IK-E397-001-GB, Change 1, 03.2024
1
MICROPROCESSOR BASED
ADDRESSABLE CONTROL AND
MONITORING ELEMENT
EKS-3222P
POLON 3000 FIRE DETECTION AND ALARM SYSTEM
_________________________________________________________________________________
INSTALLATION AND MAINTENANCE MANUAL
IK-E397-001-GB
Change I
_________________________________________________________________________________
EKS-3222P Control and Monitoring Element
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Polon-Alfa EKS-3222P
- Page 1 IK-E397-001-GB, Change 1, 03.2024 MICROPROCESSOR BASED ADDRESSABLE CONTROL AND MONITORING ELEMENT EKS-3222P POLON 3000 FIRE DETECTION AND ALARM SYSTEM _________________________________________________________________________________ INSTALLATION AND MAINTENANCE MANUAL IK-E397-001-GB Change I _________________________________________________________________________________ EKS-3222P Control and Monitoring Element...
- Page 2 IK-E397-001-GB, Change 1, 03.2024 The EKS-3222P control and monitoring element covered by the present manual complies with the requirements of the following European Union Directives: Regulation (EU) No 305/2011 of the European Parliament and of the Council of 9 March 2011 laying down harmonised conditions for the marketing of construction products and repealing Council Directive 89/106/EWG;...
-
Page 3: Table Of Contents
Storage and Transport ....................15 9.1. Storage ..............................15 9.2. Transport ............................. 15 List of Drawings Figure 3.1 EKS-3222P dimensions ......................6 Figure 6.1 TEST button access/pressing method ..................12 Figure 7.1 EKS-3222P Sample connection diagram ................. 14 _________________________________________________________________________________ EKS-3222P Control and Monitoring Element... -
Page 4: Purpose
(6÷220) VDC or 230 VAC. The outputs of the EKS-3222P element enable the connection of devices with a current consumption not exceeding 12 A at 230 VAC (starting current max 100 A at max 100 ms or max 250 A at max 50 ms at 230 VAC). -
Page 5: Technical Specifications
From -40 °C up to +70 °C Climate category 40/070/04 Admissible relative humidity Up to 95 % at 40 °C Insulation electrical strength 1500 V IP Rate IP 66 Material and frame colour polecarbonate (PC), grey _________________________________________________________________________________ EKS-3222P Control and Monitoring Element... -
Page 6: Design Description
IK-E397-001-GB, Change 1, 03.2024 Design description The EKS-3222P control and monitoring device is made of a printed circuit board with electronic elements and a set of connectors all placed in a single housing. Wall mounting holes are located in the corners of the frame. Cable entries are in the bottom of the housing. -
Page 7: Principles Of Operation
IK-E397-001-GB, Change 1, 03.2024 Principles of operation Communication between POLON 3000 control panel and the EKS-3222P control and monitoring element is via an addressable two-wire detection line. A unique, fully digital communication protocol allows transfer of any information from the control panel to the element and from the element to the control panel. - Page 8 3 V. The same rules apply to IN HV inputs. If the IN HV outputs or inputs are not used, the position of corresponding jumpers is not relevant. ___________________________________________________________________________________ EKS-3222P Control and Monitoring Element...
-
Page 9: Operating Modes Of The Control Element
(no change, not triggered, triggered), d) continuity monitoring of the cable connected to the control output(off, on), e) group number - (0, 65535), f) number of cycles (0 ÷ 255). _________________________________________________________________________________ EKS-3222P Control and Monitoring Element... - Page 10 Break time – T T ow Triggering mode Definite Cyclic Trigger delay time - T Trigger time – T Break time – T Number of cycles – L L c = 3 T ow ___________________________________________________________________________________ EKS-3222P Control and Monitoring Element...
-
Page 11: Operating Conditions
IK-E397-001-GB, Change 1, 03.2024 Operating conditions Reliable operation of EKS-3222P control and monitoring element depends on proper operating conditions, correct installation and regular periodic inspections. The inspection is carried out in order to determine the proper operation of the element as well as its proper cooperation with the control panel. - Page 12 IK-E397-001-GB, Change 1, 03.2024 Figure 6.1 TEST button access/pressing method ___________________________________________________________________________________ EKS-3222P Control and Monitoring Element...
-
Page 13: Installation Of Control Elements
3000 control panels. (See Operation and Maintenance Manual of POLON-3000 control panel). Connection method of EKS-3222P (2 high-voltage inputs (IN HV), 2 parametric inputs (IN) and 2 high- power outputs (12 A at 230 V) is shown in the Figure 7.1. - Page 14 IN HV2- IN1- Power Controlled device Supply 642 VDC - R3 2 kΩ 750 Ω IN2+ IN2- COM2 Power Supply OFF2 Controlled 4,3 kΩ 230 VAC Device Controlled device Figure 7.1 EKS-3222P Sample connection diagram ___________________________________________________________________________________ EKS-3222P Control and Monitoring Element...
-
Page 15: Safety Conditions
Storage and Transport 9.1. Storage EKS-3222P control and monitoring element should be stored in closed rooms, with no corrosive fumes or gases, at the temperature range from 0 °C to +40 °C, with relative humidity not exceeding 80 % at the temperature of +35 °C. - Page 16 IK-E397-001-GB, Change 1, 03.2024 ___________________________________________________________________________________ EKS-3222P Control and Monitoring Element...
