P900 Door Access Input Output Quick Start
Manual
Revision 1.5 Sep2024

Advertisement

loading
Need help?

Need help?

Do you have a question about the WebENTRA P900 and is the answer not in the manual?

Questions and answers

Summary of Contents for ASIS Technologies WebENTRA P900

  • Page 1 P900 Door Access Input Output Quick Start Manual Revision 1.5 Sep2024...
  • Page 2 P908 8 Doors Controller Revision 1.5 Sep2024...
  • Page 3 Basic Termination Termination points for RS485 reader, door sensor, exit push button, EM lock, PSU, Fire alarm, Tamper alarm, Ethernet connection point to LAN switch. Fire, Tamper Alarm RS485 (DEV1) Power terminal for readers 13.8V Connect to network Terminate Terminate port Door sensor EM Lock...
  • Page 4 Reader & I/O Module Expansion Expand the numbers of door access by adding P918 to the network. Expanding by connecting CANbus2 port of P908 and P918 together. Maximum 3 x P914/8 can be added. Use twisted pair and connect 220 Ohms resistor parallel on P908’s CANbus2 connector.
  • Page 5 Revision 1.5 Sep2024...
  • Page 6 Login to Controller to configure via the default IP address: 192.168.168.101:8000. Default username is manager and password is manager. Scan and select the detected Module ID and save for P918 board in Hardware Modules page of P900 webserver. Connect 1 unit P914 or P918 board at a time to scan. Revision 1.5 Sep2024...
  • Page 7 The Status LED on the P914/8 board will blink slowly in green when correctly save. P904/8 Input 1 – 16 …24 Output 1 – 4 ..12 Wiegand Reader 1 – 4 …8 RS485 Reader 1 – 8 …16 P914/8 P914/8 P914/8 Input 25 –...
  • Page 8 P908K1, configuration consist component of enclosure controller, power supply and backup battery. The configuration is reconfigurable based on requirement. Revision 1.5 Sep2024...
  • Page 9 Termination points for 8 Door In & Out Reader DOOR 1 DOOR 2 DOOR 3 DOOR 4 TERMINATION Exit button Door Sensor Exit button Door Sensor Exit Button Door Sensor Exit Door Sensor Button POINT for INPUT INP01, GND INP02, GND INP03, GND INP04, GND INP05, GND...
  • Page 10 Important Note to installer 1. Fire alarm input is active and cannot be disabled. If not in use, short the fire alarm input. 2. Box tamper switch is active and cannot be disabled. If not in use, short the tamper switch input.

This manual is also suitable for:

Webentra p908
