Summary of Contents for Unimac TOLEGVUMCAXX1
- Page 1 Engraving Tool User Manual [Revision 2.0 September 2015] RETAIN THIS MANUAL FOR FUTURE REFERENCE PLEASE READ THIS MANUAL CAREFULLY BEFORE USE...
-
Page 2: Table Of Contents
Engraving Tool Table of Contents SAFETY SIGNS ............................ 1 GENERAL APPLIANCE SAFETY WARNINGS ................... 2 Work Area Safety ........................2 Electrical Safety ........................2 Personal Safety ........................2 Power Tool Use and Care ..................... 3 Additional Safety Rules for the Electric Engraver ..............3 LAYOUT DIAGRAM ..........................4 INSTALLING AN ENGRAVER TIP ......................4 OPERATION ............................4... -
Page 3: Safety Signs
Engraving Tool Safety Signs Before use, read this manual carefully. Hearing, sight and respiratory protective gears must be worn. Wear safety gloves. Waste electrical and electronic equipment (WEEE), should not be disposed of with household waste. Please recycle where facilities exist. Check with your local council for recycling advice. Danger;... -
Page 4: General Appliance Safety Warnings
Engraving Tool General Appliance Safety Warnings WARNING! Read all safety warning and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and /or serious injury. Work Area Safety 1. Keep work area clean and well lit. Cluttered and dark areas increase risk of accidents. 2. -
Page 5: Power Tool Use And Care
Engraving Tool Power Tool Use and Care 1. Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it is designed. 2. -
Page 6: Layout Diagram
Engraving Tool Layout Diagram No. Description ON/OFF Switch Engraving Tip Stroke Adjustment Dial Release Screw Power Cord Installing an Engraver Tip WARNING! Disconnect the engraver from the power supply before making any adjustments or maintenance procedures. Loosen the release screw (4) by turning it anticlockwise with a flat head screwdriver. Insert the tip (2) through the centre of the cavity, ensuring the tip fully enters the housing. -
Page 7: Adjusting The Depth Of Engraving
Engraving Tool Before using the engraver you must ensure there is an engraving tip installed. Connect the engraver plug to the power supply. While holding the engraver firmly, push up on the on/off switch (1) with your thumb. NOTE: To turn the tool on, press the small ON/OFF Switch (1) upwards to the (I) position. To turn the tool off, push the ON/OFF Switch (1) down to the (O) position. - Page 8 ©2015 Unimac. All rights reserved. No part of this document, including descriptive content, concepts, ideas, diagrams or images may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying, scanning or recording, or any information storage and retrieval system,...
