Fox-Lux FXBX50S-M-3 Manual

FXBX50S-M-3 SELF TEST* EMERGENCY EXIT BOX
Model Variant
Rated Supply Voltage
Mains Frequency
Max. Power Consumption
Standby Power
Emergency Output Power
Rated Emergency Duration
Battery Charge Time
Operating Temperature
Insulation Class
Ingress Protection
Impact Protection
Dimensions (L x W x H)
Battery Compatibility
Battery Code
LED Configuration
IMPORTANT NOTE: This self-test luminaire is configured to manual test mode by default.
If self-test mode is required, it should be activated via remote control (ref.: REM-E1).
With this feature enabled, functional and duration tests are conducted according to BS EN 50172:2004
This product is compatible with our infrared remote control. See product REM-E1 for more details.
To optimise long-term battery performance, the luminaire will operate for 3 hours before automatically shutting down.
The battery must be recharged within 6 months of full discharge.
When the rated operational time is no longer reached after a full recharge, the battery must be replaced.
Technical Data
FXBX50S-M-3
220-240V AC
50 / 60 Hz
3W nominal
< 16 hours
0 to 40°C
540 x 290 x 66mm
2 x 18650 Li-ion 3.6V 5Ah
FXC3.6-5000-E75
EVERLIGHT 2835
8W
< 0.9W
3 hours
Class I
IP 20
IK 06
06
REF. V2.4.0 04‐09‐24
