Installation and Operations Manual
64-EGBSP-12
64-EGBSP-16
64-EGBSP-20
64-EGBSP-24
64-EGBSP-32
WATERSPHERE
12" WaterSphere with Concrete Mounting Bracket
16" WaterSphere with Concrete Mounting Bracket
20" WaterSphere with Concrete Mounting Bracket
24" WaterSphere with Concrete Mounting Bracket
32" WaterSphere with Concrete Mounting Bracket
4830 Timber Creek Dr, Houston, TX 77017
North America: +1 (713)-946-4343
PAL Lighting LLC
www. pallighting.com
Advertisement
Related Manuals for PAL 64-EGBSP-12
Summary of Contents for PAL 64-EGBSP-12
- Page 1 16” WaterSphere with Concrete Mounting Bracket 64-EGBSP-20 20” WaterSphere with Concrete Mounting Bracket 64-EGBSP-24 24” WaterSphere with Concrete Mounting Bracket 64-EGBSP-32 32” WaterSphere with Concrete Mounting Bracket PAL Lighting LLC 4830 Timber Creek Dr, Houston, TX 77017 North America: +1 (713)-946-4343 www. pallighting.com...
- Page 2 ENGLISH ___________ WATERSPHERE | INSTALLATION & OPERATION MANUAL Table of Contents SECTION 1. SAFETY INSTRUCTIONS 3 SECTION 2. PREPARATION 2.1 PACKAGE CONTENTS 2.2 PREPARATION WORK SECTION 3. INSTALLATION FOR GUNITE/CONCRETE POOLS 5 For your safety, it is imperative that this product be installed and maintained by a licensed and qualified contractor specializing in pool equipment, adhering to local regulations.
-
Page 3: Package Contents
Section 2. PREPARATION This manual provides installation and operational instructions for the PAL Lighting WaterSphere. Read the installation & operational manual before proceeding with the installation. Keep this manual for future reference. -
Page 4: Important Notice
ENGLISH ___________ WATERSPHERE | INSTALLATION & OPERATION MANUAL NOTE: The Junction Box and the low voltage transformer is located at least 4 (four) inches above ground level or eight (8) inches above maximum water level, whichever is higher. The Junction Box must be at least 48 inches from the edge of the pool. - Page 5 ENGLISH ___________ WATERSPHERE | INSTALLATION & OPERATION MANUAL Section 3. INSTALLATION FOR GUNITE/CONCRETE POOLS A. Fixing Bubbler Niche to Steel B. Concrete Stage Secure niche to steel reinforcing NOTE: use PVC solvent cement on all bars using wire in 4 positions provided fittings.
- Page 6 ENGLISH ___________ WATERSPHERE | INSTALLATION & OPERATION MANUAL Cable and plug assembly. N.B. Do not remove protective cap until installation of light. 1. Remove niche protective cap 2. Draw cable through conduit 3. Tighten cable nut by hand only N.B. Do not remove Cable Seal protective cap until pool finish is applied.
- Page 7 ENGLISH ___________ WATERSPHERE | INSTALLATION & OPERATION MANUAL C. Installing Cable N.B. Do not remove protective Pool Finish 7/8” (MAX) cap until pool finish is applied 1/2” (MIN) Apply finish to top edge render ring max 7/8” NOTE: Leave sufficient cable length to remove for servicing Install internal pipe fitting.
- Page 8 ENGLISH ___________ WATERSPHERE | INSTALLATION & OPERATION MANUAL D. Installing Luminaire Remove protective caps from plug and light socket by unscrewing. Insert plug into light and secure with screw-on cap. Secure luminaire assembly to niche using 6xM4 screws NOTE: The three machined screws will attach to the light mount and go through the gray plate into the niche to secure the light mount.
- Page 9 ENGLISH ___________ WATERSPHERE | INSTALLATION & OPERATION MANUAL 1. Once the gray face plate and light mount have been attached, pull the attached cable through the light mount and conduit back to a 24v transformer. NOTE: When wiring into the transformer, there will be a brown and blue terminal for the wires to screw into on the left side.
- Page 10 500mm (20”) Sphere Large Adapter 400mm (16”) Sphere 600mm (24”) Sphere 800mm (36”) Sphere Lens Adapter Optional (Only ts 20” Sphere and Larger) Must use silicone PAL Evenglow Bubbler gasket otherwise screw will be too long (Sold Separately) Part Number 64-EGB-CGS-XXX...
- Page 11 ENGLISH ___________ WATERSPHERE | INSTALLATION & OPERATION MANUAL NOTES...
- Page 12 ENGLISH ___________ WATERSPHERE | INSTALLATION & OPERATION MANUAL...
