AWK-3262A Series
Quick Installation Guide
Moxa AirWorks
Version 1.0, September 2024
Technical Support Contact Information
www.moxa.com/support
 2024 Moxa Inc. All rights reserved.
P/N: 1802032620010
*1802032620010*

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AWK-3262A Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Moxa Technologies AWK-3262A Series

  • Page 1 AWK-3262A Series Quick Installation Guide Moxa AirWorks Version 1.0, September 2024 Technical Support Contact Information www.moxa.com/support  2024 Moxa Inc. All rights reserved. P/N: 1802032620010 *1802032620010*...
  • Page 2: Hardware Setup

    Overview The AWK-3262A Series is an Wireless AP/bridge/client with IEEE 802.11ax technology. This Series features concurrent dual-band Wi-Fi data transmissions up to 574 Mbps (2.4 GHz mode) and 1,201 Mbps (5 GHz mode) simultaneously, meeting the speed and flexibility requirements for industrial applications. In addition, the built-in dual band pass filter and the wide-temperature design ensure reliability and continuous operation in harsh environments.
  • Page 3 Panel Layout of the AWK-3262A 1. Grounding screw (M5) 11. Screw holes for wall-mounting 2. Terminal blocks for PWR1, PWR2, relay, DI 1 and DI 2 12. DIN-rail mounting kit 3. Reset button 13. Cable holder screw 4. Antenna connector 2 (RP-SMA) 5.
  • Page 4: Mounting Dimensions

    Mounting Dimensions DIN-rail Mounting When shipped, the metal DIN-rail mounting kit is fixed to the back panel of the AWK-3262A. Mount the AWK-3262A on to a corrosion-free mounting rail that adheres to the EN 60715 standard. STEP 1: STEP 2: Insert the upper lip of the DIN-rail Press the AWK-3262A towards the kit into the mounting rail.
  • Page 5 To remove the AWK-3262A from the DIN rail, do the following: STEP 1: Pull down the latch on the DIN- rail kit with a screwdriver. STEP 2 & 3: Slightly pull the AWK-3262A backwards and lift it up to remove it from the mounting rail.
  • Page 6: Wiring Requirements

    STEP 3: Once the screws are fixed into the wall, insert the four screw heads through the large opening of the keyhole-shaped apertures, and then slide the AWK-3262A downwards (wall mounting) or forwards (ceiling mounting), as indicated to the right. Tighten the two screws for added stability.
  • Page 7 NOTE Do not run signal or communications wiring and power wiring in the same wire conduit. To avoid interference, wires with different signal characteristics should be routed separately. • You can use the type of signal transmitted through a wire to determine which wires should be kept separate.
  • Page 8 Grounding the AWK-3262A Grounding and wire routing help limit the effects of noise due to electromagnetic interference (EMI). Run the ground connection from the ground screw to the grounding surface prior to connecting devices. ATTENTION This product is intended to be mounted to a well-grounded mounting surface, such as a metal panel.
  • Page 9: Terminal Block Pin Assignment

    Terminal Block Pin Assignment The AWK-3262A comes with one 2-pin and one 8-pin terminal block located on the top panel of the device. The terminal block contains dual power inputs, a relay output, and dual digital inputs. Refer to the following figure and table for the detailed pin assignment.
  • Page 10: Wiring The Digital Inputs

    ATTENTION If the AWK-3262A is connected to a motor or other similar type of equipment, be sure to use power isolation protection. Before connecting the AWK-3262A to the DC power inputs, make sure the DC power source voltage is stable. Wiring the Relay Contact The AWK-3262A has one relay output, which consists of the two contacts of the terminal block on the AWK-3262A’s top panel.
  • Page 11: Communication Connections

    Communication Connections 10/100/1000BaseT(X) and 10/100/1000/2500BaseT(X) Ethernet Port Connection The 10/100/1000BaseT(X) and 10/100/1000/2500BaseT(X) ports located on the AWK-3262A’s front panel are used to connect to Ethernet-enabled devices. MDI/MDI-X Port Pinouts Pin 1000/2500B 10/100BaseT( 10/100BaseT( aseT MDI/MDI-X MDI-X TRD(0)+ TRD(0)– TRD(1)+ TRD(2)+ –...
  • Page 12: Specifications

    Color State Description Data is being transmitted over the 2.4 GHz Blinking band with a SNR value of 35 or higher. Client/Client-Router/Slave has established a Wi-Fi connection to an AP/Master with an SNR value of less than 35. Amber Data is being transmitted over the 2.4 GHz Blinking band with an SNR value of less than 35.
  • Page 13 ATTENTION The AWK-3262A is NOT a portable mobile device and should be located at least 50 cm away from the human body. The AWK-3262A is NOT designed for the general public. To ensure that your AWK-3262A wireless network is safe and configured correctly, consult a well-trained technician to assist with the installation process.
  • Page 14: Software Setup

    Software Setup This section covers the software setup for the AWK-3262A. How to Access the AWK Before installing the AWK device (AWK), make sure that all items in the package checklist are provided in the product box. You will also need access to a notebook computer or PC equipped with an Ethernet port.
  • Page 15 Step 5: Choose your country or region. • Select your country or region from the drop-down list and click NEXT. Step 6: Create a user account and password. • Enter the username, password, and email address for your user account and click CREATE. NOTE The username and password are case-sensitive.
  • Page 16 After creating your account, you will be automatically redirected to the login screen. • Step 7: Log in to the device. Enter your username and password and click LOG IN. The device will start initializing, this may take several seconds. Once the warning message has disappeared, you can log in using your username and password.
  • Page 17: First-Time Quick Configuration

    First-time Quick Configuration After successfully accessing the AWK, refer to the appropriate subsection below to quickly set up a wireless network. NOTE Ensure that there are no IP address conflicts when you configure more than one AWK on the same subnet. AP/Client Mode Configuring the AWK as an AP •...
  • Page 18 Step 2: Set up the AWK as an AP. • Click the ADD icon to create a new SSID. On the settings page, configure the SSID Status, SSID, RF Band, RTS/CTS Threshold, and Transmission Rate for the 5 GHz or 2.4 GHz band.
  • Page 19 Configuring the AWK as a Client Step 1: Set the operation mode of the AWK to Client mode. • Go to Wi-Fi  Wireless Settings and select Client from the Operation Mode drop-down list, set the SSID, and click Apply. For more detailed configurations, refer to the AWK-3262A User’s Manual.
  • Page 20 Master/slave Mode Configuring the AWK as a Master Step 1: Set the operation mode of the AWK to Master mode. • Go to Wi-Fi  Wireless Settings and select Master from the Operation Mode drop-down list. Step 2: Set up the AWK as a Master. •...
  • Page 21 On the second SSID Settings screen, configure the SSID Broadcast Status and Security type. From here, you can also copy the configuration over to the second SSID. When finished, click CONFIRM. Configuring the AWK as a Slave Step 1: Set the operation mode of the AWK to Slave mode. •...
  • Page 22 Manual. Certifications FCC Statements Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 23 FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed an operated with minimum distance 20 cm between the radiator & your body IMPORTANT This radio transmitter FCC ID: [SLE-AWK3262A] has been approved by FCC to operate with the antenna types listed below with the maximum permissible gain and required antenna impedance for each antenna type indicated.
  • Page 24 NCC Statements 經型式認證合格之低功率射頻電機,非經許可,公司、商號或使用者均不得擅自變 更頻率、加大功率或變更原設計之特性及功能。 低功率射頻電機之使用不得影響飛航安全及干擾合法通信;經發現有干擾現象時, 應立即停用,並改善至無干擾時方得繼續使用。 前項合法通信,指依電信法規定作業之無線電通信。低功率射頻電機須忍受合法通 信或工業、科學及醫療用電波輻射性電機設備之干擾。 應避免影響附近雷達系統之操作。 KC Statements 이 기기는 업무용 환경에서 사용할 목적으로 적합성평가를 받은기기로서가 정용 환경에서 사용하는 경우 전파간섭의 우려가 있습니다. - 24 -...
