Be sure to read this instruction manual
before use.
1.
......................................2
2. Safety Precautions ..............................2
3. Name of each part .............................. 4
4.Accessories......................................... 4
5.How to install the hanging hook........... 5
How to install the stand .......................6
6. Installation ...........................................7
7. AC adaptor connection .......................7
8. How to work ..........................................8
9. How to care .............................................9
Photocatalytic
Sterilization/Deodorizer
Portable type
KL-E01-W
10. W h e n i n t r o u b l e ..........................12
11. Specifications.................................. 13
Instruction Manual
KL-E01-K
Advertisement
Table of Contents
Summary of Contents for Kaltech TURNED K mini
-
Page 1: Table Of Contents
Photocatalytic Sterilization/Deodorizer Portable type Instruction Manual KL-E01-K KL-E01-W Be sure to read this instruction manual before use. Introduction . 10. W h e n i n t r o u b l e ......12 ........2 2. Safety Precautions ......2 11. -
Page 2: Introduction
1. Introduction This product is a portable type sterilization/deodorization device that utilizes photocatalytic technology. Photocatalyst removes organic matter such as odors and viruses to provide a confortable space. What is "photocatalytic technology？ When photocatalytic filter is irradiated with light, OH radicals with strong oxidizing power is generated. - Page 3 Warning ●Do not use this product outdoors. ● Do not allow cigarette ashes, drinking ●Do not place it in an unstable place. water, or other liquids to get inside the ●Do not give strongshocks or vibrations inlet or outlet. by stepping on or dropping the product. ※If liquid or foreign matter gets inside, turn off ●Do not use the stand for other mod the power and contact the distributor where...
-
Page 4: Name Of Each Part
3. Name of each part 【Main body】 Air volume control knob Power l a mp Nozzle Power button AC adapter connecti o n termi n al Activated carbon photocatalyic filter Main body fixing unit Pre-filter（Inlet） 【Installation image】 Front panel Stand 4. -
Page 5: How To Install The Hanging Hook
5. How to install the hanging hook/stand ●. How to install the hanging hook When opend, the stand is installed. For hanging use, install the hanging hook according to the following procedure. Loosen the two screws with a screw driver and remove the stand from the main unit. Stand Insert the hanging hook into the main body and secure the two screws with a screw driver. -
Page 6: How To Install The Stand
How to install the hanging hook ● How to install the hanging stand Loosen the two screws with a screw driver and remove the hanging hook from the main unit. Hanging hook Insert the stand into the main body and secure the two screws with a screw driver. Stand... -
Page 7: Installation
6. Installation For hanging use, please use the hanging hook. Mobile battery is not included in this product. When using a stand When using hanging hook When using mobile battery 7. AC adapter connection ※ Do not connect the AC adapter to the power outlet yet. Insert the AC adapter plug into the connection terminal on the main unit and push it firmly all the way in. -
Page 8: How To Work
8. How to work <Caution> Make sure that the inlet and outlet ports of the main unit are not blocked before operation. ● After installing the main unit,connect the AC adapter to the power outlet. Press the power button on the main unit ●... -
Page 9: How To Care
9. How to care <Caution> Be sure to turn off the power before doing. ● ●Pre-filter cleaning ● Dust accumluation reduces the ability to blow air. Clean the unit regularly. Remove the front panel from the main unit. ● Remove the front panel by pulling it straight toward your side. - Page 10 How to care ●Photocatalytic filter cleaning This product is equipped with an activated carbon photocatalytic filter. When used 8 to 10 hours per day, the power lamp will turn orange(a sign for cleaning) in about 3 months to let you know when it is time to clean the photocatalytic filter. Caution This product is a device that decomposes airborne bacteria and odor componentts.
- Page 11 How to care Dry fully naturally in the sun <Caution> f drying in the sun is not possible, dry the product in a well-lit place ● until the moisture is gone. If moisture remains, the photocatalytic may not be fully demonstrated. It is more effective if both sides of photocatalytic filter are exposed to ●...
-
Page 12: When In Trouble
When in trouble In such a case Please check ● Is the AC adapter firmly plugged into an outlet? Power does not turn on ● Is the AC adapter plug firmly inserted into the AC adapter connection terminal on the main unit? ⇒... -
Page 13: Specifications
11. Specifications Photocatalytic sterilization/ N a m e of pr o du ct deodorization portable type Model No. KL-E01-W（White） / KL-E01-K（Black） Sterilizing・deodorizing Activated carbon photocatalytic filter method ※1 Max. approx 12 ㎡（90 min.） Applicable space Width 142mm x Depth 88mm x Height 219mm Dimensions（With stand）...
