Summary of Contents for PRORUN PMC160S
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1.GENERAL MACHINE SAFETY WARNINGS 2.SAFETY INSTRUCTIONS FOR STRING TRIMMER 3.TRANSPORTING AND STORAGE 4.BATTERY AND BATTERY CHARGER 5.SYMBOLS 6.SPECIFICATIONS 7.KNOW YOUR MACHINE 8.BATTERY AND CHARGER OPERATION 9.ASSEMBLY INSTRUCTIONS 10.OPERATION 11.MAINTENANCE AND REPAIR 12.TRANSPORTING, CLEANING, AND STORING 13.TROUBLESHOOTING 14.DISPOSAL 15.EXPLODED VIEW... -
Page 3: General Machine Safety Warnings
1. General machine safety warnings WARNING Read all safety warnings, instructions, illustra- tions and specifications provided with this machine. Failure to follow the warnings and instructions may result in electric shock, fire, and/or serious injuries. Save all warnings and instructions for future reference. The term “machine”... - Page 4 machine may result in personal injury. e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the machine in unexpected situations. f) Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewelry, or long hair can be caught in moving parts.
-
Page 5: Safety Instructions For String Trimmer
fire. Service a) Contact PRORUN Customer Service with questions or issues with this machine. This will ensure that the safety of the power tool is maintained. b) Never service damaged battery packs. Service of battery packs should only be performed by the manufacturer or authorized 2. - Page 6 b) Thoroughly inspect the area for wildlife where the machine is to be used. Wildlife may be injured by the machine during operation. c) Thoroughly inspect the area where the machine is to be used and remove all stones, sticks, wires, bones, and other foreign objects.
-
Page 7: Transporting And Storage
o) Keep all parts of the body away from the trimmer head and trimmer line while the machine is operating. Before you start the machine, make sure the trimmer head and trimmer line are not contacting anything. A moment of inattention while operating the string trimmer may cause entanglement or personal injury from flying debris. -
Page 8: Battery And Battery Charger
Only use original batteries for products and only charge them in an original battery charger. Battery charger ® The battery chargers are only used for charging of PRORUN 60V replacement batteries. – This manual contains important safety and operating instructions for battery charger. - Page 9 Regularly check that the battery charger connection wire is intact – and that there are no cracks in it. Replace the charger if the power supply cord becomes worn or damaged. The power supply cord cannot be repaired or replaced. Never carry the battery charger using the cord and never pull out –...
- Page 10 Battery – Do not dismantle, open or shred secondary batteries. – Keep batteries out of the reach of children. – Do not expose batteries to heat or fire. Avoid storage in direct sunlight. – Do not short-circuit a battery. Do not store batteries haphazardly in a box or drawer where they may short-circuit each other or be short-circuited by other metal objects.
-
Page 11: Symbols
5. SYMBOLS This page depicts and describes safety symbols that may appear on this product. Read, understand, and follow all instructions on the machine before attempting to assemble and operate it. Because a chain saw is a high-speed cutting tool, special Safety Alert safety precautions must be observed to reduce the risk of personal injury. - Page 12 Take the machine, charger, accessories and packaging to Recycling an approved disposal site for environmentally friendly recycling. Symbols on the product or its packaging indicate that this product cannot be handled as domestic waste. This product Waste must be deposited at an appropriate recycling facility. Use and store charger only indoors in dry rooms.
-
Page 13: Specifications
6. SPECIFICATIONS Machine model PMC160S Voltage DC 60V Motor type BLDC Cutting device of Brush cutter & Grass trimmer Maximum speed of output shaft 6100 RPM (high), 4600 RPM (low) 17 inches (440 mm) Cutting width Weight (without battery) Max. 10.8 lbs (4.9 Kg) Diameter or cutting line 0.80 in or 0.095 in (2.4 mm or 2.0 mm) -
Page 14: Know Your Machine
7. KNOW YOUR MACHINE 1. Harness 11. Front handle 2. Locking nut 12. Barrier bar 3. Bottom protecting cap 13. Suspension ring 4. Bottom clamping plate 14. Speed switch 5. Metal blade 15. Trigger lock-out 6. Top clamping plate 16. Variable-speed switch trigger 7. -
Page 15: Battery And Charger Operation
This section describes the battery and battery charger safety for your battery product. Only use PRORUN original batteries for PRORUN products and only charge them in an original battery charger from PRORUN. The batteries are software encrypted. 1. Electric plug 5. - Page 16 The battery is ok, but temperatures are between 41 °F (5 °C) and flashing red. may be experiencing temperature deviation. 113 °F (45 °C). Wait the battery cool down. Charger LED Battery is damaged. Contact PRORUN Customer Service. always light red. Charger is damaged.
-
Page 17: Assembly Instructions
9. ASSEMBLY INSTRUCTIONS Unpacking This product requires assembly of the adjustable front-assist handle and cutting guard. – Carefully remove the product and any accessories from the box. Make sure that all items listed in the packing list are included. – Inspect the product carefully to make sure that no breakage or damage occurred during shipping. –... -
Page 18: Fitting The Guard Extension
Fitting the guard extension WARNING: The guard extension shall always be fitted when using the trimmer head and combination guard. The guard extension shall always be removed when using the grass blade and combination guard. - Hook the blade guard/combination guard onto the fitting on the shaft and secure with the bolts. - Page 19 Brush Cutter Blade Assembly Fit the top clamping plate (B) on the output shaft. – Turn the blade shaft until one of the holes in the top clamping plate aligns with the corresponding hole in the top protecting cap. – Insert a locking pin or screwdriver, (A, not included) in the hole to lock the shaft from rotating.
-
Page 20: Operation
10. OPERATION Install and remove the battery pack – Align the raised ribs of the battery pack with the mounting slots in the string trimmer’s battery port. – Slide the battery pack forward into the string trimmer until you hear the release button make an audible click. - Page 21 Correct height Adjust the shoulder strap so that the cutting attachment is parallel to the ground. Correct balance Let the cutting attachment rest lightly on the ground. Adjust the position of the suspension ring to balance the string trimmer or brushcutter correctly. •...
-
Page 22: Maintenance And Repair
11. MAINTENANCE AND REPAIR – Correct maintenance is essential to maintain the original efficiency and safety of the machine over time. – Keep all nuts, bolts, and screws tight to be sure that the machine is in safe working condition. –... -
Page 23: Transporting, Cleaning, And Storing
– If the charger has a malfunction or is damaged: Replace the charger. – If the connecting cable has a malfunction or is damaged: Do NOT use the charger and contact PRORUN Customer Service. WARNING! If the battery pack cracks or breaks, with or without leaks, do not recharge it and do not use. - Page 24 – When transporting the machine by hand, hold it by the front handle with the bump head pointing backwards, opposite the direction in witch you are walking. – When transporting the machine in a vehicle, secure and position the machine to prevent turnover, impact, and damage.
-
Page 25: Troubleshooting
Battery not fully charged. Machine runtime is too Fully charge the battery. Useful life of battery has short. Contact PRORUN Customer Service for been reached or replacement. exceeded. 14. DISPOSAL All toxic materials must be disposed of in a specified manner to prevent contamination of the environment. -
Page 26: Exploded View
15. EXPLODED VIEW... - Page 27 15. EXPLODED VIEW DESCRIPTION QTY. DESCRIPTION QTY. Upper cover decoration Square neck bolt Motor Front handle Screw ST4*16 Barrier bar Big gear wheel Locking knob Small gear wheel Driver shaft Driver shaft Circlip external circlips Connecting shaft Ball bearing screw M4*10 Bearing sleeve Clamping cap Bearing...
- Page 28 17. EXPLODED VIEW...
- Page 29 17. EXPLODED VIEW DESCRIPTION QTY. DESCRIPTION QTY. Bearing Rubber sleeve Aluminum tube Driver shaft guard Protective cover edge strip cutting blade ST screw 4.8x19 ST screw String head assembly Locking bolt clamp \ guard screw M6x25 screw M6x12 Gear box cap washer blade blade retainer...
- Page 30 PRORUN regularly improves our products, and you may find slight differences between your machine and the descriptions contained within this operator's manual. Modifications can be made to the machine without notice and without the obligation to update the manual, providing that the essential safety and functional characteristics remain unaltered.
