Package Contents
All-in-One Collaborative Touch Panel
TYPE-C HDMI TOUCH-USB USB 3.0 (PUBLIC) USB 3.0 (PUBLIC)
Display
BK Series
Display Overview (Front)
1
1
USB-C Port
2 HDMI Port
3
Touch (USB-B) Port
4
USB-A 3.0 Ports x 2
5
Magnetic Stylus Holders
Wi-Fi Antenna x 3
Remote Control Batteries
TYPE-C HDMI TOUCH-USB (PUBLIC) USB 3.0 (PUBLIC) USB 3.0
2 3 4 5 6 5 7 8 9 10 11 12
6 11
Speakers Volume Down Button
7 IR Sensor (for Remote Control) 12 Volume Up Button
8 13
Home Button Power Button
9
Back Button
10
Settings Button
Stylus x 2 HDMI Cable
Quick Start Guide
Display Overview (Rear)
1
13 4 3
1
Handles
2 Wall Mount Screw Holes
3
Power Socket
Power Cable USB Cable
Wall Mount (Including Screws)
2 1
6
5
4
Power Switch
5 Wi-Fi Antenna Connectors
6
80-Pin OPS Slot
