- Page 1 RTK Module Quick Start Guide Version 1.0...
- Page 2 To Users Dear user, thank you for choosing XAG products. For safety purposes and the best experience possible, XAG recom- mends reading through the Quick Start Guide and Disclaimer con- tained in this document before using the RTK Module. Contact Us If you have any questions about this document, please contact our Technical Support via email: info@xa.com...
-
Page 3: List Of Items
List of Items Please carefully check whether the product contains all the items listed below and contact your dealer if there are any missing items. Differential Positioning Module Assembly Insert the Differential positioning module onto the top of the ACS2 ControlStick until you hear “click”, indicating the module has been installed correctly. -
Page 4: Operational Instructions
Operational Instructions 1. Select “Field” in the Menu located in the XAG AGRI APP and click “+” to create a new field with a name and specified type. - Page 5 2. Click the “Mode” icon in the upper left corner, then select the surveying method as “Rover” and select “ACS2” to connect the rover.
- Page 6 3. Click the icon on the right to view the parameters of the rover, and then click "STATION" to select a station manually. 4. For a new field, there are four surveying functions available: Boundary, Obstacle, Restricted ZONE, and MARKER.
- Page 7 Note ACS2 ControlStick with firmware version of ACS2_1.1.1.6 or above, it requires user to press and hold to enter “Mapping Mode” to map via APP or remote controller.
- Page 8 The three function buttons in each mode (left figure below) corre- spond with the three buttons of the ACS2 ControlStick (right figure below). The figure below shows a marked plot:...
- Page 9 XAG servers during use. In the event that the flight records and data fail to be uploaded and saved and XAG fails to analyze the flight records and data due to any reason of the user, XAG will not assume any responsibility.
- Page 10 Strong safety awareness is required to operate this product. This product is not suitable for children. Do not use parts that are not provided or recommended by XAG with this product. Please strictly follow XAG’s instructions to install and use the product.
- Page 12 Certificate of Inspection This product has passed inspection. info@xa.com Visit our website for more information @XAGofficial www.xa.com/en @XAG_official This Guide is subject to upgrade @XAG Official without prior notice.
