Summary of Contents for Vacmaster SCB0501 01

  • Page 4: Table Of Contents

    ® ® Thank you for purchasing this Vacmaster carpet spot cleaner. Feel confident that with Vacmaster you are obtaining a high-quality product that is engineered for optimal performance. This carpet spot cleaner is suitable for use with liquid materials. FOR YOUR SAFETY: CAREFULLY READ AND UNDERSTAND ALL INSTRUCTIONS.

  • Page 5: Safety Information

    SAFETY INFORMATION READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE USING THIS PORTABLE CARPET SPOT CLEANER. When using the equipment, a few safety precautions must be observed to avoid injuries and damage. Please read the complete operating manual with due care. Keep this manual in a safe place so that the information is always available.
  • Page 6 • Do not unplug by pulling on the cord. To unplug, grasp the plug, not the cord. • Do not use with damaged cord, plug or other parts. • Do not pull or carry by cord, use cord as handle, close a door on cord, or pull cord around sharp edges or corners.
  • Page 7 always place cleaner at bottom of stairs or on floor. Do not place cleaner on stairs or furniture, as it may result in injury or damage. • For additional protection: It is recommended that this carpet cleaner can be used in conjunction with residual current device (RCD) with a rated residual current of 30mA or less.

  • Page 8: Unpacking And Product Features

    UNPACKING AND PRODUCT FEATURES Carry Handle Clean Water Tank Power Button Power Cord Hooks Suction Hose Clean Water Tank Cover Tab Dirty Water Tank Clean Water Tank Cover Dirty Water Tank Cover Tab Hose Cleaning Tool Dirty Water Tank Cover Tough Stain Nozzle Tool Release Button Cleaning Solution...

  • Page 9: Assembly

    ASSEMBLY 1. Align the primary hose storage clip with the bracket as shown (Fig. 1). Slide the hose storage clip downwards until it is secured into place. 2. Align the secondary hose storage clip with the bracket as shown (Fig.2). Slide the hose storage clip downwards until it is secured into place.

  • Page 10: Operation

    OPERATION 1. Filling The Clean Water Tank 1) Remove the clean water tank from the side of the unit. A security latch ( ① ) is positioned to keep the clean water tank in position to avoid unintentional release. The latch will automatically release when the tank is pulled upwards (Fig.

  • Page 11: Emptying The Dirty Water Tank

    3）Plug the power cord into a power outlet. WARNING: If any abnormality/failure occurs, stop using the product immediately and disconnect the power plug. 4) Press the power button to turn the carpet cleaner on (Fig. 10). 5) For spills, first collect any excess liquid before using water/solution. Place the cleaning nozzle towards the front of the spill and slowly pull backwards over the area.

  • Page 12: Maintenance

    MAINTENANCE WARNING: Remove the power cord from the power supply before carrying out any maintenance. 1. Cleaning Exterior 1）Turn off and unplug carpet cleaner. 2）To clean exterior, or to reduce static electricity and dust build-up, wipe outer surface with a clean, damp and soft cloth.

  • Page 13: Troubleshooting

    TROUBLESHOOTING WARNING: To reduce the risk of electric shock, unplug before troubleshooting. PROBLEM POSSIBLE CAUSE SOLUTION Unplugged at power outlet. Plug in firmly to suitable power outlet. Check with a good appliance. Be sure Defective power outlet. the power cord plug is fully plugged The carpet cleaner into an electrical outlet.
  • Page 14 PROBLEM POSSIBLE CAUSE SOLUTION Turn on the carpet cleaner. If hose Hose nozzle will does not spray, prime the pump not spray after Air is trapped in the pump and by lowering the hose down to the filling the clean hose.

  • Page 15: Technical Data

    TECHNICAL DATA Model Number SCB0501 01 Motor 220-240V~50Hz Power Input 500W Clean Capacity 1.6L Net Weight 3.5kg RECYCLING AND DISPOSAL This marking indicates that this product should not be disposed with other household wastes. The machine must be delivered in rigid packaging to avoid damage during transportation. The packaging and the machine itself are manufactured from recyclable materials and should be disposed of accordingly.
  • Page 17 ③ /0.4G /0.3G ① /0.2G ②...
  • Page 18 ④ ⑤ ⑥...
  • Page 20 SCB0501 01 Suzhou Cleva Electric Appliance Co., Ltd. No.8 Ting Rong Street Suzhou Industrial Park, Suzhou Jiangsu Province, China www.cleva-europe.com Made in P.R.C...
