WARWICK AIR DRIVEAWAY AWNING/ LOW MP9559
USER GUIDE
Please read this user guide before attempting to set up your Air Driveaway
Awning.
Follow the user guide carefully and keep for future reference.
A copy of the user guide is also available on our website
www.maypoleltd.com
1 |
P a g e

Advertisement

loading
Need help?

Need help?

Do you have a question about the MP9559 and is the answer not in the manual?

Questions and answers

Related Manuals for MayPole MP9559

Summary of Contents for MayPole MP9559

  • Page 1 WARWICK AIR DRIVEAWAY AWNING/ LOW MP9559 USER GUIDE Please read this user guide before attempting to set up your Air Driveaway Awning. Follow the user guide carefully and keep for future reference. A copy of the user guide is also available on our website www.maypoleltd.com...

  • Page 2: Before Use

    WARWICK AIR DRIVEAWAY AWNING/ LOW MP9559 USER GUIDE WARNING – GENERAL SAFETY • Not to be used in strong winds and extreme weather conditions. • If using stepladders or a platform to set up the driveaway awning you will be working at height &...

  • Page 3: Pitching Instructions

    WARWICK AIR DRIVEAWAY AWNING/ LOW MP9559 USER GUIDE PITCHING INSTRUCTIONS Remove the Awning from the carry bag and place flat on the ground. Ensure the dual beading faces the vehicle. The awning has a 4mm & 6mm dual beading sewn into it. Choose the correct beading size for your awning channel and slide it into the awning channel on your vehicle.
  • Page 4 WARWICK AIR DRIVEAWAY AWNING/ LOW MP9559 USER GUIDE Connect the large adaptor to the hand pump: Insert the adaptor into the top cap on an air valve: Inflate the air beam to approx 6-7 PSI. Once inflated; remove the adaptor from the valve and securely tighten the top cap.
  • Page 5 WARWICK AIR DRIVEAWAY AWNING/ LOW MP9559 USER GUIDE Peg down all pegging points found at the base of the air tubes and side panels. Ensure the awning is tight when pegging so it forms the correct shape. Once on position; peg down all of the guy ropes attached to the awning and fully tension using the adjusters provided.
