Installation, Operating and Service Instructions for
Lancer
Models:
• LCR-2-038
• LCR-3-068
• LCR-4-102
• LCR-5-136
• LCR-6-170
Manual Contents
Read Before Proceeding . . . . . . . . . . . . . . . . . . . . . . . . . 3
3. Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4. Locating Boiler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
5. Preparing Boiler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
6. Venting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
7.
Water Piping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
8. Gas Piping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
9. Electrical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
10. System Start-up and Checkout . . . . . . . . . . . . . . . . . . . 20
11. Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
12. Before Leaving Jobsite . . . . . . . . . . . . . . . . . . . . . . . . . . 26
13. Service and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . 27
14. How it Works . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
15. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
16. Service Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Appendix C Low Water Return Temperature . . . . . . . . . . . . 43
Appendix D High Altitude Instlalation . . . . . . . . . . . . . . . . . 45
Read these instructions carefully before installing. This boiler must only be installed, serviced, or repaired
by a qualified installer, service agency or gas supplier. Improper installation, adjustment, alteration, service,
or maintenance can cause severe personal injury, death, or substantial property damage. For assistance or
additional information, consult a qualified installer, service agency or gas supplier.
111956-02 - 3/24
Attention Installer - Affix these instructions
adjacent to boiler. Provide model number and
serial number when seeking information and
support.
Attention Building Owner - Retain these
instructions for future reference. Contact a
qualified installer, service agency or gas
Page
supplier for all issues and support.
!
WARNING
• Water Boiler
• Cast Iron
• Chimney Vent
• Gas Fired
!
WARNING
9700609
