Portable DVD Player - User'sGuide Reproductor DVD Portátil - Manual de Usuario Lecteur DVD Portable - Manuel de l'Utilisateur DVP-1560 Model – www.impecca.com...
TABLE OF CONTENTS Important Safety Instructions CD/DVD Disc Handling Package Contents Product Features Main Unit Controls Swivel Screen Panel Getting Started Charging from AC/DC Outlet Charging using Car Charger Adapter Powering Unit & Disc Playback Remote Control Buttons Operating Instructions Connecting to External TV, DVD, VCR or DVR Using Headphones Or External Speakers Advanced System Options...
IMPORTANT SAFETY INSTRUCTIONS Before using the unit, be sure to read all the operating instructions carefully. All the safety & operating instructions should be retained for future reference & all the warnings on the product and in this WARNING: To reduce the risk of 10.
regarding overheating, electrical sofas, cushions, pillows and any hazards, and laser radiation. others which limit the air circula- tion into the ventilation openings. 18. WARNING: If the unit overheats or has a deformed, damaged, or 20. WARNING: The manufacturer, destroyed battery, stop using the distributor, and retailers accept no unit IMMEDIATELY and contact cus- responsibility for battery damage...
PACKAGE CONTENTS Your Impecca Portable DVD Player includes the following: • 15.6” DVD Player • Remote controller with battery • 12V AC/DC Power Adapter • Car Charger • Audio/Video Cable • Ear buds • User Manual and Warranty Card PRODUCT FEATURES •...
MAIN UNIT CONTROLS 26 27 28 24. USB SLOT – Used for con- necting USB Flash Drives 28. AV IN JACK – Used for 25. SD CARD SLOT – Used for using an external DVD, Blu- connecting SD and MMC ray, VCR or DVR players.
GETTING STARTED CHARGING FROM AC/DC OUTLET - The unit has a built-in rechargeable Li-ion polymer battery. Recharge it before use as instructed below: • Insert the small plug from the AC/DC adapter into the DC IN jack on the side of the unit. •...
NOTES: Use the enclosed Car Charger adapter for this product only. Only use the Impecca authorized power adapter included with your DVD player. Using any other power adapter can damage the unit Remove the Car Charger adapter from the outlet when not using for a long period of time.
REMOTE CONTROL BUTTONS Note: Remove the protective plastic tap from bottom of remote before first use. The following guide will help you make the best use of your remote control: 1. STANDBY 2. MUTE- disable sound 3. NUMERIC KEYS 4. SETUP - Enter setup menu 5.
OPERATING INSTRUCTIONS CONNECTING TO EXTERNAL TV, DVD, VCR OR DVR: Your portable DVD player can act as a DVD Player that can be hooked up to a TV for viewing on a larger screen. You can use another video source such as another DVD, Blu-ray player, VCR, or DVR.
ADVANCED SYSTEM OPTIONS Press the SETUP button on the remote control unit to open the set- button again to return to the normal display. GENERAL SETTINGS TV DISPLAY Sets the aspect ratio of the playback image when using an external television display.
ADVANCED SYSTEM OPTIONS VIEWING ANGLE Displays current camera viewing information on the right hand cor- ner of the TFT screen if available on the disc. TV Display Wide Angle Mark OSD Lang Screen Saver Last Memory Mp3 Lyric Set Angle Mark OSD LANGUAGE Change the DVD player system language TV Display...
ADVANCED SYSTEM OPTIONS SCREEN SAVER er inactivity. TV Display Wide Angle Mark OSD Lang Screen Saver Last Memory Mp3 Lyric Screen Saver RESUME PLAYBACK The player will remember the last point read on your disc when this option is enabled; the player will automatically resume playback when the disc is re-inserted.
ADVANCED SYSTEM OPTIONS AUDIO SETTINGS Down-mix: This options allows you to set the analog stereo output of your DVD Player. • LT/RT: Select this option if your DVD Player is connected to a Dolby Pro Logic decoder. • Stereo: Select this option when output delivers sound from only the two front speakers.
ADVANCED SYSTEM OPTIONS PLAYBACK PREFERENCES Audio: Selects a default DVD audio language (if available). Subtitle: Selects a default DVD subtitle language (if available). Disc Menu: Selects a default DVD menu language (if available). -- Preference Page -- TV Type NTSC Audio Subtitle Disc Menu...
ADVANCED SYSTEM OPTIONS PASSWORD SETTINGS Require a password to playback restricted ratings on DVDs. If this setting is disabled, parental settings will not function. -- Preference Page -- TV Type NTSC Audio Subtitle Disc Menu Parental Password Default Password OLD PASSWORD Enter the old password using the remote control (factory setting is 0000), and the cursor will jump automatically to the new password NEW PASSWORD...
ADVANCED SYSTEM OPTIONS CONFIRM PASSWORD trol. If the incorrect password is entered, the cursor will stay in this the correct new password again, the cursor will jump automatically to the OK button. CONFIRM trol to save your new password. Note: If the password has been changed, the parental and disc lock code will also be changed.
CD RIPPING The DVD Player can copy unprotected CDs and MP3 CDs to a USB drive. Before beginning this process, ensure that your USB drive has Using the directional arrow keys on the front panel, select the track(s) pletion as shown below.
SUPPORTED DISCS & FILE FORMATS PLAYABLE DISCS: The unit can play back the following discs: DISC TYPES: chapters, each of which is named by a title and chapter number. Some features of this DVD player might not operate with some DVD discs which are preset.
TECHNICAL SPECIFICATIONS BATTERY OUTPUT: 7.4 VOLTS STORAGE ENVIRONMENTAL CONDITIONS: 1. When storing for up to 6 months: • Temperature between -4°F to 113°F (-20°C to 45°C) • Humidity at 65% ±20% 2. When storing for up to 1 week: • Temperature between -4°F to 113°F (-20°C to 45°C) •...
TROUBLESHOOTING PROBLEM SOLUTION The feature or action cannot be icon appears on screen completed at this time because: doesn’t support the feature (e.g., angles) 2. The feature is not available at the moment. track, or title number which does not exist. Picture is distorted The disc might be damaged.
If you wish to contact us by phone, please be sure to have your model num- ber and serial number ready and call us between 9:00am and 6:00pm ET, at +1 866-954-4440. Keep tabs on Impecca's newest innovations & enter contests via our social network feeds: www.facebook.com/Impecca/ www.instagram.com/impecca/...
TABLA DE CONTENIDO Instrucciones Importantes de Seguridad Manejo De Discos Cd/Dvd Caracteristicas Del Producto Controles De La Unidad Principal Pantalla Giratoria Iniciando Cargando Desde Un Enchufe AC/DC Enciendo La Unidad y Reproduccion Del Disco Botones Del Control Remoto Instrucciones De Operacion Conexion a TV, DVD, VCR O DVR Externos Utilizando Auriculares o Altavoces Externos Opciones Avanzadas Del Sistema...
INSTRUCCIONES IMPORTANTES DE SEGURIDAD Antes de utilizar su unidad, asegúrese de leer cuidadosamente todas las instrucciones de operación. Todas las instrucciones, de seguridad y operativas, deben conservarse para referencia a futuro y todas las advertencias sobre el producto y esta guía deben seguir- ADVERTENCIA: Para reducir el riesgo usar otro adaptador invalidará...
Page 27
19. ADVERTENCIA: No cargue la batería temente en un estuche o le construya temente ventilada. Las ubicaciones un librero o unidad similar, evitando la adecuada ventilación. 17. ADVERTENCIA: Cuando se usa por aire hacia las aberturas de ventila- niños, los padres deben asegurarse ción.
CARACTERÍSTICAS DEL PRODUCTO • Pantalla panorámica de 15.6” de alto contraste y 1280 x 800 dpi de resolución TFT/LCD con 180° y 90° de rotación en am- bos lados para ajustes personalizados • Reproduce la mayoría de los formatos de audio, video y fotografías y es compatible con la mayoría de los DVD, SVCD, MPEG-4 •...
CONTROLES DE LA UNIDAD PRINCIPAL 1. Modo 13. Tecla de USB/SD 2. Subtítulos 14. Repetir 3. Tecla de Audio 15. Tecla de Ajustes 4. Silencio 16. Tecla para Detener 5. Retroceder reproducción 6. Avanzar 17. Tecla para Reproducir/Pausa 7. Tecla para Vol + 18.
CONTROLES DE LA UNIDAD PRINCIPAL 26 27 28 24. Ranura USB – Usada para 27. Conexión AV OUT– Usa- da para conectar una TV externa 25. Ranura de tarjeta SD/MMC 28. Conexión AV IN – Para usar - Usada para conectar reproductores DVD, Blu- Ray, VCR o DVR externos tarjetas SD/MMC...
INICIANDO CARGANDO DESDE UN ENCHUFE AC/DC – La unidad cuenta con una batería recargable integrada de polímero Li-ion, antes de usar recárguela como se indica a continuación: • la conexión DC IN a un lado de la unidad. • Inserte el adaptador AC/DC en un enchufe AC conve- 50/60Hz .
NOTAS: DVD para este producto únicamente. Sólo utilice el adaptador de corriente Impecca autorizado. Al usar otro adaptador de corriente puede dañar la unidad y/o causar una descarga eléctrica, fuego o incluso la muerte. Retire el adaptador Cargador de Auto del enchufe cuando no se utilice por un periodo largo de tiempo.
BOTONES DEL CONTROL REMOTO La siguiente guía le ayudará a tener el mejor uso para su control remoto: STANDBY – Apaga y prende la unidad MUTE – Silencio TECLADO NUMÉRICO SETUP – Ingresar al menú de ajustes Teclas de flecha ARRIBA, ABAJO, IZQUIERDA, DERECHA ENTER/OK –...
INSTRUCCIONES DE OPERACIÓN CONEXIÓN A TV, DVD, VCR O DVR EXTERNOS Su Reproductor DVD Portátil puede actuar como un Reproductor DVD que puede conectarse a una TV para ver el video en una pantalla más grande. Puede utilizar otra fuente de video como otro DVD, Reproductor Blu-ray, VCR o VDR.
OPCIONES AVANZADAS DEL SISTEMA Presione el botón SETUP en el control remoto para abrir el menú derecha) para seleccionar los elementos del menú. Después de cambiar los ajustes deseados, presione nuevamente el botón SE- TUP para regresar a la pantalla normal. CONFIGURACIÓN GENERAL PANTALLA TV Ajusta la relación de aspecto de la imagen reproducida cuando se...
Page 37
OPCIONES AVANZADAS DEL SISTEMA ÁNGULOS DE VISIÓN Muestra la información actual de visión de la cámara en la esquina derecha de la pantalla TFT si es que está disponible en el disco. TV Display Wide Mp3 Lyric Angle Mark OSD Lang Screen Saver Last Memory Mp3 Lyric...
OPCIONES AVANZADAS DEL SISTEMA PROTECTOR DE PANTALLA después de un periodo de inactividad prolongada del DVD. TV Display Wide Mp3 Lyric Angle Mark OSD Lang Screen Saver Last Memory Mp3 Lyric Screen Saver CONTINUAR CON LA REPRODUCCIÓN Cuando está función está habilitada el reproductor recordará el último punto de lectura en su disco;...
OPCIONES AVANZADAS DEL SISTEMA AJUSTES DE AUDIO DOWNMIX Esta opción le permite ajustar la salida análoga estéreo de su repro- ductor DVD. • LT/RT: Seleccione esta opción si su reproductor DVD está • Stereo: Seleccione esta opción cuando la salida entrega soni- do sólo en los dos altavoces frontales -- Speaker Setup Page -- Downmix...
OPCIONES AVANZADAS DEL SISTEMA PREFERENCIAS DE REPRODUCCIÓN Audio: Seleccione el idioma del audio del DVD (si está disponible). Subtítulo: Selecciona el idioma de subtítulos del DVD (si está dispo- nible). Disc Menu: Selecciona el idioma del menú del DVD (si está disponible).
Page 41
OPCIONES AVANZADAS DEL SISTEMA AJUSTE DE CLAVE restringidas en el DVD. Si este ajuste está deshabilitado, los ajustes parentales no funcionarán. -- Preference Page -- TV Type NTSC Audio Subtitle Disc Menu Parental Password Default Password CLAVE ANTERIOR Ingrese la clave anterior usando el control remoto (el valor de fábri- ca es 0000) y el cursor brincará...
OPCIONES AVANZADAS DEL SISTEMA CONFIRMAR CLAVE remoto. Si se ingresa una y incorrecta, el cursor se quedará en este campo y usted deberá ingresar la clave correcta. Una vez que se ha ingresado la clave correcta el cursor brincará automáticamente al botón OK.
DISCOS Y FORMATOS DE ARCHIVOS COMPATIBLES DISCOS REPRODUCIBLES La unidad puede reproducir los siguientes discos: TIPOS DE DISCO: La información en la mayoría de los DVD está dividida en secciones llamadas uno de los cuales se nombran por un título y número de capítulo. Algunas funciones de este reproductor DVD pueden no tablecidos.
ESPECIFICACIONES TÉCNICAS SALIDA DE LA BATERÍA: 7.4 volts. CONDICIONES AMBIENTALES PARA ALMACENAJE: 1. Cuando lo almacene hasta por 6 meses: • Temperaturas entre -4°F a 113°F (-20°C a 45°C) • Humedad en 65% ±20% 2. Cuando lo almacene hasta por 1 semana •...
SOLUCIÓN DE PROBLEMAS PROBLEMA SOLUCIÓN Aparece en la pan- La función o acción no puede ser completada en talla el ícono ø porta esta función (i.e. ángulos) 2. La función no está disponible en este momento 3. Ha solicitado un número de capítulo, La imagen se ve El disco puede estar dañado.
9:00am y las 6:00pm hora del Este, al +1 866-954-4440. Manténgase al tanto de las innovaciones más recientes de Impecca y participe en concursos por medio de nuestras redes sociales.
® ; ha recibido servicio por un centro de reparación defecto de fábrica, dentro de un (1) año de la no autorizado por Impecca ® ; no ha sido mantenido u fecha de la compra original, Impecca ® reparará...
Page 49
TABLE DES MATIÈRES Consignes de sécurité importantes Contenu De La Boite Contrôle de l’unité principale Panneau de l’écran pivotant Guide de démarrage Chargement avec la prise de courant AC / DC Chargement avec le chargeur adapté pour la voiture Touches de la Télécommande Mode d’emploi Options de Système Avancés 60-66...
CONSIGNES DE SÉCURITÉ IMPORTANTES Avant d’utiliser l’appareil, veillez à lire toutes les instructions de fonctionnement avec attention. Toutes les consignes de sécurité et d’exploitation devraient être conservé pour une future référence et tous les avertissements sur le produit dans ce mode d’emploi 1.
Page 51
DVD utilise un système laser pour 18. ATTENTION: Si l’appareil sur- contrôles, ces réglages ou les pro- défectueuse, cesser d’utiliser l’appa- reil immédiatement et contacter le radiations laser dangereuses. soutien au service à la clientèle pour les options de réparation. 14.
à votre lec- attention aux égratignures qui teur et disques. empêchent le rayon laser de lire CONTENU DE LA BOÎTE Votre Lecteur DVD portable Impecca comprend les éléments sui- vants: • Lecteur DVD 15.6 • Télécommande avec batterie •...
CARACTÉRISTIQUES DU PRODUIT • Un écran large avec contraste élevé et 1280 x 800 dpi de réso- lution 15.6” TFT / LCD avec des ajustements personnalisés de 1800 et de 900 tournant sur deux côtés. • formats et est compatible avec la plupart des DVD, SVCD, VCD, CD, MP3, MP4 et autre format de disque.
CONTRÔLE DE L’UNITÉ PRINCIPALE 26 27 28 24. PORT USB - Utilisé pour la 28. PRISE AV IN - Utilisé pour un connexion USB avec une clé lecteur DVD externe, Blu-ray, USB. DVR ou un magnétoscope. 25. FENTE CARTE SD Utilisé pour 29.
DÉMARRAGE CHARGE DE LA PRISE AC / DC - L’unité a une batterie polymère Li-ion é ci-dessous: • Insérez la petite prise de l’adaptateur AC / DC dans la prise DC IN sur le côté de l’appareil. • Insérez l’adaptateur AC / DC dans une prise bien située ayant AC 100-240V ~;...
• panneau latéral gauche) le voyant LED bleu restera allumé. NOTES: l’adaptateur d’alimentation autorisé Impecca inclus avec votre lecteur DVD. L’uti- lisation de tout autre adaptateur peut endommager l’appareil et / ou causer un longue période de temps. ALIMENTATION DE L’UNITÉ & LECTURE DE DISQUE •...
TOUCHES DE LA TÉLÉCOMMANDE Le guide suivant vous aidera à faire le meilleur usage de votre télé- commande: MUTE- Silence TOUCHES NUMÉRIQUES SETUP - Entrez dans le menu de confi- guration TOUCHES DIRECTIONNELLES HAUT / BAS / GAUCHE / DROITE ENTER - Sélectionnez les éléments du menu AUDIO - Change la langue audio des...
MODE D’EMPLOI CONNEXION TV externe, DVD, VCR ou DVR: Votre lecteur de DVD portable peut agir comme un lecteur DVD qui peut être utiliser une autre source vidéo comme un autre DVD, un lecteur Blu-ray, un magnétoscope ou un DVR. Des haut-parleurs externes peuvent également être utilisés à...
OPTIONS DE SYSTÈME AVANCÉS Appuyez sur le bouton SETUP de la télécommande pour ouvrir le bas, gauche, droite) pour sélectionner les éléments du menu. Après RÉGLAGES GÉNÉRAUX AFFICHAGE TV d’un écran de télévision externe. • Normal/Ps: une télévision standard «carré» (ratio 4: 3) qui coupe les côtés gauche et droit d’une image grand écran.
OPTIONS DE SYSTÈME AVANCÉS ANGLE DE VISION l’écran TFT si disponible sur le disque. TV Display Wide Angle Mark OSD Lang Screen Saver Last Memory Mp3 Lyric Set Angle Mark LANGUE OSD Changer la langue du système du lecteur de DVD TV Display Wide Angle Mark...
OPTIONS DE SYSTÈME AVANCÉS ÉCRAN DE VEILLE Active ou désactive l’écran de veille après une période prolongée d’inactivité sur le Lecteur DVD. TV Display Wide Angle Mark OSD Lang Screen Saver Last Memory Mp3 Lyric Screen Saver REPRENDRE LA LECTURE Le lecteur se souviendra du dernier point lu sur votre disque lorsque cette option est activée;...
OPTIONS DE SYSTÈME AVANCÉS RÉGLAGES AUDIO Downmix: Cette option vous permet de régler la sortie analogique stéréo de votre lecteur DVD. • LT / RT: Sélectionnez cette option si votre lecteur DVD est connecté à un décodeur Dolby Pro Logic. •...
OPTIONS DE SYSTÈME AVANCÉS LES PRÉFÉRENCES DE LECTURE Audio: sélectionne une langue audio par défaut du DVD (si dispo- nible). Sous-titre: Sélectionne une langue de sous-titrage par défaut du DVD (si disponible). Menu du disque: Sélection de la langue par défaut du menu du DVD (si disponible).
Page 65
OPTIONS DE SYSTÈME AVANCÉS OPTIONS DE MOT DE PASSE Exiger un mot de passe pour lire des parties restreintes sur les DVD. Si ce paramètre est désactivé, les réglages de contrôles parentaux ne fonctionneront pas. -- Preference Page -- TV Type NTSC Audio Subtitle...
Page 66
OPTIONS DE SYSTÈME AVANCÉS CONFIRMEZ LE MOT DE PASSE utilisant les contrôles de la télécommande. Si le mot de passe est incorrect, le curseur restera dans le champ et vous devrez entrer le bon mot de passe. Après avoir entré le nouveau mot de passe cor- rectement, le curseur passera automatiquement sur le bouton OK.
IMPORTER D’UN CD Le lecteur DVD peut copier des CD et des CD MP3 non protégés sur En utilisant les touches directionnelles sur le panneau avant, sélec-...
DISQUES LISIBLES Les données sur la plupart des DVD sont séparées en appelés chapitres, dont chacun est nommé avec un titre et un numéro de chapitres. Certaines caractéris- fonctionnalité ne fonctionne pas comme souhaité, DISC AUDIO numéro. IMPORTANT: pays), l’image peut être déformée ou roulé verticalement. Dans un tel cas, se référer au manuel lecteur po MPEG1, 2 dat, mpg, mpeg...
SORTIE DE LA BATTERIE: 7,4 volts CONDITIONS ENVIRONNEMENTALES POUR LE STOCKAGE: • Température entre -4 ° F à 113 ° F (-20 ° C à 45 ° C) • Humidité à 65% ± 20% 2. Pour un stockage de 1 semaine: •...
Page 70
PROBL È ME SOLUTION La fonction ou l’action ne peut pas L’icône apparaît à l’écran être complété en ce moment parce ou ne prend pas en charge la fonctionnalité (par exemple, les angles) 2. La fonction n’est pas disponible pour le moment. 3.
Page 72
Une fois autorisé, vous devez VENTE ET L’UTILISATION DU PRODUIT. AUCUNE AUTRE ® envoyer le produit au centre de service autorisé Impecca GARANTIE, ORALE OU ÉCRITE, EXPLICITE OU IMPLICITE, dans ses matériaux d’emballage d’origine ou l’équivalent, N’EST DONNÉE.
