  • Page 2: Table Of Contents

    Table Contents Introduction........................3 Key Features..........................3 Getting Started ........................4 Packing Contents ........................4 Minimum System Requirements ....................4 Driver Installation ........................4 Appliactions Installed ........................ 7 BlueSoleil Introduction......................8 Main Windows........................... 8 Bluetooth Connection Management..................11 Security Configurations ......................11 Appendix ..........................13 Specification ..........................13...

  • Page 3: Introduction

    Introduction The TBW-104UB is a class 1 Bluetooth v2.0 compliant USB adapter. This Bluetooth device utilizes Enhanced Data Rate (EDR) technology to support data rates up to 3Mbps. The TBW-104UB can communicate with other Bluetooth devices to form a "Piconet". The TBW-104UB provides a fully compliant Bluetooth system for data and audio applications.

  • Page 4: Getting Started

    If you have any Bluetooth driver (software) previously installed on your computer or built-in Bluetooth device, please remove the driver and disable Bluetooth device first! 1. Please insert the Utility & Driver CD into CD-ROM drive, and then follow the instruction below to install Utility and drivers.
  • Page 5 1. Please click Install Utility to begin Bluetooth adapter installation. 2. Please select Language from the drop down menu and then click OK. 3. Please Click Next 4. Please select I accept the terms in the license agreement. Click Next...
  • Page 6 5. Please Click Next 6. Click Install 7. Disregard all popup Windows except for the installation Window shown to the right and click Finish 8. Click Yes to restart the computer.

  • Page 7: Appliactions Installed

    2. Please plug in TBW-104UB. The drivers will install automatically. 3. After the completion of the driver installation, the Welcome to Bluetooth screen will appear. Assign your Windows system a device name and device type. In most cases, you should leave the security setting checked. Click OK.

  • Page 8: Bluesoleil Introduction

    In order to connect and share services via Bluetooth wireless technology, two devices must support the same Bluetooth Profile(s) as well as opposite device roles (i.e., one must be the server, and the other must be the client). Bluetooth enabled devices often support multiple profiles, and if involved in multiple connections, can perform different device roles simultaneously.
  • Page 9 Right-click on the red ball to display a pop-up menu of related operations (e.g., General Inquiry, My Services, Security, etc.). Remote Bluetooth Devices Remote devices are other Bluetooth enabled devices that are in the Bluetooth radio range of your local device. BlueSoleil uses different icons to indicated different types of remtoe devices. Icons Icon Meanings Remote devices can be in any of three states, which BlueSoleil indicates with different colors.
  • Page 10 Right-click on the icon to display a pop-up menu of related operations (e.g. Refresh Services, Pair Devices, Connect, etc.). Bluetooth Service Buttons of Remote Device Service buttons at the top of the Main Window represent a range of Bluetooth services potentially supported by Remote Devices. Icons Icon Meanings There are 3 states for the service icons, indicated by different forms.

  • Page 11: Bluetooth Connection Management

    Right-click on the service icon to display a pop-up menu of related operations. Bluetooth Connection Management To set up a Bluetooth connection, the remote device must be found first. There are 3 ways to find remote devices in BlueSoleil. Inquire Device 1.
  • Page 12 Main Window will have a red checkmark next to it. Manually In the Main Window, right click on the device icon, and in the pop-up menu, select Pair Device. In the Enter Bluetooth Passkey dialog, enter the same passkey that you enter on the remote device.

  • Page 13: Appendix

    Appendix Specification Class 1 Bluetooth v2.0 with EDR, backward compatible with Bluetooth v1.1 & Standard v1.2 Radio Frequency 2.4~2.4835 GHz, ISM band Spread Spectrum Frequency Hopping and Adaptive Frequency Hopping GFSK, DQPSK (2Mbps) and 8DPSK (3Mbps) Modulation Data Rate Up to 3 Mbps...
  • Page 14 There are no user serviceable parts inside the product. Do not remove or attempt to service the product through any unauthorized service center. This warranty is voided if (i) the product has been modified or repaired by any unauthorized service center, (ii) the product was subject to accident, abuse, or improper use (iii) the product was subject to conditions more severe than those specified in the manual.
  • Page 15 CONSEQUENTIAL, INDIRECT, SPECIAL, OR PUNITIVE DAMAGES OF ANY KIND, OR FOR LOSS OF REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF INFORMATION OR DATE, OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION WITH THE SALE, INSTALLATION, MAINTENANCE, USE, PERFORMANCE, FAILURE, OR INTERRUPTION OF THE POSSIBILITY OF SUCH DAMAGES, AND LIMITS ITS LIABILITY TO REPAIR, REPLACEMENT, OR REFUND OF THE PURCHASE PRICE PAID, AT TRENDNET’S OPTION.
