Summary of Contents for Star 51
- Page 1 USER MANUAL Model Star 51 Latching Handset Star Universal (Gosport) Ltd Unit 2, Clarence Wharf, Mumby Road, Gosport, Hampshire, United Kingdom, PO12 1AJ Tel: + 44 (0) 23 9258 2857 Fax: + 44 (0) 23 9251 1731 Email: sales@staruniversal.com Web: www.staruniversal.com...
- Page 2 Star Universal (Gosport) Ltd cannot be held responsible for eventual damage caused by specifications deviating from the standard model. Although extreme care has been exercised during the writing of this manual, Star Universal (Gosport) Ltd will not accept any liability for eventual errors in this manual and/or for the consequences of (mis)interpretation of the contents.
-
Page 3: Table Of Contents
With the purchase of this heat sealing machine you will be able to pack a great variety of products. Star Universal (Gosport) Ltd has ensured that all the machines, from the smallest to the largest model, fulfil the greatest demands. All the machines are built in-house to the highest standard and undergo vigorous testing. -
Page 4: Safety
Check with your bag/material manufacturer. SAFETY FEATURES All Star heat sealers are built to minimise risk of any injury to machine operators and anyone who can come into contact with them. The main risks involved with Star heat sealing and the safety features built into the machines are: Sprung jaw: After machine operation when releasing the latch the jaws are sprung to open. -
Page 5: Connecting The Handset To The Power Pack
Power Pack Serial Number: 000000/56 If you wish to connect a different set of jaws or sealing head to the above power pack please contact Star Universal with the new specification and power pack serial number so we can advise compatibility. -
Page 6: Monthly Maintenance
Change tapes, element and rubber if necessary. Check end blocks are not damaged. 6 MONTH MAINTENANCE Repeat monthly maintenance A 6-month maintenance kit can be ordered from Star Universal. YEARLY MAINTENANCE Contact Star Universal You can request an onsite visit or send the machine to... -
Page 7: Jaw Maintenance And Service Spares
Under normal operating conditions it will be necessary to replace certain expendable items that are readily available from our spares department. Use of non-Star genuine parts or the incorrect part number can cause damage to the machine and invalidate the warranty. - Page 8 Silicone Rubber/Sponge – Heated Jaw: Remove the barrier tape and element ribbon as above. Peel the silicone rubber away from the aluminium sealing jaw and clean any residual adhesive left behind. Apply a NARROW bead of silicone adhesive to the channel, cut a piece of silicone rubber to length and press into the channel ensuring a smooth surface.
-
Page 9: Thermocouple Replacement
THERMOCOUPLE REPLACEMENT Thermocouple: If the silicone has been replaced cut a shallow V in it just deep enough for the thermocouple wire to sit flush with the rubber, the tip/disc should be sat on top of the rubber. Place the thermocouple through the hole and fasten in place with thermocouple adhesive strip. The tip of the thermocouple should be in the centre of the silicone. -
Page 10: Jaw Assembly Diagram
HEATED JAW TENSION ASSEMBLY JAW ASSEMBLIES HEATED JAW WITH HEATED JAW UNHEATED JAW THERMOCOUPLE Part No Diag No Description B018003 50mm Barrier Tape E024002 Element Ribbon B017002 9.5mm Silicone Rubber B017007 9.5mm Silicone Sponge M202003 9.5mm Brass Shim B021005 Compression Spring B022002 Ball Bearing B023002... -
Page 11: Wiring Diagram
WIRING DIAGRAMS STAR HANDSET... -
Page 12: Technical Specification
As Star Universal only build industrial equipment to individual customer requirements the responsibility for the disposal lies with the end user. Star Universal will offer a collection service for machines we have built at the end of their useful life for recycling. -
Page 13: Warranty Policy
STAR UNIVERSAL WARRANTY POLICY The Company provides a 1-year warranty from the date of delivery on all Star Heat Sealing machines. If any part is found defective due to faulty manufacture, Star Universal will affect the repair or replacement to the customer free of charge providing: a) The fault is reported directly to the Service Department. - Page 14 Star Universal (Gosport) Ltd Unit 2, Clarence Wharf, Mumby Road, Gosport, Hampshire, United Kingdom, PO12 1AJ Tel: + 44 (0) 23 9258 2857 Fax: + 44 (0) 23 9251 1731 Email: sales@staruniversal.com Web: www.staruniversal.com...
