RONDINI SP 500 Manual

Hide thumbs
1
2
3
4
5
6
7
8
9

Advertisement

Table of Contents

1 - How to use the machine
The spreader cannot be used for other purposes than those ones for which had
been designed.
The liability is null and void in case of damages occurred when the machine is
used for different applications than those ones specified by the manufacturer.
The way of operating the machine implies also to:
Follow the operative prescription, maintenance and repair given by the
manufacturer,
The use of original parts and accessories advised by the manufacturer.
The spreader must be operated and repaired by skilled operators who are
familiar with the way of using the machine. Said operators must be also aware of
the dangers that can arise along the use of the machine.
The operator is requested to strictly follow the rules concerning the:
accidents prevention
labour safety rules
circulation on public roads.
The operator must strictly follow the warnings stuck on the machine.
RONDINI SP 500
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SP 500 and is the answer not in the manual?

Questions and answers

Summary of Contents for RONDINI SP 500

  • Page 1 RONDINI SP 500 1 - How to use the machine The spreader cannot be used for other purposes than those ones for which had been designed. The liability is null and void in case of damages occurred when the machine is used for different applications than those ones specified by the manufacturer.
  • Page 2 For whatever modification worked out on the machine by the user or by whatever person without the written permission of the manufacturer, the liability is born by the machine's owner. A) The noise level created by the machine whilst working is less than 80 dB. Prior operating and setting at work the unit machine-tractor, be sure of its conformity with the rules concerning the safety of labour and the road traffic code.
  • Page 3 16. Do not leave the operating seat while the tractor is still moving. 17. The speed and the way of driving must always be according to the ground. In all cases do not perform sudden direction changes. 18. The steering uniformity, tractor adhesion, road holding and the efficiency of the braking devices are influenced by the following factors: weight and nature of the connected machine, ballasting of the front axle and the state of the ground or the cobblestone paving.

  • Page 4: Moving Parts

    5. During the transportation the hoisting arms must be secured by means of stiffening rods as to prevent oscillations and lateral rocking of the machine. 6. When the machine is not to be transported in hoisted position, block the booster controlling lever. 4 - Moving Parts (P.T.O.

  • Page 5: Setting At Work

    disengage the power take off, switch off the engine and remove the starting key from the panel. 2. Periodically check the tightening of nuts and screws. Tighten them if it were necessary. 3. Prior performing maintenance operations on a machine in raised position prop it by means of proper means.
  • Page 6 To preserve the joint shaft in a good working state: (see figure below) Do not overcome the joint working angular position of 25 (1). Check that the length of the joint shaft suits your tractor. Let a clearance of 3 cm at each end (2). The rotation speed must be of 540 r.p.m.

  • Page 7: Maintenance & Preservation

    The Diagram below shows the SP500's Spreading Rate Click on the image for a large screen view B - Width adjustment The spreader had been designed to get a good fertilizer distribution on the ground. To get good results it is necessary to reach the following conditions: Keep the power take off rotational speed at 540 r.p.m.
  • Page 8 A- Washing procedure: advices The spreader is an agricultural implement whose maintenance is difficult to perform. It is constantly submitted to the worst conditions: Chemical etching: potassium, phosphoric acid, nitrogen. Mechanical damages: granulated abrasion, shocks and scoring. Weather damages: rain, close to the sea, inclemency of the weather. High pressure washing: hight pressure and too close to the machine.

  • Page 9: 10 - Technical Specifications

    after the first 30 hours of operation and then after each 150 hours of operation by means of SAE 85 W6140 oil. 10 - Technical Specifications Model SP500 Capacity 350 lt. Max. Carrying Capacity 480 kg Loading Height 1,15 mtr Width 1,20 mtr Empty Weight...
