RightSpot
RightSpot enables automatic nozzle by nozzle swath control while maintaining consistent rate,
pressure, and droplet size at every nozzle. RightSpot can increase productivity, reduce overlap,
and achieve consistent results throughout a broad range of speed all while navigating
challenging terrain such as contours and odd-shaped fields.
General Guidelines
Some products tend to come out of suspension over time causing thick, slimy material to settle
in the boom and inhibit proper nozzle valve functionality. When using these types of products it
is a good practice to flush the boom with clean water when the sprayer won't operate for 6 or
more hours.
Use the recommended chemical mixing order when filling the sprayer to avoid plugging screens
and affecting nozzle valve functionality.
Avoid using wettable powder products in tank mixes and use liquid formulations when possible.
Dry ingredients have a higher tendency of plugging screens and settling out in the boom which
can affect nozzle valve functionality.
Use a minimum of 80 mesh screens to prevent debris from entering the boom that is large
enough to obstruct nozzle valves. Inspect filters prior to starting the season and periodically
throughout the season to ensure they are clean and undamaged.
Avoid cleaning VCMs and RightSpot Hub with high pressure water to prevent water from entering
the connectors and damaging the modules.
Operating RightSpot above 60 psi will increase wear and reduce life expectancy of
NOTE!:
the plungers.
1
PN 2006669–ENG Rev. A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RightSpot and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Ag Leader RightSpot

  • Page 1 Inspect filters prior to starting the season and periodically throughout the season to ensure they are clean and undamaged. Avoid cleaning VCMs and RightSpot Hub with high pressure water to prevent water from entering the connectors and damaging the modules.
  • Page 2 RightSpot Universal Boom Layout...
  • Page 3: Safety And Notices

    RightSpot is equipped with Ag Leader's DirectCommand L2 Rate Control Module and L2 Liquid Swath Control Module. The RightSpot Hub, Valve Control Modules (VCMs) and Nozzle Valve Assemblies are added to complete the RightSpot system. RightSpot incorporates Blended Pulse™ technology. Blended Pulse™ is a feature that pulses adjacent nozzles in alternate timing to ensure proper spray coverage.
  • Page 4: Product Registration

    Product Registration Ag Leader Technology products can be registered by one of the following methods. Registering allows the option of receiving notice of any new product updates or features. Register at the Ag Leader Web site: http://www.agleader.com Operator Safety Symbols These symbols are used throughout the manual to designate where extra attention is necessary for the reader.
  • Page 5: Nozzle Selection

    DANGER!: Nozzle Selection New nozzles will be required to utilize RightSpot with Blended Pulse ™. To identify the nozzle size appropriate for your sprayer and application rates, use the QR code or internet address, shown below, and reference the chart that matches your nozzle valve size and nozzle spacing.
  • Page 6 PWM systems or uncheck Nozzle Pulsing and operate like a standard sprayer with individual nozzle section control Ag Leader is not responsible for selecting the nozzle tip used in an application. Use NOTE!: these charts as a tool prior to selecting the specific nozzle tip that meets the needs for proper application.
  • Page 7: Maintenance

    Maintenance Disassembling and Reassembling a Nozzle Valve Assembly When inspecting and troubleshooting RightSpot, it will be necessary to remove and disassemble nozzle valve assemblies. The following instructions will guide the process. Disassembling Nozzle Valves 1. Remove the nozzle valve assembly from nozzle body by unscrewing the fly nut from the nozzle body.
  • Page 8 3. Remove the orifice insert. 4. Remove the plunger from the coil. Items to Review a. Inspect plunger seal for excessive wear. b. Identify and remove debris located on the plunger seal and the mating orifice. c. Look for debris and built up product residual around the plunger and inside the valve coil.
  • Page 9 3. Slide the fly nut on the coil assembly and insert the U-clip to hold the fly nut in place. 4. Install nozzle valve assembly. Refer to the following section for proper installation. Nozzle Valve Assembly Installation 1. Remove the Drip Check from the existing Nozzle body. 2.
  • Page 10 Cleaning Nozzle Valves RightSpot was designed to monitor valve plunger status and will generate lodged open/closed alarms when the valve plungers aren’t moving as expected. Lodged alarms indicate debris, sediments, or syrup-like residue in the valve is preventing proper operation.
  • Page 11: Parts List

    8. Reassemble the nozzle valve assembly and install on the nozzle body. Parts List Ag Leader offers two versions of Nozzle Valve Assemblies. The Standard Valve accommodates most typical application rates and speeds while the High Rate Valve can be utilized when higher application rates are required.
  • Page 12 Coil Assembly Standard Item Description Tee Jet Part Arag Part Wilger Part Number Number Number Coil Assembly 7W 116500-200 116500-200 116500-200 U-clip, Fly Nut 116500-222 116500-222 116500-222 Orifice Insert 116500-244 116500-243 3116500-244 O-ring, Spoke 116500-225 116500-225 116500-225 Common Plunger Assembly 116500-199 116500-199 16500-199 O-ring, orifice insert 116500-221...
  • Page 13 10pcs - 116500-245 116500-013 Service Kit - Spoke O-ring 10pcs - 116500-225 116500-014 Service Kit - Orifice Insert O-ring 10pcs - 116500-221 116500-200 Coil (7W) 116500-300 Coil (12W RightSpot Hub Item Description Part Number RightSpot Hub 4006634 Module PN 2006669–ENG Rev. A...
  • Page 14 Valve Control Module (VCM) Item Description Part Number Valve Control Module 4006635 (VCM) Diagnostics L2 Liquid Rate Controller High Current LED Status Definition No Power Solid Red Low Voltage Solid Green Power OK LED 1– Local CAN Communication Status Definition CAN Bus Idle Solid Red CAN Bus Off...
  • Page 15 Blinking Local CAN Bus Communicating with L2 Rate Controller Green LED 2– Local CAN Communication Status Definition Standard Working State RightSpot Hub LED 1 – PWR Status Definition Green High Current power present No power LED 2 – CAN Communication...
  • Page 16: Troubleshooting

    LED 3, 4, and 5– CAN Bus Status Status Definition CAN Bus Idle Solid Red CAN Bus Off Solid Amber CAN Bus Error Passive Blinking Amber CAN Bus Error Active LED 6 and 7 – High Current Power Status Definition Solid Green Power On No power Valve Control Modules...
  • Page 17 1. Remove nozzle valve assembly and orifice disk. Inspect for contaminants, plunger wear, and damage to the spoke o-ring and orifice insert. Replace any worn or damaged parts, rinse with clean water and re-install. Nozzle body/Coil Leak – Typically a result of the fly nut not being threaded on Problem: appropriately or a poor spoke o-ring seal.
  • Page 18 Alarm: VCM x: Low Voltage Trigger Condition: VCM voltage is below 8.5 volts Voltage is above 8.5 volts Clear Condition: Alarm: RightSpot Hub Not Communicating Trigger Condition: No CAN communication from RightSpot Hub to L2 Local Bus RightSpot Hub start communicating Clear Condition:...
  • Page 19 Alarm: VCM: Solenoid Open Circuit Trigger Condition: Solenoid is not plugged in Nozzle Valve Coil is plugged in and detected. Clear Condition: Alarm: VCM: Solenoid Short Circuit Trigger Condition: Nozzle Valve Coil is shorted or the two wire cable to nozzle valve is shorted. Short in nozzle valve coil or cabling is addressed.
  • Page 20: Nozzle Charts

    Nozzle Charts Standard (15 series), 20 Inch Nozzle Spacing Tip Sizes #6 — #15 Rate 15 GPA — 25 GPA 15 GPA 17.5 GPA 20 GPA 25 GPA Gauge Min. MPH @ MPH @ Min. MPH @ MPH @ Min. MPH @ MPH @ Min.
  • Page 21 Standard (15 series), 50 cm Nozzle Spacing Tip Sizes 01 #1 — 08 #8 Rate 50 L/Ha — 200 L/Ha 50 L/Ha 100 L/Ha 150 L/Ha 200 L/Ha Gauge Min. KPH @ KPH @ Min. KPH @ KPH @ Min. KPH @ KPH @ Min.
  • Page 22 High Rate (24 series), 20 Inch Nozzle Spacing Tip Sizes #1 — #5 Rate 5 GPA — 12 GPA 5 GPA 7.5 GPA 10 GPA 12 GPA Gauge Min. MPH @ MPH @ Min. MPH @ MPH @ Min. MPH @ MPH @ Min.
  • Page 23 High Rate (24 series), 50 cm Nozzle Spacing Tip Sizes 01 #1 — 08 #8 Rate 50 L/Ha — 200 L/Ha 50 L/Ha 100 L/Ha 150 L/Ha 200 L/Ha Gauge Min. KPH @ KPH @ Min. KPH @ KPH @ Min.
