TECHNICAL DATA SHEET
AGE GROUP:
PLAYERS:
SIZE (cm):
IMPACT ZONE:
FREE FALL HEIGHT:
MATERIALS:
INSTALLATION:
STANDARDS:
WARRANTY:
GED09 - swing
1. FEATURES
0-12 y
3 max
L:500/W:214/H:218
35 m2
125 cm
metal tubes; metal plates; metal chain, plastic, rubber
anchor / concrete
EN1176-1; EN1176-2+AC
60 m
web:gotinshtain.com
e-mail: office@gotinshtain.com
tel: +359 896 602070
ISO 9001
ISO 14001
Advertisement
Summary of Contents for GOTINSHTAIN GED09
- Page 1 +359 896 602070 ISO 9001 ISO 14001 TECHNICAL DATA SHEET GED09 - swing 1. FEATURES 0-12 y AGE GROUP: PLAYERS: 3 max L:500/W:214/H:218 SIZE (cm): 35 m2 IMPACT ZONE: 125 cm FREE FALL HEIGHT: MATERIALS: metal tubes; metal plates; metal chain, plastic, rubber...
- Page 2 3. IMPACT ZONE - 35 m2 700 см 4. INSTALLATION Concrete Anchor Pole Pole Level 0 mark Anchor plate Shock absorbing layer Shock absorbing layer Reinforcing steel Level 0 Ground Concrete 40/40/40cm Ground 40 cm GED09 - swing TECHNICAL DATA SHEET...
- Page 3 +359 896 602070 5. MATERIALS Constructions They are made of metal tubes and plates, which ensure strength, long-term use, durability and reliability of the equipments. Metal parts are covered by anti-corrosion primer and paint with UV protection.The structures of the facilities are designed according to the requirements of EN 1176-1.
