incorrect and unreasonable use of this product, the manufacturer does not assume any legal and related responsibilities.
User Manual Ⅰ.Overview Before installing, debugging, and using the flake ice machine, please read the instruction manual in detail. This instruction manual introduces the operating conditions, performanceparameters, installation and debugging, operating procedures, etc. of the company's flake ice machine. Please use with our company's special ice storage bin.
User Manual According to the machine nameplate parameter requirements, select the appropria- ② te air switch, and the air switch must be installed within reach. ③ The sockets or other power supplies provided on site must be installed with a grou- nd wire in accordance with relevant requirements, and a reliable connection to the m- achine ground must be ensured.
Page 7
User Manual Ice storage bin installation: install the ice storage bin and adjust the 4 supporting feet of the ice storage bin to keep the ice storage bin horizontal and vertical. Placement of the machine: Place the machine horizontally on the upper part of the ice storage bin, and the rear is basically level with the back of the ice storage bin.
Page 8
User Manual Figure 3 Final inspection: Fill in the following installation checklist to ensure the correct installation of the machine: Check item Result Remarks Whether the packaging inside and outside of the machine and the fixings for transportation are all removed Whether the ice maker and ice storage bin are placed horizontally Whether the water and electricity part is fixedly connected...
User Manual Ⅴ.Machine operation instructions Control Panel Compressor Motor Pump Figure 4 Start and stop Set up Increase Reduce Reservati o n Instructions Power-on state: power-on default shutdown state, display OFF. ① Shutdown state: In the ice making state, short press the "Start/Stop" button to start ②...
Page 10
User Manual High-voltage failure-when the high-voltage switch is continuously disconnected, it ② enters a failure state, and the display shows high-voltage failure. Low-voltage protection-delay to start the low-voltage detection function after each ③ startup. High temperature fault——Under normal circumstances, the evaporation tempera- ④...
Page 11
User Manual adjusted to the best water level line when the machine leaves the factory,please do not adjust it up or down arbitrarily. If the water level is indeed too low or too high, you can adjust the valve in the water tank to make the water level reach the right position (the water level is about 26mm from the bottom of the water divider).
User Manual check the electrical circuit. After troubleshooting, the corresponding indicator light will go out, and then click the button, the ice maker will start with a delay and enter the normal operating state. Compressor and reducer overload fault: When the compressor and reducer current ④...
Page 13
User Manual The steps are shown in Figure 5: Figure 5 3. Special maintenance: This maintenance needs to be performed by our company's maintenance personnel or trained and approved personnel. ★Note: When disassembling the ice machine, please put all the parts away and disassemble and debug according to the drawings.
User Manual 4. When not using the ice machine for a long time: ★Note: This ice maker cannot work at temperatures below freezing. To prevent ① damage to the water supply pipeline, when the temperature is below zero, drain the water in the ice maker.
User Manual Ⅷ.Factory parameter setting table Item Function description Option range Defaults Remarks Boot delay 1-20 minute 1 minute Shutdown delay 1-20 minute 1 minute Compressor protection 0.1-25.0A current Motor protection current 0.1-25.0A 2.5A When setting "PUMP", start and stop together OFF-None with the water pump: Valve definition...
Page 16
User Manual TRUFROST COOLING PRIVATE LIMITED 1214 & 1215, Tower B, Emaar Digital Greens, Golf Course Extn. Road, Sector 61, Gurugram – 122011, Haryana, India T. +91-7303166766 info@trufrost.com www.trufrost.com...
