USER MANUAL

LTSP Series

Lighting spotlights

v1.2 - eng

LIGHTING

Table of Contents

Need help?

Do you have a question about the LTSP Series and is the answer not in the manual?

Questions and answers

Summary of Contents for opto engineering LTSP Series

Page 1 USER MANUAL LTSP Series Lighting spotlights v1.2 - eng LIGHTING...
Page 2: Table Of Contents
Contents GENERAL INFORMATION Disclaimer ........Forbidden use .
Page 3 Connectors and pinout ....... . . Electrical speciﬁcations ....... . . Electrical protections .
Page 4: General Information
1 GENERAL INFORMATION 1.1 Disclaimer Always use and store Opto Engineering® products in the prescribed conditions in order to ensure their proper operation: failing to comply with the prescribed conditions may shorten the product lifetime and/or result in malfunctioning, performance degradation or failure.
Page 5: Revisions
LTSP | USER MANUAL • This device has limited protection against transients caused by inductive loads. If necessary, use external protection devices like fast diodes or other speciﬁc transient protectors; • Do not allow foreign objects to enter the unit or drop into holes, terminals and other openings or gaps.
Page 6: Ordering Code
LTSP | USER MANUAL 1.4 Ordering code The product part number is composed as follows: LTSP50-X-YYL where X is the label of the color variant and YYL is the label of the lens. The ordering code is explained more precisely in Table 2. Code Description Options...
Page 7: Warranty And Certifications
LTSP | USER MANUAL 2 WARRANTY AND CERTIFICATIONS 2.1 Warranty The device warranty is 12 months from the effective delivery date with reference to the device serial number. Warranty covers the replacement or the repair of the defective part (components, device or part of it) with the exclusion of dismantling and shipping costs.
Page 8: Rohs, Reach And Weee
LTSP | USER MANUAL • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver isconnected. • Consult the dealer or an experienced radio/TV technician for help. 2.4 RoHS, REACH and WEEE LTSP products are conformal to the following directives and standards: •...
Page 9: Introduction
3 INTRODUCTION 3.1 Manual and conventions Opto Engineering® SpA, with its registered oﬃce in Strada Circonvallazione Sud 15, 46100 Mantova (Mn) - Italy, hereinafter the manufacturer, provides all the necessary information in this installa- tion, use and maintenance manual in a clear and simple way to install, use and service the LTSP products.
Page 10: Storage And Use Conditions
LTSP | USER MANUAL This label is used to identify the part number and serial number of the product and contain some basic information on power consumption and current draw. A box label example is shown in Fig- ure 1. A cable tag label example is shown in Figure 2. Figure 1: Example of box label.
Page 11 CAUTION: If used outside of the speciﬁed temperature range, the expected life of the product might consistently decrease. Opto Engineering® will not be re- sponsible for product life reduction due to excessive thermal stress.
Page 12: Photobiological Safety
LTSP | USER MANUAL 3.4 Photobiological safety LTSP series has been tested against EN 62471:2008 (photobiological safety of lamps and lamp system). The norm classiﬁes LED lightings in 4 distinct groups, according to their hazardousness degree. For LTSP series, the risk group is reported in Table 5.
Page 13: Getting Started
LTSP | USER MANUAL 4 GETTING STARTED 4.1 Overview LTSP products are high power LED spotlights with integrated electronics. LTSP LED spotlights are designed to operate in both continuous and pulsed mode with an easy hardware interface. Also the boosted mode is allowed, which offers the possibility to have in- creased continuous power delivered for a time duration up to 4.2 Accessories As schematized in Table...
Page 14 LTSP | USER MANUAL Parameters Value Thickness Transmission Degree of polarization 99.98 Extinction ratio < 0.01 Spectral range Table 7: Technical speciﬁcations of the additional accessory polarizing ﬁlter PLLTSP50. v1.2 - eng...
Page 15: Technical Specifications
LTSP | USER MANUAL 5 TECHNICAL SPECIFICATIONS 5.1 LED color The product is available with different LED color options depending on the speciﬁc model. In Table you will ﬁnd the correspondence between the model suﬃx and the color with its peak wave- length.
Page 16: Connectors And Pinout
LTSP | USER MANUAL 5.2 Connectors and pinout The M12 straight plug male connector is schematized in Figure in order to show the pins. The functionality of the pins are shown in Table 9. Figure 5: Scheme of the connector pinout (device side). Standard Power + Analog dimming...
Page 17: Electrical Specifications
LTSP | USER MANUAL 5.3 Electrical speciﬁcations The voltage supported by the pins in Figure for the standard variant device are: Voltage 1: Power V (Maximum Working voltage) V (Absolute Maximum Ratings) 2: NPN V (Absolute Maximum Ratings) 3: GND Ground 4: PNP V (Absolute Maximum Ratings)
Page 18: Operating Modes
LTSP | USER MANUAL 5.6 Operating modes The LEDs can operate in three different modes: the continuous mode, the boosted mode and the strobe mode that are schematized in Figure and described more precisely in the following sec- tions. Figure 6: LED power delivered in the three modalities. The time scale of the strobe mode is different from the other ones.
Page 19: Continuous Mode
LTSP | USER MANUAL 5.6.1 Continuous mode Continuous operations are available with the possibility of delivering continuous electrical power on the LED. In order to select the -continuous mode, there are two different options: 100% 1. the pin NPN must be kept at N P N 2.
Page 20: Boosted Mode
LTSP | USER MANUAL 5.6.2 Boosted mode In boosted mode, the LEDs are allowed to be slightly overpowered compared to the continuous mode ( of the power), forcing a use with shutdown after a time interval on the order of 200% 30 60 s to avoid excessive overheating of the device.
Page 21: Strobe Mode
LTSP | USER MANUAL 5.6.3 Strobe mode Operations in strobe mode are available with the possibility of delivering pulsed electrical power on the LEDs (about % of peak power with respect to the continuous mode power). When V or V, the LEDs are turned on for a time duration that corresponds to >...
Page 22 LTSP | USER MANUAL Voltage 1: Power 2: NPN Start: V (for pulse duration) 0 < V N P N 3: GND Ground 4: PNP 5: Analog Voltage 1: Power 2: NPN 3: GND Ground 4: PNP Start: V (for pulse duration) 3 <...
Page 23: Signal Timing
LTSP | USER MANUAL 5.6.4 Signal timing Figure 8: Scheme of the input trigger signal and of the corresponding LED output. For strobe mode and boosted mode, let’s refer to Figure for the deﬁnitions of . The of f period is .
Page 24: Analog Regulation Use
LTSP | USER MANUAL 5.6.5 Analog regulation use The electrical power delivered on the LED in continuous mode can be regulated with power mod- ulation by means of the connection of the Pin 5 (analog input) to an input voltage 100% V, without using the PNP and NPN input signals.
Page 25: Status Led
LTSP | USER MANUAL 5.7 Status LED A RGB-LED, placed on the outer surface of the device, indicates the system status with the following color legend. Color Status Orange Idle (for all modalities: power supply on, but no inputs) Green PNP/NPN active (for continuous mode and for strobe mode during the pulse) Purple Boosted mode active (i.e.
Page 26: I/O Circuitry
LTSP | USER MANUAL 5.8 I/O circuitry 5.8.1 NPN input Figure 10: Scheme of the NPN input. The NPN logic input scheme is depicted in Figure 10. Please note that the NPN input is in pull-up conﬁguration. Thus, it could be a current source with respect to the controller connected. v1.2 - eng...
Page 27: Pnp Input
LTSP | USER MANUAL 5.8.2 PNP input Figure 11: Scheme of the PNP input. The PNP logic input scheme is depicted in Figure 11. Please note that the PNP input is a current sink with respect to the controller connected. v1.2 - eng...
Page 28: Analog Dimming Input
LTSP | USER MANUAL 5.8.3 Analog dimming input Figure 12: Scheme of the analog dimming input. The analog dimming input scheme is depicted in Figure 12. The DC input impedance is = 11.5 . A low-pass ﬁlter (cut-off frequency KHz) cuts high-frequency input signals. Ω...
Page 29 LTSP | USER MANUAL Appendix A Depending on the lens variant and the color of the speciﬁc device model, the values and the behav- ior of the irradiance as a function of the working distance are different. The plots of the measured irradiance curves, distinguishing by lens model and use mode, are shown in Figure 13-16.
Page 30 LTSP | USER MANUAL Figure 14: Irradiance curves as a function of the working distance for LTSP50-X-30L. v1.2 - eng...
Page 31 LTSP | USER MANUAL Figure 15: Irradiance curves as a function of the working distance for LTSP50-X-60L. v1.2 - eng...
Page 32 LTSP | USER MANUAL Figure 16: Irradiance curves as a function of the working distance for LTSP50-X. v1.2 - eng...
Page 33 LTSP | USER MANUAL Appendix B The images of the beam transverse sections at different working distances, as well as the intensity proﬁles Gaussian ﬁt, allow one to verify how the degree of spatial homogeneity and the spot size vary with distances. For the estimation of the spot size it is possible to consider the quantity that is the radial distance in the transverse plane at a speciﬁc working distance within which the of the total spot energy is contained.
Page 34 LTSP | USER MANUAL Figure 18: Homogeneity heatmaps of the LTSP50-W. Notice that the sizes of the shown window are different from the other variants. v1.2 - eng...
Page 35 LTSP | USER MANUAL Spot size for LTSP50-W-YYL Figure 19: Vertical and horizontal normalized intensity proﬁles with Gaussian ﬁt ( = Ae of the LTSP50-W-YYL at working distances mm for all the lens variants. The wd = 300, 500, 1000 degree of superposition of the vertical and horizontal proﬁles is a measure of the goodness of the circular symmetry of the spot.
Page 36 LTSP | USER MANUAL LTSP50-W-YYL Light cone @300 @500 @1000 angle LTSP50-W-10L 68 mm 115 mm 230 mm LTSP50-W-30L 88 mm 145 mm 292 mm LTSP50-W-60L 176 mm 292 mm 583 mm LTSP50-W 240 mm 400 mm 802 mm Table 17: Typical values of the light spot at different working distance wd = 300, 500, 1000 is the radial size within which the 80% of the total energy of the spot at a transverse plane placed at the speciﬁc working distance...
Page 37 LTSP | USER MANUAL Homogeneity for LTSP50-X-10L Figure 21: Homogeneity heatmaps of the LTSP50-X-10L for all color variants in order to show how homogeneity and size of the light beam spot scales with the working distance. v1.2 - eng...
Page 38 LTSP | USER MANUAL Spot size for LTSP50-X-10L Figure 22: Vertical and horizontal normalized intensity proﬁles with Gaussian ﬁt ( = Ae of the LTSP50-X-10L at working distances mm for all the color variants. The wd = 300, 500, 1000 degree of superposition of the vertical and horizontal proﬁles is a measure of the goodness of the circular symmetry of the spot.
Page 39 LTSP | USER MANUAL LTSP50-X-10L Light cone @300 @500 @1000 angle LTSP50-R-10L 50 mm 84 mm 167 mm LTSP50-G-10L 45 mm 76 mm 152 mm LTSP50-B-10L 73 mm 121 mm 242 mm LTSP50-W-10L 68 mm 115 mm 230 mm Table 18: Typical values of the light spot at different working distance wd = 300, 500, 1000 is the radial size within which the 80% of the total energy of the spot at a transverse plane placed at the speciﬁc working distance...
