DC92
Disc Mower Conditioner
SERVICE MANUAL
Part number 48068913
English
November 2016
Replaces part number 84207979

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DC92 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Case IH DC92

  • Page 1 DC92 Disc Mower Conditioner SERVICE MANUAL Part number 48068913 English November 2016 Replaces part number 84207979...
  • Page 2 SERVICE MANUAL DC92 48068913 04/11/2016...
  • Page 3 Contents INTRODUCTION Power Take-Off (PTO) ..............31 [31.201] Power Take-Off (PTO) drive shaft ..........31.1 [31.214] Secondary Power Take-Off (PTO) .
  • Page 4 INTRODUCTION 48068913 04/11/2016...
  • Page 5: Table Of Contents

    Contents INTRODUCTION Foreword - Important notice regarding equipment servicing ........3 Safety rules .
  • Page 6: Foreword - Important Notice Regarding Equipment Servicing

    Specifications, descriptions, and illustrative material herein are as accurate as known at time of publication but are subject to change without notice. In case of questions, refer to your CASE IH Sales and Service Networks. 48068913 04/11/2016...
  • Page 7: Safety Rules

    INTRODUCTION Safety rules Personal safety This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible death or injury. Throughout this manual you will find the signal words DANGER, WARNING, and CAUTION followed by special in- structions.
  • Page 8: Safety Rules - Personal Safety

    INTRODUCTION Safety rules - Personal safety General safety rules Use caution when you operate the machine on slopes. Raised equipment, full tanks and other loads will change the center of gravity of the machine. The machine can tip or roll over when near ditches and embankments or uneven surfaces.
  • Page 9: General Maintenance Safety

    INTRODUCTION Before you leave the machine: 1. Park the machine on a firm, level surface. 2. Put all controls in neutral or park lock position. 3. Engage the parking brake. Use wheel chocks if required. 4. Lower all hydraulic equipment — Implements, header, etc. 5.
  • Page 10: Wheels And Tires

    INTRODUCTION Wheels and tires Make sure that tires are correctly inflated. Do not exceed any recommended load or pressure. Follow the instructions in the manual for proper tire inflation. Tires are heavy. Handling tires without proper equipment could cause death or serious injury. Never weld on a wheel with a tire installed.
  • Page 11 INTRODUCTION Power Take-Off (PTO) Power Take-Off (PTO) driven machinery can cause death or serious injury. Before you work on or near the PTO shaft or service or clear the driven machine, put the PTO lever in the disengage position, stop the engine, and remove the key.
  • Page 12 INTRODUCTION Dispose of all fluids, filters, and containers in an environmentally safe manner according to local laws and regulations. Check with local environmental and recycling centers or your dealer for correct disposal information. Store fluids and filters in accordance with local laws and regulations. Use only appropriate containers for the storage of chemicals or petrochemical substances.
  • Page 13: Safety Rules - Ecology And The Environment

    CASE IH strongly recommends that you return all used batteries to a CASE IH dealer, who will dispose of the used batteries or recycle the used batteries properly. In some countries, this is a legal requirement.
  • Page 14: Torque - Nominal Tightening Torques For Normal Assembly

    INTRODUCTION Torque - Nominal tightening torques for normal assembly NOTE: In the metric tables, nominal sizes M4 through M8 hardware torque specifications are shown as a Newton meters (pound-inches) numerical value. Nominal sizes M10 through M24 hardware torque specifications are shown as a Newton meters (pound-feet) numer- ical value.
  • Page 15: Identification Markings

    INTRODUCTION Identification markings Metric hex head, flange hex head and carriage bolts, Classes (CL) 5.6 and upward NHIL14RB00662AA Metric bolt identification markings 1. Manufacturer's identification 2. Property class Metric hex nuts and locknuts, Classes (CL) 05 and upward NHIL14RB00663AA Metric hex nut identification markings •...
  • Page 16 INTRODUCTION NOTE: In the Imperial units tables, the nominal sizes, 1/4 (0.25) in (inch) and 5/16 (0.3125) in (inch) hardware torque specifications are shown as a Newton meters (pound-inches) numerical value. Nominal sizes 3/8 (0.375) in (inch) through 1 (1.0) in (inch) hardware torque specifications are shown as a Newton meters (pound-feet) numerical value.
  • Page 17 INTRODUCTION Identification marking Grades of inch bolts and free-spinning nuts SAE (J995) bolt head and nut grade identification Grade Grade identification marking Marking description Grade 2 No line marks Grade 5 Three line marks Grade 8 Six line marks Grade 2 No circumferential line marks Grade 5 Two circumferential line marks located 120°...
  • Page 18 INTRODUCTION Grades of inch prevailing torque locknuts, all metal (three common marking methods) On prevailing torque locknuts, the grade of nut is identified by one of three different sets of markings that denote the strength level and manufacturer. Common prevailing torque locknut grade identification markings Grade Grade identification marking Marking description...
  • Page 19: Basic Instructions - Shop And Assembly

    Only use CNH Original Parts or CASE IH Original Parts. Only genuine spare parts guarantee the same quality, duration, and safety as original parts, as they are the same parts that are assembled during standard production. Only CNH Original Parts or CASE IH Original Parts can offer this guarantee.
  • Page 20: Special Tools

    The special tools that CASE IH suggests and illustrate in this manual have been specifically researched and designed for use with CASE IH machines. The special tools are essential for reliable repair operations. The special tools are accurately built and rigorously tested to offer efficient and long-lasting operation.
  • Page 21: Specifications

    INTRODUCTION Specifications Roll conditioner units only Overall Width Transport position 3020 mm ( 9 ft 11 in) Field position 4520 mm ( 14 ft 10 in) Overall Length Transport position 5400 mm ( 17 ft 7 in) Field position 5230 mm ( 17 ft 2 in) Height Transport position 1730 mm ( 5 ft 8 in)
  • Page 22: Ground Speed

    INTRODUCTION Roll conditioner units only Cutterbar Type Modular No. of Discs Knives Per Disc Disc Cutting Diameter 500 mm (19.7 in) Disc Drive Bevel gears in sealed modules Disc Speed 3000 RPM Cutting Height, approximate 24 - 81 mm (0.95 - 3.2 in) with high stubble shoes 58 - 115 mm (2.25 - 4.5 in) Conditioner...
  • Page 23 Thank you so much for reading. Please click the “Buy Now!” button below to download the complete manual. After you pay. You can download the most perfect and complete manual in the world immediately. Our support email: ebooklibonline@outlook.com...
