Summary of Contents for RUKO R111

Page 1 User Manual R111 CONTACT US FOR MORE TECH SUPPORT +1 (888)892-0155 Mon-Fri 7:00AM - 7:00PM (PST)
Page 2 CONTACT US FOR MORE TECH SUPPORT +1 (888)892-0155 Mon-Fri 7:00AM - 7:00PM (PST) +1(732)207-0697...
Page 3: Table Of Contents
Content 1 Quick Guide 2 Product Introduction 2.1 Product List 2.2 Product Appearance 2.3 Product Charging 3. Ruko Scanner App 3.1 Ruko Scanner Download 3.2 Video Tutorials 3.3 Ruko Scanner Interface 4. RID Module Usage 4.1 RID Serial Number Registration 4.2 Drone Information Binding...
Page 5 2.RID Serial Number Registration Register with the RID Serial Number on the FAA Drone Zone website. 18696000001 3.Drone Information Binding Press the power switch for 3 seconds; Press the settings button for 3 seconds; Copyright ©2024 Ruko All Rights Reserved.
Page 6 After bind is done , pls restart the device SAVE Restart the RID module until the indicator on the right side blinks rapidly. Long press for 3 seconds Note: The binding succeeds only after the device is restarted. Copyright ©2024 Ruko All Rights Reserved.
Page 8: Product Introduction
3. Charging Cable 4. Double-Sided Tape User Manual R111 CONTACT US FOR MORE TECH SUPPORT +1 (888)892-0155 Mon-Fri 7:00AM - 7:00PM (PST) 5. Self-Locking Zip Tie 6. Instruction Manual 7. Adjustable Zip Tie Mount Copyright ©2024 Ruko All Rights Reserved.
Page 9: Product Appearance
R111 User Manual 2.2 Product Appearance The Ruko R111 is a small, lightweight external remote ID broadcast module that allows you to repeatedly change the settings to bind other drone device, which needs remote ID broadcast module requirment. 1.Indicator light 3.Setting...
Page 10 Working Star-searching Completed Indicator Status: the middle light is always on, the right light ﬂashes. Enter Setup: Green light is always on. Setting Indicator Setup Succeeded: Green light ﬂashes quickly. Copyright ©2024 Ruko All Rights Reserved.
Page 11: Product Charging
In the charging state, the indicator will be in red light. When the indicator turns green, it means charging completed. After charging is completed, please remove the charger in time. When using 5V/2A charging plug, it may take about 40 minutes to complete charging. Copyright ©2024 Ruko All Rights Reserved.
Page 12: Ruko Scanner App
R 111 User Manual 3 Ruko Scanner App 3.1 Ruko Scanner Download Scan the QR code to get the download link. Connect the Ruko Scanner App to use R111 remote ID module. The App supports Android 6.0 and above, iOS 10.0.2 and above.
Page 13: Video Tutorials
D r one s a r ound Settings D e vic e 18696000001 Please long press setting button after power on the module Searching drone and display series number Please click series number to enter setting page Copyright ©2024 Ruko All Rights Reserved.
Page 14 Information Editing Bar) Instruction / Video provide Operation Guide Bar the operation guide. Click it to enter the Surrounding Drones Drones around Bar Interface to view the information of surrounding drones. Copyright ©2024 Ruko All Rights Reserved.
Page 15 W eight (g) Editing Bar ********* of your drone. U AS ********* After bind is done , pls restart the device S A VE Display the serial Surrounding number information of Drones Interface surrounding drones. 18696000001 Copyright ©2024 Ruko All Rights Reserved.
Page 16: Rid Module Usage
In order to comply with FAA Declaration of Compliance, the Remote ID Module serial number must be registered with the FAA website. The serial number is available on the device case sticker or on the Ruko Scanner App. 18696000001 18696000001...
Page 17 ③ Fill in "Ruko" for "UAS MANUFACTURER"; ④ Fill in the corresponding "R111" for "UAS MODEL"; ⑤ "REMOTE ID SERIAL NUMBER" can be obtained from the sticker on the device case or from the Ruko Scanner App; ⑥ After ﬁlling in, select "ADD DEVICE".
Page 18: Drone Information Binding
Long press for 3 seconds Press and hold the device setting button. The light on the right side will stay on and the device will enter the setting mode. Long press for 3 seconds Copyright ©2024 Ruko All Rights Reserved.
Page 19 R111 User Manual Enter Ruko Scanner App (using this App requires turning on the Bluetooth function of your phone). D e vic e sea r ch Bluet o o th D r one s a r ound Settings D e vic e...
Page 20 Long press for 3 seconds Power off: Long press the switch for 3 seconds until the indicator light goes out. Note: After setting the information, restart the device to work properly based on the latest binding information. Copyright ©2024 Ruko All Rights Reserved.
Page 21: Rid Module Installation
R111 User Manual 4.3 RID Module Installation The R111 is equipped with Velcro. It can be ﬁxed by Velcro or other means. Attach one Velcro to the RID module; Attach the other Velcro to the drone; Attach the RID module to the drone.
Page 22: Rid Information Broadcasting
FPV drone and other aircraft. 4.4 RID Information Broadcasting The RID module can send broadcast information normally only when the GPS signal is found outdoors. Search time: 90-120s (depending on the environment). Copyright ©2024 Ruko All Rights Reserved.
Page 23 The RID module needs to be installed in an unobstructed place to avoid blocking the GPS signal of the RID module, resulting in the inability to search the GPS signal and broadcast data normally. Copyright ©2024 Ruko All Rights Reserved.
Page 24: Broadcast Data Viewing
Please long p r e s s setting but t on af t er power on the module Sea r ching d r one and displ a y serie s number Please clic k seri e s number t o ent er setting p age 18696000001 Copyright ©2024 Ruko All Rights Reserved.
Page 26: Specification
Model: R111 Working Mode: Bluetooth4 / Bluetooth5 Charging Time: About 40 minutes Working Time: About 5 hours Battery Capacity: 150mAh Operating Voltage: 3.7V Product Size: 34*28*13.5mm / 1.34*1.10*0.53in Product Weight: About 13.5g / 0.48oz Copyright ©2024 Ruko All Rights Reserved.
Page 27: Common Problems And Solutions
RID module module of the drone The App cannot Mobile phone Bluetooth Turn on Bluetooth search for RID permission is not permission and refresh module serial enabled the search list number Copyright ©2024 Ruko All Rights Reserved.
Page 28: Safety Precautions
All instructions and warnings in the manual must be read and followed before assembly, setup or use in order to operate correctly and avoid damage or serious injury. Copyright ©2024 Ruko All Rights Reserved.
Page 29 R111 User Manual Note: This product is suitable for use in consumer-grade drones. RUKO does not assume any responsibility for any damage to drones or other equipment during use, except for the remote ID module. Copyright ©2024 Ruko All Rights Reserved.
Page 30: Fcc Warning
Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help Copyright ©2024 Ruko All Rights Reserved.
Page 31 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Copyright ©2024 Ruko All Rights Reserved.
