- Page 1 Pro Audio Solutions Microphone Mute/ Talk Switch User Manual MUTEMATE-85...
- Page 2 Thank you for choosing Kopul. Kopul’s MUTEMATE-85 for dynamic and condenser microphones functions as a momentary mute button so an audience, recording talent, or online conferees won’t hear coughs or side conversations. With the flip of a switch, it becomes a momentary talk button that activates the microphone while the button is pressed.
- Page 3 Precautions • Please read and follow these instructions, and keep this manual in a safe place. • Exposure to high sound levels can cause permanent hearing loss. Avoid listening at high volumes for extended periods of time. • Keep this product away from water and any flammable gases or liquids.
- Page 4 Using a Signal Booster for Low-Output Dynamic and Ribbon Microphones: When using a mic activator, like the Cloudlifter, or an inline mic preamplifier like the Polsen Single-Channel Mic Preamp: Connect the microphone to the signal booster. Then connect the signal booster to the MUTEMATE-85.
- Page 5 Once all connections have been made, activate phantom power on your external preamp. The MUTEMATE-85 is designed to attenuate a microphone signal by approximately 85 dB. It works best when using under a normal sensitivity and gain structure between 30 and 60 dB.
-
Page 6: Replacing The Battery
Replacing the Battery The indicator LED is powered by a 3 V CR1632 lithium battery. When the battery runs low, the indicator light does not turn on when the button is pressed. Replace the battery following these steps: Unscrew the four side screws and remove the chassis. -
Page 7: Specifications
Specifications Connector 1 Remove the battery, 3-pin XLR female input place a new one into Connector 2 the battery slot, and 3-pin XLR male output slide it into place. Selector Talk/Mute Switches Material Steel Dimensions 2 × 2.3 × 2.4 in. (H ×... - Page 8 One-Year Limited Warranty This KOPUL product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later. The warranty provider’s responsibility with respect to this limited warranty shall be limited solely...
