- Page 1 INSTRUCTION MANUAL VHF TRANSCEIVERS iF3262DT iF3262DS UHF TRANSCEIVERS iF4262DT iF4262DS The photo shows the UHF transceiver.
-
Page 2: Explicit Definitions
SAVE THIS INSTRUCTION MANUAL — This instruc- explosion may occur. tion manual contains important oper ating instructions for Personal injury, fire hazard or electric the IC-F3262DT, IC-F3262DS VHF TRANSCEIVERS and RWARNING! shock may occur. IC-F4262DT, IC-F4262DS UHF TRANSCEIVERS. Equipment damage may occur. -
Page 3: Precautions
PRECAUTIONS CAUTION: DO NOT operate the transceiver unless the flexible R DANGER! NEVER short the terminals of the battery pack. antenna, battery pack and jack cover are securely attached. Shorting may occur if the terminals touch metal objects such as a key, so be careful when placing the battery packs (or the Confirm that the antenna and battery pack are dry before transceiver) in bags, and so on. -
Page 4: Recommendation
RECOMMENDATION PRECAUTIONS (Continued) CLEAN THE TRANSCEIVER THOROUGHLY WITH FRESH BE CAREFUL! The transceiver meets IP67* requirements WATER after exposure to salt water, and dry it before operat- for dust-tight and waterproof protection. However, once the ing. Otherwise, the transceiver’s keys, switches and control- transceiver has been dropped, dust-tight and waterproof pro- lers may become unusable, due to salt crystallization, and/or tection cannot be guaranteed because of possible damage to... -
Page 5: Table Of Contents
TABLE OF CONTENTS IMPORTANT ................i 4 BATTERY CHARGING ..........19–23 EXPLICIT DEFINITIONS ............i ■ Caution ...............19 PRECAUTIONS ..............ii ■ Optional battery chargers ...........21 RECOMMENDATION ............iii 5 BATTERY CASE ............24–26 VOICE CODING TECHNOLOGY ........iii ■ BP-240 optional battery case ........24 1 ACCESSORIES ............1–3 ■... -
Page 6: Accessories
ACCESSORIES ■ Supplied accessories ■ Accessory attachments D Flexible antenna The following accessories are supplied. Connect the supplied flexible antenna to the antenna connector. Flexible antenna Battery pack Belt clip (This illustration is CAUTION: for the UHF type.) • NEVER carry the transceiver by holding antenna. -
Page 7: D Battery Pack
ACCESSORIES D Battery pack D Belt clip To attach the battery pack: To attach the belt clip: Slide the battery pack in the direction of the arrow (q) until the q Remove the battery pack if it is attached. battery release button makes a ‘click’ sound. w Slide the belt clip in the direction of the arrow until the belt clip locks and makes a ‘click’... -
Page 8: D Connector Cover
ACCESSORIES D Connector cover To attach the connector cover: To detach the connector cover: q Place the connector cover over the multi-connector. q Remove the screw using a Phillips screwdriver. w Tighten the screw. w Detach the connector cover to connect optional equip- ment. -
Page 9: Panel Description
PANEL DESCRIPTION ■ Front panel r DEALER-PROGRAMMABLE KEY [Side1] D esired functions can be preset by your dealer. (p. 6) GPS receiver* t PTT SWITCH [PTT] Hold down to transmit, release to receive. Speaker y DEALER-PROGRAMMABLE KEYS [Side2]/[Side3] D esired functions can be preset by your dealer. (p. 6) Microphone u 10-KEYPAD (Depending on the version) T he keypad allows you to enter digits to:... -
Page 10: Function Display
PANEL DESCRIPTION ■ Function display !0 MULTI-CONNECTOR C onnects to optional equipment. Connector cover NOTE: Attach the connec- tor cover when optional equipment is not used. See page 3 for details. CALA TXCU TXC q SIGNAL STRENGTH ICON Indicates relative signal strength level. w LOW POWER ICON Appears when low output power is selected. -
Page 11: Battery Icon
PANEL DESCRIPTION ■ Programmable function keys y BELL ICON The following functions can be assigned to the [EMR], [Side1], [Side2], [Side3], [P0], [P1], [P2] and [P3] program- A ppears or blinks when a matched signal is received, de- pending on the presetting. mable function keys. - Page 12 PANEL DESCRIPTION ZONE KEY “ZONE” SCAN ADD/DEL (TAG) KEY “SCAD” Push this key, then push [CH Up] or [CH Down] to select the ➥ Push to add a channel to, or delete it from the current scan desired zone. When [Rotary selector] selects the “operating group.
- Page 13 PANEL DESCRIPTION MEMORY CH 1/2/3/4 KEYS “CH1” “CH2” “CH3” “CH4” LONE WORKER KEY “LONE” Push to directly select memory channels 1 to 4. Push to turn the Lone Worker function ON or OFF. • If the Lone Worker function is activated, the Emergency function is automatically turned ON after the specified time period has passed MONI KEY “MON”...
- Page 14 PANEL DESCRIPTION C.TONE CH ENT KEY “TSEL” CALL KEYS “CALL” “CALA” “CALB” Push to enter the continuous tone channel selection mode. Push to transmit a 2/5-tone or BIIS ID code. Then push [CH Up] or [CH Down] to select the desired tone •...
- Page 15 PANEL DESCRIPTION TX CODE CHANNEL SELECT KEY “TXC” USER SET MODE KEY “SET” Push to enter the TX code channel selection mode. Then ➥ Hold down for 1 second to enter the User set mode. push [CH Up] or [CH Down] to set the desired channel. (pp. •...
-
Page 16: Basic Operation
BASIC OPERATION ■ Turning power ON D Battery type selection Prior to using the transceiver for the first time, the battery pack must be fully charged for optimum life and operation. When turning ON the transceiver, the battery type must be (p. -
Page 17: Channel Selection
BASIC OPERATION ■ Channel selection D Voting operation (for zone selection) Several types of channel selections are available. Methods may differ, depending on the presetting. The transceiver automatically starts scanning when a zone, specified for the voting operation, is selected. NON-ZONE TYPE: The voting scan detects the signal of the repeater and auto- To select the desired operating channel:... -
Page 18: Call Procedure
BASIC OPERATION ■ Call procedure ■ Receiving and transmitting When your system employs tone signaling, excluding CTCSS CAUTION: Transmitting without an antenna will damage and DTCS, this call procedure may be necessary prior to the transceiver. voice transmission. The tone signaling employed may be a selective calling system which allows you to call only specific Receiving: station(s) and prevents unwanted stations from contacting... -
Page 19: D Transmitting Notes
BASIC OPERATION D Transmitting notes D TX code channel selection • Transmit inhibit function If the transceiver has [TX Code CH Select] assigned to it, The transceiver has several inhibit functions which restrict the display can be toggled between the operating channel transmission under the following conditions: number or name, and the TX code channel number or name. -
Page 20: D Dtmf Transmission
BASIC OPERATION D TX code number edit USING [TX CODE ENTER] KEY: (PMR operation only) q After pushing [TX Code CH Select], push [CH Up] or [CH If the transceiver has [TX Code CH Select] or [TX Code Down], or push [TX Code CH Up] or [TX Code CH Down] Enter] assigned, the TX code contents can be edited within to select the desired TX code channel. -
Page 21: User Set Mode
BASIC OPERATION ■ User set mode ■ Scrambler function The User set mode allows you to set seldom-changed set- The voice scrambler function provides private communica- tings and “customize” the transceiver operation to suit your tion between stations. All transceiver versions have a built-in preferences and operating style. -
Page 22: Emergency Transmission
BASIC OPERATION ■ Emergency transmission D NOTES When [Emergency] is pushed for the specified time period, an emergency signal is transmitted once, or repeatedly, on the Depending on the presetting, the following functions may be specified emergency channel, depending on the presetting. automatically activated. -
Page 23: Automatic Key Lock Function
BASIC OPERATION ■ Automatic Key Lock function When [Lock] is assigned to any key, and the Automatic Key Lock timer is preprogrammed*, the key lock function can be automatically turned ON after the specified time period has passed with no key operation. While the lock function is ON, hold down [Lock] for 1 second to turn the function OFF. -
Page 24: Battery Charging
BATTERY CHARGING ■ Caution R DANGER! NEVER strike or otherwise impact the battery Misuse Misuse of Li-ion batteries may result in the pack. Do not use the pack if it has been severely impacted or following hazards: smoke, fire, or the battery cells may dropped, or if it has been subjected to heavy pressure. -
Page 25: D Charging Caution
BATTERY CHARGING D Charging caution R DANGER! NEVER charge the battery pack in areas with CAUTION: DO NOT use the battery pack out of the specified extremely high temperatures, such as near fires or stoves, temperature range for the transceiver (–25˚C to +55˚C) and inside a sun-heated vehicle, or in direct sunlight. -
Page 26: Optional Battery Chargers
BATTERY CHARGING ■ Optional battery chargers D Rapid charging with the BC-160 D Regular charging with the BC-171 The optional BC-160 provides rapid charging of the Li-ion The optional BC-171 provides regular charging of the Li-ion battery pack. battery pack. Charging time: Approximately 3.5 hours Charging time: Approximately 11.5 hours The following items are additionally required:... - Page 27 BATTERY CHARGING D AD-106 installation D Rapid charging with the BC-119N+AD-106 The AD-106 must be installed into the BC- The optional BC-119N provides rapid charging of the Li-ion charger adapter 119N or BC-121N before battery charging. battery pack. Charging time: Approximately 3.5 hours ➥...
- Page 28 BATTERY CHARGING D Rapid charging with the BC-121N+AD-106 The optional BC-121N allows up to 6 battery packs to be si- IMPORTANT: Battery charging caution multaneously charged. Ensure the guide tabs on the battery pack are correctly Charging time: Approximately 3.5 hours aligned with the guide rails inside the charger adapter.
-
Page 29: Battery Case
BATTERY CASE ■ BP-240 optional battery case When using the BP-240 battery case, install six AAA (LR03) Fig.1 size alkaline batteries, as illustrated to the right. BP-240 q Unhook the battery cover release hook (q), and open the cover in the direction of the arrow (w). (Fig.1) w Install six AAA (LR03) size alkaline batteries. -
Page 30: Bp-261 Optional Battery Case
BATTERY CASE ■ BP-261 optional battery case D Alkaline batteries installation BP-261 Install six AA (LR6) size alkaline batteries as described below. q Unhook the battery cover release hook (q), and open the cover in the direction of the arrow (w). (Fig.1) Fig.1 w Install six AA (LR6) size alkaline batteries. - Page 31 BATTERY CASE D Battery case attachment Slide the battery pack in the direction of the arrow until the To remove the battery case: battery release button makes a ‘click’ sound. Slide the battery case’s battery release button in the direction of the arrow (q), and then push the release button in the direction of the arrow (w).
-
Page 32: Swivel Belt Clip
SWIVEL BELT CLIP ■ MB-93 contents r Clip the belt clip to a place on your belt. Insert the trans- ceiver into the belt clip until the base clip is fully inserted into the groove. Qty. q Belt clip ................1 w Base clip ................1 ■... -
Page 33: To Detach
SWIVEL BELT CLIP ■ To detach q Turn the transceiver upside down in the direction of the CAUTION: HOLD THE TRANSCEIVER TIGHTLY WHEN HANGING arrow and pull it out of the belt clip. OR DETACHING THE TRANSCEIVER FROM THE BELT CLIP. -
Page 34: Speaker Microphone
SPEAKER MICROPHONE ■ Optional HM-184/HM-184H ■ To attach Attach the connector of the speaker microphone into the multi Microphone connector on the transceiver and tighten the screw. Speaker Belt clip PTT SWITCH Hold down to Screw transmit; release to receive. Coin Turn OFF the trans- CAUTION: Firmly attach... -
Page 35: Options
OPTIONS D BATTERY PACKS D CHARGERS • BP-232WP • BC-119N + AD-106 l i-ion battery pack desktop charger charger adapter Voltage: 7.4 V, Capacity: 2250 mAh (min.) 2300 mAh (typ.) + BC-145S ac adapter • Battery life For rapid charging of battery packs. A power adapter may be supplied with the charger, depending on the version. -
Page 36: D Belt Clips
OPTIONS D BELT CLIPS D OTHER OPTIONS • MB-93 • AD-118 swivel belt clip acc adapter Allows you to connect an accessory which uses a HIROSE • MB-94R belt clip plug. See the instruction sheet of the AD-118 for details of Exclusive alligator-type belt clip. -
Page 37: Country Code List
COUNTRY CODE LIST • ISO 3166-1 Country Codes Country Codes Austria Liechtenstein Belgium Lithuania Bulgaria Luxembourg Croatia Malta Czech Republic Netherlands Cyprus Norway Denmark Poland Estonia Portugal Finland Romania France Slovakia Germany Slovenia Greece Spain Hungary Sweden Iceland Switzerland Ireland Turkey Italy United Kingdom... - Page 38 MEMO...
- Page 39 MEMO...
- Page 40 < Intended Country of Use > A-7017D-1EU-r Printed in Japan © 2012-2016 Icom Inc. 1-1-32 Kamiminami, Hirano-ku, Osaka 547-0003, Japan Printed on recycled paper with soy ink.
