Summary of Contents for AEROKLAS CANALUMODTRI24
- Page 1 Assembly & Installation Guide Product: Aluminium Canopy Vehicle: Mitsubishi Triton Dual Cab 2024+ Part No. CANALUMODTRI24 File: CANALUMODHIL Page 1 of 14 04/09/2024...
-
Page 2: Parts List
Assembly & Installation Guide Product: Aluminium Canopy Vehicle: Mitsubishi Triton Dual Cab 2024+ Part No. CANALUMODTRI24 Parts List Part Description Image Roof Panel Carton 1 Front Panel Left Side Panel Right Side Panel Carton 2 Rear Door File: CANALUMODHIL Page 2 of 14... - Page 3 Assembly & Installation Guide Product: Aluminium Canopy Vehicle: Mitsubishi Triton Dual Cab 2024+ Part No. CANALUMODTRI24 Part Description Image Left Rear Door Bracket Right Rear Door Bracket 6g x ½” Flat Head Self Taping Screw 6g x 3/8” Flat Head Self Taping Screw...
-
Page 4: Tools Required For Installation
Product: Aluminium Canopy Vehicle: Mitsubishi Triton Dual Cab 2024+ Part No. CANALUMODTRI24 Rear Rail Guard Important Information • Read instructions completely & carefully before assembly & installation • Use only tools recommended in this guide • Use only the hardware that is provided •... - Page 5 Assembly & Installation Guide Product: Aluminium Canopy Vehicle: Mitsubishi Triton Dual Cab 2024+ Part No. CANALUMODTRI24 Canopy Assembly 1. Assemble Rear Door to Roof Panel Rear Door Brackets File: CANALUMODHIL Page 5 of 14 04/09/2024...
- Page 6 Assembly & Installation Guide Product: Aluminium Canopy Vehicle: Mitsubishi Triton Dual Cab 2024+ Part No. CANALUMODTRI24 2. Assemble Side Panel Note: Lift up rear door before sliding side panel into side roof frame File: CANALUMODHIL Page 6 of 14 04/09/2024...
- Page 7 Assembly & Installation Guide Product: Aluminium Canopy Vehicle: Mitsubishi Triton Dual Cab 2024+ Part No. CANALUMODTRI24 3. Assemble Front Panel Front Panel Brackets Note: Pre-assemble fasteners by hand then tighten by tool 5mm Allen Key 10mm File: CANALUMODHIL Page 7 of 14...
- Page 8 Assembly & Installation Guide Product: Aluminium Canopy Vehicle: Mitsubishi Triton Dual Cab 2024+ Part No. CANALUMODTRI24 4. Connect Wiring Front Rear File: CANALUMODHIL Page 8 of 14 04/09/2024...
- Page 9 Assembly & Installation Guide Product: Aluminium Canopy Vehicle: Mitsubishi Triton Dual Cab 2024+ Part No. CANALUMODTRI24 5. Securing Side Panel to Roof Front Corner Cover Note: Pre-assemble fasteners by hand then tighten by tool Rear Corner Cover 13mm Connect Brake Light...
- Page 10 Assembly & Installation Guide Product: Aluminium Canopy Vehicle: Mitsubishi Triton Dual Cab 2024+ Part No. CANALUMODTRI24 6. Assemble Water Channel Water Channel Note: Pre-assemble fasteners by hand then tighten by tool 12mm 10mm File: CANALUMODHIL Page 10 of 14 04/09/2024...
- Page 11 Assembly & Installation Guide Product: Aluminium Canopy Vehicle: Mitsubishi Triton Dual Cab 2024+ Part No. CANALUMODTRI24 7. Attach Front Corner Cover Clean surface before applying adhesive tape 8. Attach Rear Corner Cover Clean surface before applying adhesive tape File: CANALUMODHIL...
-
Page 12: Canopy Installation
Assembly & Installation Guide Product: Aluminium Canopy Vehicle: Mitsubishi Triton Dual Cab 2024+ Part No. CANALUMODTRI24 9. Apply Foam Tape Apply foam tape to tub Apply foam tape to underside of canopy 10. Canopy Installation • Minimum of four (4) people or use of a mechanical aid used to lift/lower canopy onto tub. - Page 13 Assembly & Installation Guide Product: Aluminium Canopy Vehicle: Mitsubishi Triton Dual Cab 2024+ Part No. CANALUMODTRI24 12. Installing Gas Struts File: CANALUMODHIL Page 13 of 14 04/09/2024...
- Page 14 Assembly & Installation Guide Product: Aluminium Canopy Vehicle: Mitsubishi Triton Dual Cab 2024+ Part No. CANALUMODTRI24 13. Connecting Plug & Play Harness Plug & Play Harness File: CANALUMODHIL Page 14 of 14 04/09/2024...
