WAC InvisiLED PRO2+ Installation Instruction

INSTALLATION INSTRUCTION
InvisiLED PRO2+
LED-TC24XX-X
SAFETY INSTRUCTION
IMPORTANT: NEVER attempt any work without shutting off the electricity.
Always turn off power at fuse box prior to installation to prevent
•
electrical shock.
Intended for indoor use. Dry and damp locations.
•
• For installation and serviced by a qualified, licensed electrician.
• Install in accordance with national electric code, and local
regulations.
CAUTION – TO REDUCE RISK OF FIRE AND ELECTRICAL SHOCK
Read all instructions before installing.
•
• Handle product with care.
• Do not conceal or extend exposed conductors through a building
wall
To reduce the risk of fire and burns, do not install this lighting
•
system where the exposed bare conductors can be shorted or
contact any conductive materials
• To reduce the risk of overheating and potential fire risk, make sure
all connections are tight.
Do not install any fixture assembly closer than 6 in. from any
•
curtain, or similar combustible material.
• Do not modify or disassemble product beyond instructions or
warranty will be void.
Failure to follow safety warnings, and installation instruction will
•
void the warranty
INVISILED™ PRO2+ Tape Lights have no polarity for connection.
• If a 1/2"x1/2" or greater cove or channel is not built-in, a Retrofit Channel may be necessary to conceal the tape lights or provide
an extended surface for mounting or directing the light.
WIRING AND INSTALLATION:
1. Please refer to installation diagrams shown on next page.
Determine the number of separately powered runs needed. Calculate the number of power supplies.
Maxmimum run length:
Power consumption:
2. Measure the length of each run and round it off to the nearest 2-inch interval. Determine the necessary quantities of 1-ft, 5-ft, and 2-in
sections.
3. Count the number turns in the runs in order to determine the number of L, X, and Y connectors.
4. If making lateral turns at angles other than 90°, determine the number of joiner cables necessary to make the lateral adjustment.
5. Connect to power supply
Hard Wire
• Power supply must be installed away from heat sources and
accessible for service
• Power supply is UL listed. The power supply box has a
separate line volt, and low volt wiring compartments. Trade size
knock out are provided on both compartments. Connect
building wires to like color transformer wires with wire nuts.
• Building ground wire my be green or un-insulated, and attaches
to green wire from power supply box.
6. Connect the output female connector of the transformer with the male connector of the InvisiLED® tape or lead wires, to form straight
lines or turns around the installation surface.
7. LED sections may be cut where indicated at the end of the run only.
8. On smooth surfaces, the included adhesive is sufficient in most applications.
However if mounting surface is a porous or textured surface, then use a Mounting Clip every 6 inches to reinforce the installation.
9. Terminate each separately powered run with an end cap. Cut end caps or male end caps are the available choices for cut or uncut
sections respectively.
Waclighting.com Headquarters/Eastern Distribution Center
Phone (800) 526.2588 44 Harbor Park Drive
Fax (800) 526.2585 Port Washington, NY 11050
WAC Lighting retains the right to modify the design of our products at any time as part of the company's continuous improvement
25' per run with 96W power supply
15' per run with 60W power supply
4.1 Watts/ft with 24VAC and 2.5 Watts/ft with 24VDC
Consult with local inspector to assure compliance.
•
Do not submerge, or install within 5 feet of a swimming pool.
•
Do not connect the tape directly to high voltage power
•
• Do not exceed maximum run recommended for each tape series
ATTENTION - AFIN DE RÉDUIRE LES RISQUES D'INCENDIE ET
DE CHOC ÉLECTRIQUE
• Lire toutes les instructions avant d'installer.
• Manipuler le produit avec soin.
• Ne pas dissimuler et faire passer les conducteurs exposés à
travers un mur de bâtiment.
• Afin de réduire les risques d'incendie et de brûlures, ne pas
installer ce système d'éclairage là où les conducteurs dénudés
peuvent être court-circuités, ou entrer en contact avec des
matériaux conducteurs.
• Afin de réduire le risque de surchauffe et d'incendie potentiel,
s'assurer que toutes les connexions sont bien serrées.
• Ne pas installer aucun luminaire à moins de 6 pouces d'un rideau
ou d'un matériau combustible similaire.
• Ne pas modifier ou démonter le produit au-delà des instructions
sous peine d'annuler la guarantie.
• Ne pas respecter les avertissements de sécurité et des
instructions d'installation annulera la garantie.
Portable
• 24 Volts power supply plugs into standard 120 Volts 3 prong
grounded outlet
• Power supply must be installed away from the heat sources
• Class II output splices do not require enclosures
