Summary of Contents for Lumenier CINEQUADS QAV-PRO VIER
- Page 1 product manual...
- Page 2 parts needed for the assembly isolation camera plate lipo strap top plate bottom plate core plates isolation camera dji O3 air unit crossfire M3x30mm nylon lipo pad XT-60 universal action mount heat sink set horizontal standoff landing feet connector camera mount pigtail mount M3x25mm...
- Page 3 M3x6mm top plate assembly screws M3x5mm screws top plate M2.5x8mm screws isolation camera mount XT-60 connector M3x30mm standoff Start the assembly by using the bottom plate to attach the M3x30mm standoffs with the M3x6mm screws and the M3x5mm screws to mount the isolation camera mount on the front.
- Page 4 bottom plate assembly dji O3 air unit bottom plate heat sink set M1.6x12mm screws Use the bottom plate to mount the dji O3 module in the front 25x25MM pattern. Secure the module to the heat sink plates by using the M1.6x12mm screws.
- Page 5 closing the assembly pigtail core plates Close the frame by installing the core plates in the tabs and secure the top and bottom assemblies and the M3x6MM screws. In order to add the nylon landing feet use the M3x12MM screws to M3x6mm M3x12mm secure them to the bottom plate.
- Page 6 M3x10mm screws closing the assembly lipo pad crossfire horizontal mount universal action camera mount M2x6mm screws isolation camera plate M2 lock M2 nylon washer M2 rubber washer grommet M2x8mm screws Finish the build by adding the accessories and miscelaneous parts such as the lipo pad.
