DLI HOBO UX100-014M Manual

HOBO® Single Channel Thermocouple
Data Logger (UX100-014M) Manual
HOBO Single Channel
Thermocouple
Data Logger
UX100-014M
Included Items:
• Command™ strip
• Double-sided tape
• Hook & loop strap
Required Items:
• HOBOware 3.4 or later
• USB cable (included with
software)
• Thermocouple sensor type
J, K, T, E, R, S, B, or N
16211-B
The HOBO Single Channel Thermocouple data logger records temperature in indoor
environments with J, K, T, E, R, S, B, or N type thermocouple sensors (sold separately). Using
HOBOware®, you can easily configure the logger alarm to trip for specific high or low
temperatures. Or, you can set up burst logging in which the logger records data at a different
interval during certain conditions. The logger can also calculate minimum, maximum, average,
and standard deviation statistics. This compact data logger has a built-in LCD screen to monitor
temperature, logging status, battery use, and memory consumption in between readouts.
Specifications
Thermocouple
Type Range
J -210° to 760°C
(-346° to 1,400°F)
K -260° to 1,370°C
(-436° to 2,498°F)
T -260° to 400°C
(-436° to 752°F)
E -260° to 950°C
(-436° to 1,742°F)
R -50° to 1,550°C
(-58° to 2,822°F)
S -50° to 1,720°C
(-58° to 3,128°F)
B 550° to 1,820°C
(1,022° to 3,308°F)
N -260° to 1,300°C
(-436° to 2,372°F)
Logger
Logger Operating Range
Logging Rate
Logging Modes
Memory Modes
Start Modes
Stop Modes
Restart Mode
Time Accuracy
Battery Life
Battery Type
Memory
Download Type
Full Memory Download Time
LCD
Size
Weight
Environmental Rating
Accuracy
±0.6°C (±1.08°F) ± thermocouple
probe accuracy
±0.7°C (±1.26°F) ± thermocouple
probe accuracy
±0.6°C (±1.08°F) ± thermocouple
probe accuracy
±0.6°C (±1.08°F) ± thermocouple
probe accuracy
±2.2°C (±3.96°F) ± thermocouple
probe accuracy
±2.2°C (±3.96°F) ± thermocouple
probe accuracy
±2.5°C (±4.5°F) ± thermocouple
probe accuracy
±1.0°C (±1.8°F) ± thermocouple
probe accuracy
Logging: -20° to 70°C (-4° to 158°F); 0 to 95% RH (non-condensing);
logger accuracy from 0° to 50°C (32° to 122°F)
Launch/Readout: 0° to 50°C (32° to 122°F) per USB specification
1 second to 18 hours, 12 minutes, 15 seconds
Normal, burst, or statistics
Wrap when full or stop when full
Immediate, push button, date & time, or next interval
When memory full, push button, or date & time
Push button
±1 minute per month at 25°C (77°F), see Plot A
1 year, typical with logging rate of 1 minute and sampling interval of
15 seconds or greater
One 3V CR2032 lithium battery
512 KB (208,076 measurements, maximum)
USB 2.0 interface
1 minute, 30 seconds
LCD is visible from 0° to 50°C (32° to 122°F); the LCD may react slowly
or go blank in temperatures outside this range
3.66 x 5.94 x 1.52 cm (1.44 x 2.34 x 0.6 in.)
30 g (1.06 oz)
IP50
The CE Marking identifies this product as complying with all relevant
directives in the European Union (EU).
Resolution
0.03°C (0.06°F)
0.04°C (0.07°F)
0.02°C (0.03°F)
0.03°C at (0.05°F)
0.08°C (0.15°F)
0.08°C (0.15°F)
0.1°C (0.18F)
0.06°C (0.11°F)
